Laser Distance Meter

Order no.: DISTO D110

The laser distance measuring device Leica Disto D110 is a handy and ergonomic measuring device for the measurement of length and surface measurements. With the Disto D110 laser distance measuring device, distances of up to 60 m can be determined. The measuring unit can be set to meters, feet or inches with the laser distance measuring device.


- Measuring range: 0.2 ... 60 m
- Accuracy: ± 1.5 mm
- Bluetooth interface
- Free app for smartphones / tablets



Manufacturer: Gottlieb Nestle GmbH
£ 138.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: Disto D210

Laser distance measuring device Leica Disto D210.


- Measuring range of up to 80 m
- Measuring accuracy: ± 1 mm
- Illuminated 3-line display



Manufacturer: Gottlieb Nestle GmbH
£ 155.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: Disto X310

The Disto X310 laser distance measuring device is extremely robust and protects the sensitive measuring elements with solid rubber components. The laser distance measuring device is thus protected against spray water and dustproof according to IP 65. Cleaning under water is no problem. With the 360 ° tilt sensor and the combination of distance and tilt measurement, you can determine the horizontal distance precisely and easily, even across obstacles.


- Measuring range up to 120 meters
- 360° Tilt sensor
- Smart Horizontal Mode
- Protection class IP 65



Manufacturer: Gottlieb Nestle GmbH
£ 232.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: Disto D810 Touch

The Leica DISTO D810 Touch is the world's first laser distance measuring device with a touch screen, thus ensuring a fast and intuitive operation. The laser distance meter Leica DISTO D810 Touch offers numerous measurement functions and performs distance, area, volume and trapezium measurements, amongst others. In addition, tracked inclinations and functions such as addition, subtraction or Pythagoras may be used with this laser range meter.


- Measuring range: 0.05 ... 200 m
- Accuracy: ± 1.0 mm
- Touch screen
- Built-in Camera
- Measurement in the photo possible



Manufacturer: Gottlieb Nestle GmbH
£ 671.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-LRF 600

PCE-LRF 600 is a metric-only rangefinding distance meter that not only measures distance, but also determines the speed of moving objects. Ideal for hunting, shooting, golfing and more, these compact laser rangefinding binoculars make great gifts for sports and outdoor enthusiasts.


- Distance measurement range: 6 ... 800 m
- Distance measurement accuracy: ±1 m; ± 0.2%
- Speed measurement range: 0 ... 300 km/h
- Speed measurement accuracy: ±1 km/h
- Measurement resolution: 1 m or 1 km/h



Manufacturer: PCE Instruments
£ 112.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: Distance-Master

The laser distance meter Distance-Master is equipped with a new technology, so you can measure more easily and accurately. Because of laserlight you take exact values, which you can see on the illuminated LC-display. With the plane and volume function of this laser distance meter you can capture room-sizes for materialweight-calculation. With addition and subtraction-function you can capture the room-extent and the wall area.


- Measurement Range: 0.05 ... 60 m
- Accuracy: ± 1.5 mm
- Simple assessment of room perimeter with the addition and subtraction
  functions



Manufacturer: UMAREX GmbH & Co. KG
£ 95.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: GLM 80

The high-tech Laser Distance Meter GLM 80 for convenient measurements with integrated 360° incline sensor. This Laser Distance meter helps you to make high accurate measurements in many different fields.


- Measurement range: 0.05 – 80 m
- Measurement accuracy, typical: ± 1.5 mm
- Measurement time, typical: < 0.5 s



Manufacturer: Bosch
£ 162.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: GLM-150

This Laser Distance Meter GLM 150 gives you more functionality and user-friendliness for indoor and outdoor work. The Laser Distance Meter integratet new functions such as partial height measurement, height calculation and roof slope measurement.


- Measurement range: 0.05 ... 150 m
- Measurement accuracy, typical: ± 1 mm
- Measurement time, typical: < 0.5 s



Manufacturer: Robert Bosch GmbH
£ 215.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: GLM-250-VF

Handheld Laser Distance Meter GLM 250 VF with the longest range (0,05 ... 250 m). This Laser Distance Meter gives you maximum measurement performance and precision, even in adverse lighting conditions, due to large glass lens and ceramic optics carrier.


- Measurement range: 0.05 ... 250 m
- Measurement accuracy, typical: ± 1 mm
- Measurement time, typical: < 0.5 s



Manufacturer: Robert Bosch GmbH
£ 258.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: DLS-C30

The Laser Distance Meter DLS-C30 is used to measure distances accurately in the industry sector. This laser Distance Meter can, for example, measure the contents of containers, the position of objects on conveyors or the thickness of rolls and cylinders, as well as store and evaluate data on a PC. You can connect the laser distance meter to a SPS for handling and reading.


- Measurement range: 0.05 ... 65 m in natural surfaces, 0.05 ... 150 m with
  testing target
- Resolution: 0.1 mm
- Accuracy: ±3 mm
- Operating temperature: -10 ... +50 ºC single measurement, -10 ... +45 ºC
  continous measurement
- RS-232 or RS-422 interface
- 0/4 ... 20 mA output
- Power supply: 9 ... 30 V DC



Manufacturer: Dimetix AG
£ 981.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: DLS-C15

The Laser Distance Meter DLS-C15 is used to measure distances accurately in the industry sector. This Laser Distance Meter can, for example, measure the contents of containers, the position of objects on conveyors or the thickness of rolls and cylinders, as well as store and evaluate data on a PC. You can connect the laser distance meter to a SPS for handling and reading.


- Measurement range: 0.05 ... 65 m in natural surfaces, 0.05 ... 150 m with
  testing target
- Resolution: 0.1 mm
- Accuracy: ±1.5 mm
- Operating temperature: -10 ... +50 ºC single measurement, -10 ... +45 ºC
  continous measurement
- RS-232 or RS-422 interface
- 0/4 ... 20 mA output
- Power supply: 9 ... 30 V DC



Manufacturer: Dimetix AG
£ 1,102.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: DLS-CH30

The Laser Distance Meter DLS-CH30 is used to measure distances accurately in the industry sector. This Laser Distance Meter can, for example, measure the contents of containers, the position of objects on conveyors or the thickness of rolls and cylinders, as well as store and evaluate data on a PC. You can connect the laser distance meter to a SPS for handling and reading.


- Measurement range: 0.05 ... 65 m in natural surfaces, 0.05 ... 150 m with
  testing target
- Resolution: 0.1 mm
- Accuracy: ±3 mm
- Operating temperature: -40 ... +50 ºC single measurement, -40 ... +45 ºC
  continous measurement
- RS-232 or RS-422 interface
- 0/4 ... 20 mA output
- Power supply: 24 ... 30 V DC



Manufacturer: AK-Industries GmbH
£ 1,102.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: DLS-CH15

The Laser Distance Meter DLS-CH15 is used to measure distances accurately in the industry sector. This Laser Distance Meter can, for example, measure the contents of containers, the position of objects on conveyors or the thickness of rolls and cylinders, as well as store and evaluate data on a PC. You can connect the laser distance meter to a SPS for handling and reading.


- Measurement range: 0.05 ... 65 m in natural surfaces, 0.05 ... 150 m with
  testing target
- Resolution: 0.1 mm
- Accuracy: ±1.5 mm
- Operating temperature: -40 ... +50 ºC single measurement, -40 ... +45 ºC
  continous measurement
- RS-232 or RS-422 interface
- 0/4 ... 20 mA output
- Power supply: 24 ... 30 V DC



Manufacturer: AK-Industries GmbH
£ 1,192.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: 50041203

The optical laser distance meter (sensor) ODSL 30 RS232 model covers a vast application range. For example the optical laser distance meter (sensor) allows positioning transfer cars, cranes, lifting facilities. Even a measurement of the volume can be performed by measuring in two dimensions with simultaneously moving the object can be performed by means of the optical laser distance meter (sensor) ODSL 30 series. There are different editions of the optical distance sensor purchasable.


- Measurement range: 200 ... 65,000 mm
- Geometric resolution: 1.0 mm
- Outputs: 2 x PNP / NPN / RS232



£ 1,312.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: 50041204

The optical laser distance meter (sensor) ODSL 30 RS485 output model covers a vast application range. For example the optical laser distance meter (sensor) allows positioning transfer cars, cranes, lifting facilities. Even a measurement of the volume can be performed by measuring in two dimensions with simultaneously moving the object can be performed by means of the optical laser distance meter (sensor) ODSL 30 series. There are different editions of the optical distance sensor available for purchase.


- Measurement range: 200 ... 65,000 mm
- Geometric resolution: 1.0 mm
- Outputs: 2 x PNP / NPN / RS485



£ 1,312.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: 50039447

The optical laser distance meter (sensor) ODSL 30 analog output model covers a vast application range. For example the optical laser distance meter (sensor) allows positioning transfer cars, cranes, lifting facilities. Even a measurement of the volume can be performed by measuring in two dimensions with simultaneously moving the object can be performed by means of the optical laser distance meter (sensor) ODSL 30 series. There are different editions of the optical distance sensor purchasable.


- Measurement range: 0.2 ... 30 m / 200 ... 30,000 mm
- Geometric resolution: 1.0 mm
- Outputs: PNP / NPN / mA / V
- 655 nm red light



£ 1,358.00

Price excl. VAT &. delivery
2 year Warranty
