PCE Instruments

Colorimeter

Order no.: PCE-CSM 1

The handheld portable digital colorimeter PCE-CSM 1 was developed for quality control and offers a high accuracy. When using the colorimeter, you can choose between different color spaces (CIE L*a*b*C*h, CIE L*a*b* and CIE XYZ). After a measurement with the colorimeter, the reading can be used as a reference value while other readings can be recorded as a sample and later be compared to the 100 reference value easily. A 6 mm aperture is used for sample scanning.


- CIE L*a*b*C*h, L*a*b* and XYZ
- automatic white and black calibration
- 8°/d geometry diffused illumination integrating sphere system
- rechargeable Li-ion battery



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-XXM 20
The colorimeter PCE-XXM 20 is used to quickly measure the color of surfaces. The colorimeter has a highly sensitive RGB photodiode as a color sensor. The measurement of the color with the colorimeter PCE-XXM 20 takes place in the LAB color space.

- Color spaces: CIE LAB, CIE XYZ, RGB, CMYK, Pantone
- Wavelength colour sensor: 400 ... 720 nm
- Interface: Micro-USB / Bluetooth
- Sensor: RGB Photodiode
- "Meterbox Lab" App (Playstore) (Android)
- "Meterbox Lab" App (App Store) (IOS)
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-RGB2

PCE-RGB2 is a colorimeter for RGB (red, green, blue) or HSL (hue, saturation, luminance) color measurements. The color meter's 45 ° / 0 ° measurement geometry and 16 mm / ≈ 0.63" diameter aperture accommodate standardized color measurement methods on a variety of surfaces. The handheld color-measuring probe is connected to the colorimeter via a 1.5 m / 4.9' long cable, allowing a wide range of motion for the color measurement procedure.


- Measurement geometry: 45° / 0°
- Measurement range: RGB: 0 to 1023 / HSL: 0 to 1.00
- Resolution: 1 for RGB / 0.001 for HS
- Repeatability: < 3 RGB, for a minimum of 1 measurement
- Internal light source can be disabled to measure active light sources



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CSM 2

A very precise Colorimeter with 45°/0° viewing angle. This very professional instrument works in color spaces CIEL*a*b*C*h*, CIEL*a*b*, and CIEXYZ. This kind of color meter is mainly made for the use in an R&D laboratory, for industrial product evaluation, or for any kind of color testing application. The Colorimeter comes fully equipped (click on detail sheet) and is manufacturer calibrated. - A color meter for industrial professionals and researchers -


- Measuring aperture of 8 mm and 45°/0° illumination/viewing angle
- Rechargeable lithium-ion battery
- Auto white black calibration
- Designed specifically for the food industry
- Software Included
- Stores 100 reference values and 20,000 samples



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CSM 3

The colorimeter PCE-CSM 3 was developed for quality control and offers a high accuracy. When using the colorimeter, you can choose between different color spaces (CIE L*a*b*C*h, CIE L*a*b*). After a measurement with the colorimeter, the reading can be used as a reference value while other readings can be recorded as a sample and later be compared to the reference value easily.


- CIE L*a*b*C*h, CIE L*a*b*
- Measuring geometry 8°/d
- White calibration standard included
- Stores 100 reference values and 20,000 samples
- Measuring aperture is 8 mm
- optional liquid sample kit listed under accessories



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CSM 4

This Colorimeter is especially designed for meat, food, vegetables or wet products testing. Only the aperture comes into contact with the surfaces to be measured. So it is guaranteed that no liquids can cause cross contamination while doing the measurement. The colorimeter simulates to see surfaces like with human eyes. Used mainly in the medical and food industry the color test instrument in addition meets all requirements for plastics surface measurements (PP, PE, PET, ABS, EVA) and also powders. The color meter is delivered manufacturer calibrated, but can optionally be certified to ISO standards.


- Measuring aperture of 20 mm and 45°/0° illumination/viewing angle
- Rechargeable lithium-ion battery
- Auto white black calibration
- Designed specifically for the food industry
- Software included



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-WSB 1

PCE-WSB 1 is a portable handheld battery-powered brightness / whiteness colorimeter used to measure the brightness level of paper, cardboard, cellulose, pulp, textiles, paint, enamel, plastic, porcelain, cement, concrete, building materials, chemicals, powders, talc, starch, flour, salt, detergents, cosmetics and other non-metal substances.

- Measures the whiteness degree of blue light (Wb = R457)
- Meets ISO 2470 and ISO 3688 standards
- Compact, lightweight and user-friendly

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CSM 6

The colorimeter PCE-CSM 6 was developed for quality control and offers a high accuracy. When using the colorimeter, you can choose between different color spaces (CIE L*a*b, CIE L*a*b*C*h). After a measurement with the colorimeter, the reading can be used as a reference value while other readings can be recorded as a sample and later be compared to the reference value easily. Useful for determining color difference, chromaticity index, color sample database management, and color difference cumulative analysis.


CIE L*a*b*C*h, CIE L*a*b*
- Measuring aperture: Ø8 mm
- optional liquid sample kit listed under accessories
- Storage of 100 reference values and 20,000 samples
- Light sources D65
- Illumination/Viewing Angles 8°/d



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CRM 40

PCE-CRM 40 is a portable handheld colorimeter or spectrophotometer used to accurately measure the correlated color temperature (CCT - in Kelvin), illuminance, chromaticity, excitation purity (Pe), luminous flux (in lumens - lm), RGB and dominant wavelength of light sources such as LED, organic LED (OLED) and other forms of organic electroluminescence (EL).


- Measuring range: 0.1 ... 150,000 lux / 0.01 ... 15,000 foot-candle
- Spectral wavelength range: 360 ... 780 nm
- Display: 3.2" colour LCD
- Chromaticity: Ev xy, Ev u'v'

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CSM 5

The colorimeter PCE-CSM 5 was developed for quality control and offers a high accuracy. When using the colorimeter, you can choose between different color spaces (CIE LAB, XYZ, LCh, RGB, LUV). In addition, the colorimeter PCE-CSM 5 comes with two different measuring apertures (Ø6 mm and Ø10 mm). After a measurement with the colorimeter, the reading can be used as a reference value while other readings can be recorded as a sample and later be compared to the reference value easily.


- CIE LAB, XYZ, LCh, RGB, LUV
- White calibration
- Storage of 100 reference values and 20,000 samples
- Light sources D65, A, C, D50, F2, F6, F8, F10, F11 and F12
- Exchangeable measuring apertures
- Illumination/Viewing Angles 8°/d and CIE 10°



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CSM 7

PCE-CSM 7 is a portable colorimeter used to measure different spectral parameters. This user-friendly, ergonomically designed colorimeter automatically performs a white and black calibration when powered on. Suitable for manufacturing quality control and assurance as well as product research and development, the colorimeter offers impressive measuring accuracy and comes manufacturer calibrated. Camera/illumination locating for small samples.


- Color spaces: CIEL*a*b*C*h* CIEL*a*b* CIEXYZ CIERGB CIEL*u*v*
  CIEL*C*h +Yellowness + Whiteness + Color Fastness
- Offers two different measuring apertures
- Three light sources D65, D50, A
- optional liquid sample kit listed under accessories
- Storage of 100 reference values and 20,000 samples
- Illumination/Viewing Angles 8°/d

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-TCR 200

The industrial Colorimeter PCE-TCR 200  device carries out an analysis of the color using CIE L*a*b color space. This colorimeter also allows you to determine the colors in the RGB color range. The test instrument is mainly made for use in plating and painting industries. It has three inspection conditions: D65 (daylight), D50, and F11. Also this color meter comes manufacturer calibrated.


- Conversion into LCH, RGB ...
- 8 mm aperture
- 10° Field of view
- White light source
- High repeatability
- Selection of three light sources
- Balancing of white and black objects
- Specular Component Included (SCI)



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CSM 8

The colorimeter and spectrophotometer PCE-CSM 8 was developed for quality control, offers a high accuracy and comes with a 3.5" touch screen display. When using the colorimeter, you can choose between different color spaces (CIE LAB, XYZ, Yxy, LCh, and LUV) and 13 illuminants. The reading can be used as a reference value while other readings can be recorded as a sample and later be compared to the reference value easily to determine delta pass/fail.  58 mm sphere with wavelength from 400 to 700 nm in 10 nm increments.


CIE LAB, XYZ, Yxy, LCh, and LUV
- 13 illuminants to choose, white and black calibration
- 1000 alphanumeric reference values and up to 10,000 sample values memory
- WI, YI, TI, Mt, Color Stain, Color Fastness, SCI and SCE option (specular included and excluded)
- Measuring aperture of 8 mm and 45°/0° illumination/viewing angle

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CSM 20
PCE-CSM 20 is a handheld colorimeter used for high-quality color measurement. Featuring a single 8 mm aperture and including SCI and SCE specular modes for industrial color measuring applications, the PCE-CSM 20 offers a long battery life, a 4-color lamp and an easy-to-use portable design. The PCE-CSM 20 covers the full spectrum from 400 to 700 nm in 10 nm increments. Camera/illumination locating for small samples.

- Measuring geometry: 8° / d
- Includes Yellowness, Whiteness, Opacity, Staining and other color indexes
- USB cable and software for data transfer
- 2,000 reference standard memory, 20,000 sample memory
- Light source: D65, A, C, D50
- Color ranges: CIE L*a*b, XYZ, Yxy, LCh, CIE LUV, Hunter L*A*B
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CSM 21
PCE-CSM 21 is a handheld spectrophotometer colorimeter used for high-quality color measurement. Featuring a custom 4 mm aperture and including SCI and SCE specular modes for industrial color measuring applications, the PCE-CSM 21 offers a long battery life, a 9-color lamp and an easy-to-use portable design. The PCE-CSM 21 covers the full spectrum from 400 to 700 nm in 10 nm increments. Camera/illumination locating for small samples.

- Measuring geometry: 8° / d
- Includes Yellowness, Whiteness, Opacity, Staining and other color indexes
- Bluetooth 4.0 and USB cable for data transfer
- 2000 reference standard memory, 20,000 sample memory
- Light sources: D65, A, C, D50, D55, D75, F2, F7, F11
- Color ranges: CIE Lab, XYZ, Yxy, LCh, CIE LUV, Hunter LAB
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CSM 10

The colorimeter PCE-CSM 10 was developed for quality control, offers a high accuracy and comes with a 3.5" touch screen display. You can choose between different color spaces like CIE L*A*B, XYZ, Yxy, LCh, LUV, LCH, LAB &WI &YI, Color Fastness, and Staining Fastness. 400 to 700 nm photodiode array for 10 nm wavelength increments with Reflectance Curve graph.


CIE L*A*B/LCh, CIE XYZ/Yxy, CIE LUV/LCH, LAB &WI &YI, Color Fastness, and Color Staining
- Measuring geometry 10° or 2°/d
- Black and white calibration
- Opacity, 18 light source options, metameric index, CIE 1976/1994/2000
- 1000 Standards, 15,000 sample memory

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CSM 22
PCE-CSM 22 is a handheld spectrophotometer colorimeter used for high-quality color measurement. Featuring a dual aperture 8 mm and 4 mm, and including SCI and SCE specular modes for industrial color measuring applications, the PCE-CSM 22 offers a long battery life, a 18-color lamp with UV light, and an easy-to-use portable design. The PCE-CSM 22 covers the full spectrum from 400 to 700 nm in 10 nm increments. Camera/illumination locating for small samples.

- Measuring geometry: 8° / d
- Includes Yellowness, Whiteness, Opacity, Staining and other color indexes
- Bluetooth 4.0 and USB cable for data transfer
- 2000 reference standard memory, 20,000 sample memory
- Illuminant: D65, A, C, D50, D55, D75, F1, F2, F3, F4, F5, F6, F7, F8, F9, F10, F11, F12
- Color ranges: CIE Lab, XYZ, Yxy, LCh, CIE LUV, Hunter LAB
- Combined LED and UV light
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CSM 30
This very accurate tabletop colorimeter is intended for laboratory use to perform measurements on liquids, paper, textiles or other reference samples. This spectrophotometer uses both transmission and reflectance to accurately measure liquids, solids, and pastes.

Chromaticity for spectral reflection:  Φ 25.4 mm / SCI, standard deviation ΔE*ab 0.02
Chromaticity for spectral transmittance:  Φ 25.4 mm / SCI, standard deviation ΔE*ab 0.02

- Color touchscreen
- 256 Pixel CMOS sphere-type Image Sensor
- Data storage: 2000 Standards, 20,000 Samples
- Menu languages: English, Chinese
- Single and average measurements
- Data interface: USB
- Device software included
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CSM 31
The colorimeter, like any other colorimeter, is responsible for colorimetry. This very accurate table colorimeter is intended for laboratory use to perform measurements on paper, textiles or, for example, reference samples.

Chromaticity for spectral reflection:
Φ 25.4 mm / SCI, standard deviation ΔE*ab 0.01
Chromaticity for spectral transmittance:
Φ 25.4 mm / SCI, standard deviation ΔE*ab 0.03

- Touchscreen
- 256 Pixel CMOS Image Sensor
- Data storage: 5000 Standards, 40000 Samples
- Menu languages: English, Chinese
- Single and average measurements
- Data interface: USB, Bluetooth
- Device software
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: 0287.01.31

The Colorimeter Spektromaster 565-45 is especially suitable for quality checks of many devices. The colorimeter has the main advantage of being able to measure color and gloss at the same time.  Samples with the same color but diverging gloss, appear to the human eye not the same, as the glossy surface is perceived as more sated and even darker. Therefore an inspection with the color meter is essential in order to achieve a consistent general picture. The meter comes calibrated by the manufacturer and can be certified to ISO or at any time.


- Measuring range: 400 ... 700 nm
- Resolution: 10 nm
- color: geometry 45°/0°, measuring aperture 11 mm / .4 in
- Gloss: geometry 60°, measuring aperture 5 x 10 mm / .2 x .4 in



Manufacturer: Erichsen GmbH & Co. KG
Test Instruments manufacturer
