The HVAC Meter / HVACR Tester is equipped with a powerful motor that provides sufficient torque for stable operation. The motor power is 1.014 hp (750 W) and ensures reliable and efficient performance. With a flow rate of 340 ... 407 l/min, the HVAC HVAC Meter / HVACR Tester can quickly remove air and moisture from air conditioning systems, cooling systems or heat pumps.
The HVAC Meter / HVACR Tester has 1/4 inch and 3/8 inch connections, which increases its versatility and adaptability to different refrigerant hoses and applications. An integrated filter element effectively reduces oil mist, extends the service life of the HVAC Meter / HVACR Tester and ensures a cleaner working environment. The ergonomic rubber handle enables safe transport and easy handling.
The HVAC Meter / HVACR Tester is used to evacuate air conditioning systems, cooling systems or heat pumps before filling them with refrigerant. This removes moisture and air from the system, which improves the efficiency and service life of the system.
| General technical data | |
| Cable length | 130 cm |
| Connections | 1/4 inch SAE, 3/8 inch SAE |
| Motor power | 1,014 PS |
| Oil capacity | 780 ml |
| Ultimate vacuum | 0,02 mbar |
| Flow rate | 340 ... 407 l/min |
| Protection class (device) | IP20 |
| Power supply | 220 V AC | 50 Hz |
| Connector type | Schuko plug |
| Operating conditions | 5 ... 40 °C , 20 ... 80 % RH |
| Storage conditions | 5 ... 40 °C , 20 ... 80 % RH |
| Dimensions ( L x W x H ) | 390 x 140 x 250 mm |
| Weight | 1351 g |
