PCE Instruments

Coating Thickness Gauge

Order no.: PCE-CT 24FN
The PCE-CT 24FN Coating thickness gauge allows you to quickly and accurately determine, for example, ink layer thicknesses. The mobile device enables thickness measurements on ferrous and non-ferrous metals. The measured value is displayed directly on the LC display.

- Measuring range: 0 ... 1500 μm
- Resolution: 0.1 μm (at <100 μm)
- Accuracy: ± 3% + 1 μm (at> 150 μm)
- Alarm when limit value exceeded
- Graphical representation of the measured values
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CT 80
The paint layer coating thickness gauge PCE-CT 80 is a measuring device for the nondestructive measurement of coatings (paints, paints, plastics ...) on steel / iron and non-ferrous metals.

- Measuring range: Fe: 0 ... 5000 μm (0 ... 196.9 mils) / NFe: 0 ... 3000 μm (0 ... 118.1 mils)
- For many materials such as:
- Iron
- Steel
- Aluminum
- Copper
- Brass
- Stainless steel
- Incl. ISO laboratory calibration with certificate
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CT 26FN
The PCE-CT 26FN coating thickness gauge can measure non-destructive coatings (paints, plastics ...) on steel / iron and non-ferrous metals. The PCE-CT 26FN coating thickness gauge is ideally suited to immediately detect, for example, accident damage to the vehicle.

- Measuring range: 0 ... 1250 μm / 0 ...  49.2 mils
- Resolution: 1 μm / 0.039 mils
- Accuracy: ± (3% + 2 μm / 0.079 mils)
- Wear-resistant sensor
- V-groove for measurement on pipes
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CT 26FN-ICA
The PCE-CT 26FN coating thickness gauge can measure non-destructive coatings (paints, plastics ...) on steel / iron and non-ferrous metals. The PCE-CT 26FN coating thickness gauge is ideally suited to immediately detect, for example, accident damage to the vehicle.

- Measuring range: 0 ... 1250 μm / 0 ...  49.2 mils
- Resolution: 1 μm / 0.039 mils
- Accuracy: ± (3% + 2 μm / 0.079 mils)
- Wear-resistant sensor
- V-groove for measurement on pipes
- Incl. ISO calibration certificate
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CT 65

PCE-CT 65 is a coating thickness gauge that uses magnetic induction (ferrous) or eddy current (non-ferrous) to take non-destructive measurements of coating and dry film thickness (DFT) on metal substrates such as steel and aluminum. This thickness gauge is ideal for painted and powder-coated surface testing, automotive paint inspection, coated material testing, and manufacturing quality control applications.


- Measuring range of 0 ... 1350 µm / 0 ... 53 mils
- Accuracy of ±2.5 % ±2 µm for 0 ... 1000 µm / ±3.5 % for 1000 µm ... 1350 µm / ±2 % ±0.08 mils for 0 ... 39.3 mils / ±3.5 % for 39.3 mils ... 53.1 mils
- Saves up to 1500 measurements to memory

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CT 65-ICA

PCE-CT 65 is a coating thickness gauge that uses magnetic induction (ferrous) or eddy current (non-ferrous) to take non-destructive measurements of coating and dry film thickness (DFT) on metal substrates such as steel and aluminum. This thickness gauge is ideal for painted and powder-coated surface testing, automotive paint inspection, coated material testing, and manufacturing quality control applications.


- Measuring range of 0 ... 1350 µm / 0 ... 53 mils
- Accuracy of ±2.5 % ±2 µm for 0 ... 1000 µm / ±3.5 % for 1000 µm ... 1350 µm / ±2 % ±0.08 mils for 0 ... 39.3 mils / ±3.5 % for 39.3 mils ... 53.1 mils
- Saves up to 1500 measurements to memory
- Incl. ISO Calibration Certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CT 5000H

PCE-CT 5000H is a coating thickness measuring instrument used for the rapid determination of coating thicknesses on ferrous (Type F) and non-ferrous (Type N) metals. The coating thickness gauge automatically detects the type of metal to be measured.


- Type F measuring range: 0 ... 5000 µm / 0 ... 5 mm / 0 ... 196 mils
- Type N measuring range: 0 ... 3000 µm / 0 ... 3 mm / 0 ... 118 mils
- Displays measuring units in μm, mm or mils
- Saves up to 2000 measurements to internal memory
- Practical V-groove on the measuring head

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CT 5000H-ICA

PCE-CT 5000H is a coating thickness measuring instrument used for the rapid determination of coating thicknesses on ferrous (Type F) and non-ferrous (Type N) metals. The coating thickness gauge automatically detects the type of metal to be measured.


- Type F measuring range: 0 ... 5000 µm / 0 ... 5 mm / 0 ... 196 mils
- Type N measuring range: 0 ... 3000 µm / 0 ... 3 mm / 0 ... 118 mils
- Displays measuring units in μm, mm or mils
- Saves up to 2000 measurements to internal memory
- Practical V-groove on the measuring head
- Incl. ISO Calibration Certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CT 28

The PCE-CT 28 Coating Thickness Gauge for cars is for measuring the thickness of paint and plastic on ferrous or non-ferrous materials without damaging the coating's surface. The Coating Thickness Gauge stands out due to its high range of measurement.


- Measurement range: 0 ... 1250 µm / 49.2 mils
- Resolution: 0.1 µm / 0.004 mils (in a range of 0.0 µm ... 99.9 µm / 3.9 mils)
  1 µm / 0.04 mils (above the range)
- Accuracy: ± 2% or 2.5 µm / 0.1 mils (highest reading is valid)
- Display: LCD with 4 mm x 10 mm (0.2 in x 0.4 in) high digits



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CT 28-ICA

The PCE-CT 28 Coating Thickness Gauge for cars is for measuring the thickness of paint and plastic on ferrous or non-ferrous materials without damaging the coating's surface. The Coating Thickness Gauge stands out due to its high range of measurement.


- Measurement range: 0 ... 1250 µm / 49.2 mils
- Resolution: 0.1 µm / 0.004 mils (in a range of 0.0 µm ... 99.9 µm / 3.9 mils)
  1 µm / 0.04 mils (above the range)
- Accuracy: ±2 % or 2.5 µm / 0.1 mils (highest reading is valid)
- Display: LCD with 4 mm x 10 mm (0.2 in x 0.4 in) high digits
- Incl. ISO Calibration Certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CT 27FN

PCE-CT 27FN is a Coating Thickness Gauge that takes non-destructive measurements of nonmagnetic coating, insulating layer and dry film thickness (DFT) on metal substrates such as steel and aluminum. Ideal for surface testing, automotive paint inspection, material testing and manufacturing quality control applications.


- Measuring range of 0 ... 1250 µm / 0 ... 50 mils
- Accuracy of ± (2% + 2 µm) / ± (2% + 0.1 mils)
- Features a resolution of 0.1 µ / 0.1 mils



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CT 27FN-ICA

PCE-CT 27FN is a Coating Thickness Gauge that takes non-destructive measurements of nonmagnetic coating, insulating layer and dry film thickness (DFT) on metal substrates such as steel and aluminum. Ideal for surface testing, automotive paint inspection, material testing and manufacturing quality control applications.


- Measuring range of 0 ... 1250 µm / 0 ... 50 mils
- Accuracy of ± (2% + 2 µm) / ± (2% + 0.1 mils)
- Features a resolution of 0.1 µ / 0.1 mils
- Incl. ISO Calibration Certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CT 5000

The PCE-CT 5000 Coating Thickness Gauge is an instrument for a nondestructive thickness measurement of coatings, such as varnishes, paints, etc. on steel / iron and non-ferrous metals. The extremely wide measuring range of the Coating Thickness Gauge goes up to 5000 µm or 200 mils. Gumming or plastic coatings for shock and impact protection can be controlled just as the thin paint coatings.


- Measuring range: 0 ... 5000 µm / 0 ... 196.8 mils
- Ferrous metals (Fe)
- Non-ferrous metals (NFe)
- Accuracy: ± 2 % or 2.5 µm / 0.1 mils (the highest value is valid)



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CT 5000-ICA

The PCE-CT 5000 Coating Thickness Gauge is an instrument for a nondestructive thickness measurement of coatings, such as varnishes, paints, etc. on steel / iron and non-ferrous metals. The extremely wide measuring range of the Coating Thickness Gauge goes up to 5000 µm or 200 mils. Gumming or plastic coatings for shock and impact protection can be controlled just as the thin paint coatings.


- Measuring range: 0 ... 5000 µm / 0 ... 196.8 mils
- Ferrous metals (Fe)
- Non-ferrous metals (NFe)
- Accuracy: ± 2 % or 2.5 µm / 0.1 mils (the highest value is valid)
- incl. ISO Calibration Certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CT 10
The coating thickness gauge is used for quick and easy measurement of ink layer thicknesses on metallic surfaces. Due to the measuring range and the possibility of measuring on ferrous and non-ferrous metals, the coating thickness gauge covers a large part of measuring tasks.

- Measuring range: 0 ... 2.20 mm
- Resolution: 0.01 mm
- Digital LCD display
- Automatic self-shutdown
- Adjustment with supplied standard possible
- For quick orientation measurement
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CT 25

The PCE-CT 25 Coating Thickness Gauge is used for quickly detecting the thickness of metals, such as steel and iron (F) as well as non-ferrous metals (N) in the automotive sector. The PCE-CT 25 Coating Thickness Gauge is used to detect damages in cars (the coating thickness of paint can say if the car has suffered any damage) to establish if the car has been in an accident and the resulting value of the car in the used car market.


- Measurement range: 0 µm ... 1000 µm / 40 mils
- Resolution: 0.1 mils / 1 µm
- Display: 3 1/2 digit LCD display
- Operating conditions: 0 ... 50°C / 32 ... 122°F



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CT 90
The coating thickness gauge is a versatile measuring device. This is made possible by the various optional sensors on the coating thickness gauge. Thanks to the surface temperature sensor, the coating thickness gauge can be used to determine the surface temperature of an object within a measuring range of -50 ... 125°C / -58 ... 257°F.

- Measuring range standard sensor : 0 ... 60 mm (Fe and non-Fe)
- Automatic sensor detection
- Zero point and one-point calibration
- Various sensors (optional selectable)
- Incl. ISO calibration certificate
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CT 100N
The coating thickness gauge works according to the magnetic inductive (ISO 2178) and the eddy current method (ISO 2360). These methods supported by the coating thickness gauge are used for the non-destructive testing of materials.

- Measuring range: 0 ... 1250 µm
- Accuracy: ± (1% + 1 µm)
- Resolution: 0.1 µm (<99.9 µm), 1 µm (> 100 µm)
- Measurement data storage for up to 500 data
- Data transfer via wifi and USB
- Two different probes for NFe and Fe (included)
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-USC 30

PCE-USC 30 is a coating thickness gauge designed for the non-destructive testing (NDT) and non-destructive evaluation (NDE) of electrically conductive materials. This portable, handheld thickness meter detects surface defects and measures layer thicknesses using an eddy current. The PCE-USC 30 material tester also measures metal conductivity in accordance with the International Annealed Copper Standard (IACS).


- Frequency range: 0.01 ... 16000 kHz
- Non-destructive testing of surfaces
- Makes surface defects and defects near the surface visible
- Conductivity measurement of metals according to IACS
- Power supply via internal battery



Manufacturer: PCE Instruments
Test Instruments manufacturer
