Infrared Thermometer PCE-MIR 10-ICA

Infrared Thermometer PCE-MIR 10-ICA incl. ISO-Calibration Certificate

Order no.: PCE-MIR 10-ICA
GTIN (EAN): 4250348748195
£ 132.00
£ 158.40
price ex. (VAT / delivery)
:
4250348748195
PCE-MIR 10-ICA
Delivery time:5-7 working days

Description

Infrared Thermometer with a measuring range of -50 ... +500 °C / emission value 0.95 / Display of largest and smallest measured values / backlit display /  measuring spot 12:1 / quickly ready for use / optionally with ISO calibration certificate

The Infrared Thermometer has a measuring range of -50 ... +500 °C and covers a wide temperature range. With an accuracy of ±2 % ±2 °C at 20 ... 500 °C, the Infrared Thermometer is a very precise measuring device. For better orientation of the measuring spot, a laser pointer is built into the Infrared Thermometer. This laser has an output power of <1 mW. The emission value of the Infrared Thermometer is fixed at 0.95.
The Infrared Thermometer is used, for example, for surface temperature testing of electric motors, combustion engines or heat sinks. Thanks to its compact design, the Infrared Thermometer is handy and can be easily stowed away.
To switch on the Infrared Thermometer, press the measuring button. The measurement is then immediately taken by the Infrared Thermometer. When the button is released, the last value remains on the Infrared Thermometer display until a new measurement is taken. Optionally, the Infrared Thermometer can be equipped with an ISO calibration certificate.


Highlights

- Measuring range -50 ... 500 °C
- automatic switch-off
- immediate operating range
- Measuring ratio 12:1
- Max / Min function
- optionally with ISO calibration certificate
- incl. ISO-Calibration Certificate

Specification

Infrared temperature
Measuring range  -50 ... +20 °C
Resolution  0,1 °C
Accuracy  ±3°C

Infrared temperature
Measuring range  20 ... 500 °C
Resolution  0,1 °C
Accuracy  ±(2% of reading +2°C)

Infrared temperature
Measuring range  -58 ... +68 °F
Resolution  0,1 °F
Accuracy  ±5.4 °F

Infrared temperature
Measuring range  68 ... 932 °F
Resolution  0,1 °F
Accuracy  ±(2% of reading +3.6°F)

General technical data
Repeat accuracy  ±1°C / ±1.8°F
Measuring rate  2 Hz
Measurement spot  12:1
Laser  Class 2 <1mW
Emissivity  0,95
Spectral range  8 ... 14 µm
Wavelength range  630 ... 670 mm
Menu language  English, English (GB)
Protection class (device)  IP20
Power supply  batteries
(Rechargeable) battery  1 x 9 V 9V block , Alkali-manganese
Capacity  640 mAh
Operating conditions  0 ... 50 °C , 0 ... 90 % RH
Storage conditions  -10 ... 60 °C , 0 ... 80 % RH
Dimensions ( L x W x H )  175 x 75 x 35 mm
Weight  132 g

Delivery Scope

1 x Infrared Thermometer PCE-MIR 10-ICA
1 x Carrying bag
1 x instruction manual
1 x ISO-Calibration Certificate
