PCE Instruments

HVAC Meter / HVACR Tester

Order no.: PCE-HVAC 3

PCE-HVAC 3 is a multifunction HVAC meter, tester or diagnostic measuring device used for indoor climate and environmental monitoring. In addition to measuring relative humidity and ambient room / dry-bulb temperature, the meter calculates dew-point and wet-bulb temperatures in degrees Celsius (°C) and Fahrenheit (°F). Thus, heating, ventilation and air conditioning (HVAC) installations and HVAC system performance assessments are key applications of the PCE-HVAC 3 meter.


- Relative humidity measuring range: 0 ... 100% RH
- Ambient / dew-point temp. range: -30 ... +100 °C / -22 ... 212 °F
- Wet-bulb temp. range: 0 ... +80 °C / 32 ... 176 °F



Manufacturer: PCE Instruments
£ 99.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-TC 28

The IR HVAC Meter was designed for taking non-contact temperature measurements. To get accurate readings, the emissivity of the thermometer can be adjusted, depending on the operation purpose. Besides taking infrared images, the thermometer can also take normal pictures, as well as a mixture of both, due to the built-in digital camera.


- Measurement range: -20 ... +300 °C
- Accuracy: ±2 %, ±2 °C
- Frequency image recording: 9 Hz
- Camera: 48608 Pixel



Manufacturer: PCE Instruments
£ 227.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VA 20

PCE-VA 20 is a multifunction HVAC meter for testing heating, ventilation and air conditioning or cooling (HVAC) systems. This combination anemometer-hygrometer-thermometer features a 10 cm / 3.9" Ø fan impeller, easy-to-read backlit LCD, and functions such as display hold, average value, maximum value, minimum value, battery-saving automatic power off, low-battery indicator, and metric or imperial unit selection.


- Measures air flow velocity, volume flow, relative humidity, air temperature, dew
  point temperature and wet-bulb temperature
- Air flow velocity range: 0.2 ... 30 m/s (39.4 ... 5905.5 fpm)
- Accuracy: ±(1.5% of measured value + 0.3 m/s) when less than 20 m/s, ±(3% of
  measured value + 0.3 m/s) when more than 20 m/s
- Resolution: 0.1



Manufacturer: PCE Instruments
£ 172.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VA 20-SET

PCE-VA 20-SET is a multifunction HVAC meter with flow hoods for testing, assessing and balancing (TAB) heating, ventilation and air conditioning or cooling (HVAC) systems. This combination anemometer-hygrometer-thermometer features a 10 cm / 3.9" diameter fan impeller, easy-to-read backlit LCD, and functions such as display hold, average value, maximum value, minimum value, battery-saving automatic power off, low-battery indicator, and metric or imperial unit selection.


- Measures air flow velocity, volume flow, relative humidity, air temperature, dew point temperature and wet-bulb temperature
- Air flow velocity range: 0.2 ... 30 m/s (39.4 ... 5905.5 fpm)
- Accuracy: ±(1.5% of measured value + 0.3 m/s) when less than 20 m/s, ±(3% of measured value + 0.3 m/s) when more than 20 m/s
- Resolution: 0.1
- Includes 2 x flow hoods (1 x round 210 mm / 8.3" diameter, 1 x square 346 x 346 mm / 13.6 x 13.6")

Manufacturer: PCE Instruments
£ 283.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-HVAC 2

PCE-HVAC 2 is a high-velocity multifunction HVAC meter with a pitot tube. This portable HVAC meter can be used to determine air speed, air pressure, air flow, differential pressure and ambient temperature. The pitot tube allows access through tiny openings to take measurements in small pipe systems and other confined spaces.


- Measures air velocities up to 80 m/s / 262 ft/s
- Zero, minimum, maximum, average, record and hold functions
- Stores to memory up to 99 measurement values per parameter

Manufacturer: PCE Instruments
£ 160.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-TDS 100H

PCE-TDS 100H is a portable handheld clamp-on ultrasonic flow meter or HVAC meter used for non-invasive, unobstructed and highly accurate measurements of the flow velocity of liquids in metal, plastic and rubber pipes and tubes with a diameter of 57 … 720 mm / approx. 2 ... 28".  Software sold separately - see accessories for details.


- Measuring range: -32 ... +32 m/s
- Resolution: 0.0001 m/s
- Accuracy: ±1 % of measured value
- Linearity: 0.5 %
- Repeatability: 0.2 %
- Incl. factory calibration certificate



Manufacturer: PCE Instruments
£ 1,028.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-TDS 100HS

PCE-TDS 100HS is a portable handheld clamp-on ultrasonic flow meter or HVACR meter used for non-invasive, unobstructed and highly accurate measurements of the flow velocity of liquids in metal, plastic and rubber pipes and tubes with a diameter of 20 … 108 mm / approx. 3/4" ... 4". Software sold separately - see accessories for details.


- Measuring range: -32 ... +32 m/s
- Resolution: 0.0001 m/s
- Accuracy: ±1 % of measured value
- Linearity: 0.5 %
- Repeatability: 0.2 %
- Incl. factory calibration certificate



Manufacturer: PCE Instruments
£ 1,114.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-TC 29

PCE-TC 29 is an IR HVAC meter or infrared imaging camera used for visual inspection and non-contact infrared (IR) temperature measurement. Ideal for industrial use in electrical, mechanical, and building installations (such as in the auditing of machines, engines, or heating, ventilation, and air conditioning (HVAC) systems), this affordable infrared imager captures and saves 60 x 60 pixel IR resolution images to the included MicroSD card memory.


- IR Resolution: 60 x 60 pixels
- Temperature measuring range: -20 ... +300 °C (-4 ... +572 °F)
- IR image, visual image, picture-in-picture
- Hot / cold spot localisation
- Field of view: 20 x 20 °
- Adjustable emissivity from 0.1 ... 1.0
- Frequency image recording: 6 Hz
- Data storage: MicroSD

Manufacturer: PCE Instruments
£ 245.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-779N

The HVAC Meter PCE-779N measures temperatures quickly and without contact. The PCE-779N can be used for almost all surfaces. The emissivity of the HVAC Meter is adjustable over the range of 0.1 ... 1.0. The HVAC Meter has various measurement functions such as max, min and average measurement.


- OLED-Display
- Measuring range: -60 ... +760 °C
- Additional thermocouple measurement -64 ... +1400 °C
- Dual Laser
- Resolution: 0.1 °C at -83.2 ... +999.9 °C, otherwise 1 °C



Manufacturer: PCE Instruments
£ 86.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-423

The PCE-423 HVAC Meter with thermal sensor is highlighted by its good relation between price and quality. The PCE-423 HVAC Meter has a high resolution to be used for different applications. This PCE-423 HVAC Meter. It belongs to the the basic equipment for professionals working with ventilation systems.


- Measurement units:
- m/s: 0.1 ... 25.0
- feet/min: 20 ... 4925
- knots: 0.2 ... 48.5



Manufacturer: PCE Instruments
£ 125.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-330

PCE-330 is a multifunction digital HVAC meter or hygro-thermometer with a quick-response sensor for determining ambient temperature, relative humidity and dew point temperature. Equipped with an easy-to-read dual display, this data-logging indoor air quality (IAQ) meter features a large internal memory with storage for up to 16,000 recorded values.


- Temperature range: -20 ... +60 °C (-4 ... 140 °F)
- Relative humidity range: 0 ... 100% RH
- Resolution: 0.1
- Accuracy: ± 0.8 °C (± 1.5 °F), ± 2.0 ... 4.0% RH



Manufacturer: PCE Instruments
£ 212.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-ST 1

The PCE-ST 1 HVAC Meter is a handheld digital device to measure temperature in the HVAC sector, as for instance in heating ducts, air conditioning vents, insulation, crawl spaces, etc., thanks to its 120 mm stainless steel probe. The PCE-ST 1 HVAC Meter is very easy to use, with small dimensions and short response time.


- Measurement range: -40 ... +250 ºC
- Resolution: 0.1 º
- Accuracy: ±1.5 °C ±2 ºC
- Sensor: NTC



Manufacturer: PCE Instruments
£ 15.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-777N

The HVAC Meter PCE-777N measures non-destructively and from a distance, the temperature of surfaces via infrared beam. This small HVAC Meter is characterized by simple operation and the red sighting tool.


- Temperature range: -30 ... + 260 °C
- Measuring spot (measuring distance to measuring spot size): 8: 1
- Resolution: 0.1 °C



Manufacturer: PCE Instruments
£ 25.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-TH 5

The HVAC Meter PCE-TH 5 is a universal temperature / humidity gauge which allows the measurement of both the ambient temperature and the ambient humidity, as well as the determination of the dew point and wet bulb temperature.


- Temperature measuring range: -20 ... +50 °C
- Humidity measuring range: 0 ... 99.9% RH
- Resolution: 0.1 °C, 0.1% RH
- Calculation of dew point and wet bulb temperature



Manufacturer: PCE Instruments
£ 31.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-TD 60

The HVAC Meter PCE-TD 60 with a measuring range of -40 ... +85 °C and USB interface allows the detection of temperatures in an adjustable interval. The data is collected in the internal memory of the HVAC Meter and can be output via USB interface to a PC for analysis and archiving.


- Measuring range: -40 ... +85 °C
- Internal memory for up to 32,000 readings
- USB interface
- Internal sensor



Manufacturer: PCE Instruments
£ 35.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-DC1

HVAC Meter PCE-DC1 for measuring AC current, AC voltage, DC current and frequency.


- AC current (50/60 Hz): 200 A / 0.1 A or 100 mA / ±3.0% + 8 digits
- DC current: 200 A / 100 mA / ±2.8% + 8 digits
- AC test voltage (without contact): 100 VAC to 600 VAC 50 / 60 Hz
- Frequency: 40 to 50 Hz / 51 to 510 Hz/ 0.51 to 1 kHz



Manufacturer: PCE Instruments
£ 39.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-DC3

HVAC Meter PCE-DC3 to determine indirectly, the AC/DC currents with high accuracy.


- AC current (50 / 60 Hz): 2 A  / 1 mA / ± 2.8 % + 10 dgt
- DC current: 2 A / 1 mA / ± 3.0 % + 10 dgt
- AC overload protection: 100 VAC up to 600 VAC 50 / 60 Hz



Manufacturer: PCE Instruments
£ 60.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-DC2

Digital Clamp Meter for measuring AC/DC current, AC voltage and resistance. This clamp meter is designed to indirectly detect AC/DC current and ohms. The clamp has white LEDs which illuminate the point of measurement and test the voltage without contact. Small dimensions of this device allow to take measurements in places with limited access. The clamp meter comes manufacturer calibrated and can optionally be certified according to ISO or standards.


- AC / DC current, voltage and resistance measurement
- 3 2/3-digit LCD display
- Power supply: 2 x 1.5V AAA battery
- Dimensions: 164 x 65 x 32 mm / 6.4 x 2.5 x 1.2 in



Manufacturer: PCE Instruments
£ 63.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-ITF 10

PCE-ITF 10 is a portable handheld HVAC meter, infrared thermometer gun or laser pyrometer that uses an infrared (IR) sensor to measure temperature in degrees Celsius (°C) or Fahrenheit (°F) without contact. This non-contact IR temperature meter can be used to detect leaks in walls, windows, doors and heating, ventilation and air conditioning (HVAC) systems.


- Measuring range: -50 ... +380 °C / -58 ... +716 °F
- Accuracy: ±3% -50 ... +20 °C / -58 ... +68 °F
                ±1% / ±1 °C +20 ... +380 °C / +68 ... +716 °F
- Optical resolution: 20:1
- Spectral range: 8 ... 14 μm
- Fixed emissivity: 0.95



Manufacturer: PCE Instruments
£ 65.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-P01

PCE-P01 is a portable handheld digital HVAC meter or differential pressure manometer used to measure differential pressure in pneumatic, compressor and pump installations, valves, tanks and heating, ventilation and air conditioning (HVAC) systems. The PCE-P01 displays min / max / average values right on the meter's screen for comparison against current measurement values.

- 0.001 to 0.137 bar (0.001 to 2.000 psi) measuring range
- 11 measurement units: bar, mmHg, ozin², kgcm², psi, inH2O, kPa, ftH2O, inHg, cmH2O, mbar
- Features real-time data-logging capabilities using the included PC software and USB cable

Manufacturer: PCE Instruments
£ 69.00

Price excl. VAT &. delivery
2 year Warranty

Purchase Advice on HVAC Meters

What exactly is HVAC? The specialist knows for certain: HLK describes the subject area of heating, ventilation and air-conditioning systems. Especially in the field of heating technology many physical variables can be measured. Whenever these systems have to be tested, maintained and monitored, the measuring instruments are used. The following text is a purchase advice and helps to find a suitable measuring device for the HVAC area.

A large area for measuring devices in the HVAC field is the measurement of temperature and humidity. These two parameters are decisive in order to check whether the heating and ventilation systems are still working correctly or whether the systems are set appropriately. The thermo-hygrometers from PCE Instruments are designed for quick and easy use in maintenance applications. Due to a simple operation of these HVAC measuring instruments, only a short training time is required. The HVAC hygrometers can be used both, for temporary measurement of temperature and humidity as well as for continuous monitoring. These HVAC meters often have an internal data logger that stores the measured values internally or on a memory card. The hygrometers can also directly perform many calculations, such as the dew point. The dew point is important to detect mold hazards. Hygrometers with data loggers are also suitable for determining the correct ventilation behavior.

It goes without saying that in the range of HVAC measuring instruments you can also find thermometers, that can directly measure a fluid temperature. These thermometers are available in different designs and with different measuring principles.

For measurement of temperatures on the heating pipes, it is recommended to mount a temperature sensor on the heating pipe to measure, for example, the flow and return temperature. For fast temperature measurements in boilers, radiators or floor heating systems, an infrared thermometer or even a thermal imaging camera is very well suited. These HVAC meters measure the surface temperature of all surfaces without contact and very quickly. To measure the water temperature of water heating equipment or other heaters, we recommend thermometers with an immersion sensor.

Below the thermometers or thermos-hygrometers are presented in accordance with their application area:

Room temperature / room climate - Thermo-hygrometer
Measurement of flow and temperature - Contact thermometer with differential measurement
Coninuous monitoring of temperatures on surfaces - Thermometer with data logger
Dew point measurement - Hygrometer with dew point calculation
Control of floor heating systems - Infrared thermometer / thermal imaging camera
Ventilation conrtol rooms - Hygrometer with data logger

nother area of HVAC measuring equipment is the monitoring of air flows. Anemometers are always used whenever ventilation systems are to be tested. Here, vane anemometers with corresponding funnel attachments are frequently used. The funnels are placed on the outlet of a ventilation or air-conditioning system and the correct volumetric flow is measured directly via an impeller. In the case that no reachable outlet is available for the measurement of the volumetric flow, a small hot wire anemometer can be used, which is placed directly into the duct. The advantage of a hot wire anemometer in HVAC area is that even very small wind speeds can be measured. Thus, this anemometer is not only suitable for checking ventilation systems, but also for checking the tightness of windows.

Frequently in the HVAC field there is also a task of looking into the components, ventilation systems in order to find a fault. However, there are usually no accesses or access is difficult to reach. For this application, in the products range of PCE Instruments, you may find special endoscopes, which complete the range of HVAC measuring instruments. Various cable lengths and designs allow looking inside in such areas, that otherwise would only be achievable with great effort. So, with the help of an HVAC endoscope, it is possible to look into the tubes for up to 30 m in order to control. By means of photo and video functions the damages can be additionally documented then. Frequently, for the control of the heating systems, an additional HVAC meter must be taken. A multimeter measures various electrical variables such as current, voltage and resistance. Especially when checking a heating system, it is often necessary and indispensable to use a multimeter. Does a relay switch properly? Does voltage come to the heater? Is a resistor defective? All this can be detected in the HVAC field with the help of a multimeter.

More Information about HVAC Meter

Air quality, temperature and humidity conditions in the offices, residential, and industrial buildings must meet certain sanitary standards. Keeping of these parameters in the given values should be done by ventilation, heating and air conditioning. When they work unsatisfactory or in case of redevelopment, reconstruction or modification of technological processes there should be carried out an adjustment for achieving the required sanitary standards.

Bad air quality, incorrect operation of ventilation system, high or low temperature or the presence of drafts influence the health and well-being of the people. it can also cause different breathing problems and diseases. HVAC Meter PCE-VA 20 applicationWith the help of an appropriate instrument you can measure air quality parameters and characteristics of the air and heat balance in the entire facility in order to improve, adjust and optimize the work of HVAC systems.

During the repair, maintenance and adjustment of heating, ventilation and air conditioning systems different parameters should be measured, such as temperature (including differential), pressure, power, capacity, resistance, voltage, dew point, air flow velocity, humidity, etc. For this purpose people usually use devices of various types. Our multifunctional HVAC meter is able to solve a variety of measurement tasks. It successfully replaces multiple traditional meters, thereby reducing the total time of performance and increasing efficiency. Versatility and multi-functionality of this device allow the use of one electronic unit with the probes of various types. In the process of making HVAC adjustments our multifunction HVAC meter can record the controlled quantities for further evaluation and comparison with the values that are defined by sanitary norms.

Unlike stationary measuring devices, such gauge performs measurements anywhere in the system, and therefore provides the most complete and objective information about the characteristics of the air and heat balance and air quality throughout the facility. HVAC Meter by testing an air ventilation tubesIt is characterized by the extended functionality. It can help you determine the parameters of indoor climate, as well as basic characteristics of air distribution and air exchange in the facility. All measurement results can be stored in memory and later transferred to a PC or other programs. Software and USB interface cable help you process, analyze and print data on the site. Internal data logger keeps the measurement results with the date and time in internal memory. When designing our multi-functional HVAC meter we have paid special attention to the maximum reliability and accuracy. Robust housing with IP protection class prevents accidental damages of the electronic unit. Our HVAC meter is compact, light, reliable, accurate, durable, easy and safe to use. With its help you can register all the necessary parameters of the microclimate in your residential room or office and make reports about the performed measurements with maximum comfort and in the shortest time. It is usually used in swimming pools, saunas, industrial ventilation systems and air ducts, offices and residential buildings and in other places where HVAC system control is required.

PCE Instruments provides extensive support of engineers, consultants, experts in the field of climate, experts in maintenance of ventilation and air-conditioning systems. Our qualified technicians will help you find the right HVAC meter with the functions that are needed for your work.
