Clamp Meter

Order no.: PCE-DC1

Mini Clamp Meter for measuring AC current, AC voltage, DC current and frequency. PCE-DC 1 clamp meter is designed to indirectly detect AC/DC current and frequency. The clamp has one white LED which illuminates the point of measurement. Users can test the voltage without contact. Small dimensions of this test instrument allow to take measurements in places with limited access. The clamp meter is delivered manufacturer calibrated and can be certified according to ISO or standards.


- AC current (50/60 Hz): 200 A / 0.1 A or 100 mA / ±3.0% + 8
  digits
- DC current: 200 A / 0.1 A or 100 mA / ±2.8% + 8 digits
- AC test voltage (without contact):100 VAC to 600 VAC 50 /
  60 Hz
- Frequency (3 ranges): 40 to 50 Hz / 51 to 510 Hz/ 0.51 to 1 kHz



Manufacturer: PCE Instruments
£ 39.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-DC3

PCE-DC3 is a user-friendly digital clamp meter used to measure AC/DC electrical currents with high accuracy. This electrical current detector features a thoughtfully integrated built-in flashlight to illuminate dark spaces. This clamp meter should be part of every electrician's toolbox. The PCE-DC3 current clamp meter comes manufacturer calibrated. Optional ISO calibration is available as an accessory for an additional fee.


- AC current (50 / 60 Hz): 2 A  / 1 mA / ± 2.8 % + 10 dgt
- DC current: 2 A / 1 mA / ± 3.0 % + 10 dgt
- AC overload protection: 100 VAC up to 600 VAC 50 / 60 Hz

Manufacturer: PCE Instruments
£ 60.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-DC2

Digital Clamp Meter for measuring AC/DC current, AC voltage and resistance. This clamp meter is designed to indirectly detect AC/DC current and ohms. The clamp has white LEDs which illuminate the point of measurement and test the voltage without contact. Small dimensions of this device allow to take measurements in places with limited access. The clamp meter comes manufacturer calibrated and can optionally be certified according to ISO or standards.


- AC / DC current, voltage and resistance measurement
- 3 2/3-digit LCD display
- Power supply: 2 x 1.5V AAA battery
- Dimensions: 164 x 65 x 32 mm / 6.4 x 2.5 x 1.2 in



Manufacturer: PCE Instruments
£ 63.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-LCT 1

Clamp Meter to test leakage / RMS measurement / continuity and resistance test. With PCE-LCT 1 leakage current clamp meter it is possible to measure leakage current with a range up to 100 A. The  current meter can measure leakage current while current flows through electrical conductors that are not designed for conduction current. The leakage clamp meter is delivered manufacturer calibrated and can additionally be certified to ISO or standards.


- Measures current up to 100 A
- Measures voltage up to 600 V
- Measures resistance up to 400 Ohms
- Test cables are included



Manufacturer: PCE Instruments
£ 100.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-PCM 1

PCE-PCM 1 is a multipurpose clamp meter or power analyzer used to measure alternating current (AC), voltage (TRMS) and frequency to determine active (kW), apparent (kVA) and reactive (kVAR) power as well as active energy (kWh) consumption. Both the phase angle and the power factor (cos φ) are shown on the handheld power meter's large and easy-to-read backlit display.

- Voltage (50 ... 200 Hz): 100 / 400 / 750 V, ± (1.2 % + 5 digits)
- Internal memory: Stores up to 99 measurement values
- Includes USB cable and PC software
- Three-phase power measurement
- True RMS

Manufacturer: PCE Instruments
£ 100.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-DC 41

The clamp meter PCE-DC 41 can measure voltages up to 600 V, currents up to 600 A and electrical resistance up to 1000 ?. To perform a measurement, you can either use the measuring leads, which are included in the package of the clamp meter, or you can use the integrated clamp mechanism. By using the clamp of the clamp meter, you are able to measure the electrical parameters of an electrical conductor contact-free and without disconnecting it.


- Voltage: 600 V AC/DC
- Current: 600 A AC/DC
- Electrical Resistance: 1000 Ω
- Clamp mechanism



Manufacturer: PCE Instruments
£ 108.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-CM 4

By using the clamp meter PCE-CM 4, you are able to perform AC measurements on electrical conductors without having to disconnect them. Just put the flexible clamp of the clamp meter around the conductor to be measured and start the measurement. The flexible design of the clamp allows measurements even on hard to reach conductors.


- Range: 4 A / 40 A / 400 A AC
- Resolution: 0.001 A / 0.01 A / 0.1 A AC
- Accuracy: ± 3 %
- Easy to use



Manufacturer: PCE Instruments
£ 117.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-GPA 62

Three-Phase Clamp Meter with network analyzer / power and energy meter with data logger. he three-phase harmonic Analyzer (Graphic Power Quality Analyzer) is used for single-phase or three-phase measurements of active, reactive and apparent power, power factor, phase angle, energy, voltage, current as well as peaks and harmonics up to 50? of the harmonic waveform. This clamp meter is a perfect tool for all energetic measurements. It is delivered manufacturer calibrated and can be certified to ISO or standards.


- Voltage measurement: 4.0 ... 600.0 V RMS value ± 0,5 %, ± 5
  digits / 0,1 V
- Voltage peaks (> 10V): 50 Hz - 60 Hz / ± 5 % ± 50 digits
- Current measurements: 4.0 ... 1500.0 A real ± 1% V. ± 5 digits /
  0,01 A
- Current peaks (> 20A):  50 Hz - 60 Hz / ± 5 % ± 50 digits



Manufacturer: PCE Instruments
£ 512.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-360

The PCE-360 is a Clamp Meter with data logger functionality. This versatile power analyzer can take single-phase and three-phase power measurements both in real time and over an extended time period.


- Voltage range: 50.0 V ... 600.0 V True RMS value
- Current range: 3.0 A ... 999.9 A True RMS value
- Includes clamps, clips, leads, PC software and data cable

Manufacturer: PCE Instruments
£ 941.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-PA 8000

With the PCE-PA 8000 Clamp Meter you will be able to perform prolonged measurements of electrical properties. The measurement data is saved in xls format on the included SD card to be easily transferred to a computer or laptop for review. The Clamp Meter comes manufacturer calibrated and can be certified to ISO or UTIL standards as an option.
- Display: 3.7 in / 94 mm LCD (320 x 240 pixels) with LED backlight
- Electrical properties: AC V, AC A, active power, apparent power, power factor, phase angle, power frequency
- Voltage ranges: 10 V ... 600 V AC, automatic range selection
- Measures current up to 1200 A
- Security / Standards: IEC1010CAT III 600V

Manufacturer: PCE Instruments
£ 1,023.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-830-1

The PCE-830 Clamp Meter is used for measuring one to three phases of electrical quantities for alternating current (AC). This Clamp Meter also measures parameters such as voltage, current, frequency, harmonics, and power as well as indicating, according to standard EN50160, harmonic values, interharmonics, and asymmetrics. Interference, such as interruptions, leaks, overloads, or transience (from 16 µs) are detected with their corresponding values. The power logging instrument is delivered manufacturer calibrated. An ISO calibration certificate may be ordered optionally.


- PCE-830 + PCE-6801 amp clamp (100 A)
- Electrical conductor pick-up: 30 mm / 1.1 in diameter
- Range selection: manual (1 A, 10 A, 100 A)
- Clamp dimensions: 210 mm x 62 mm x 36 mm / 8.2 in x 2.4 in x 1.4 in
- Sampling rate: 2 sec.
- Memory size: 512 kB (max. 52,000 values (single phase)

Manufacturer: PCE Instruments
£ 1,286.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-830-2

The PCE-830-2 Clamp Meter is used for measuring one to three phases of electrical quantities for alternating current (AC). This Clamp Meter also measures parameters such as voltage, current, frequency, harmonics, and power as well as indicating, according to standard EN50160, harmonic values, interharmonics, and asymmetrics. Interference, such as interruptions, leaks, overloads, or transience (from 16 µs) are detected with their corresponding values. The power logging instrument is delivered manufacturer calibrated. An ISO calibration certificate may be ordered optionally.


- PCE-830 + PCE-6802 amp clamp (1000 A)
- Electrical conductor pick-up: 55 mm / 2.1 in diameter
- Range selection: manual (10 A, 100 A, 1000 A)
- Clamp dimensions: 244 mm x 97 mm x 46 mm / 9.6 in x 3.7 in x 1.8 in
- Sampling rate: 2 sec.
- Memory size: 512 kB (max. 52,000 values (single phase)

Manufacturer: PCE Instruments
£ 1,286.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-830-3

The PCE-830-3 Clamp Meter is used for measuring one to three phases of electrical quantities for alternating current (AC). This Clamp Meter also measures parameters such as voltage, current, frequency, harmonics, and power as well as indicating, according to standard EN50160, harmonic values, interharmonics, and asymmetrics. Interference, such as interruptions, leaks, overloads, or transience (from 16 µs) are detected with their corresponding values. The power logging instrument is delivered manufacturer calibrated. An ISO calibration certificate may be ordered optionally.


- PCE-830 + PCE-3007 flexible amp clamp (3000 A)
- Electrical conductor pick-up: 170 mm / 6.69 in diameter
- Length of electrical conductor: 610 mm / 24.0 in
- Dimensions: 257 mm x 155 mm x 57 mm / 10.1 in x 6.1 in x 2.2 in
- Sampling rate: 2 sec.
- Memory size: 512 kB (max. 52,000 values - single phase)

Manufacturer: PCE Instruments
£ 1,286.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-PA 8300

The easy-to-use PCE-PA 8300 Clamp Meter is the ideal tool for performing power and harmonics analysis as well as for measuring network capacity. The PCE-PA 8300 is a 3-phase power analyzer that features:


- Voltage measurement range of 10 V ... 600 V AC
- Current measurement range of (Set 1) 20 A ... 1200 A AC or (Set 2) 30 A ... 3000 A AC
- Performance measurement range of 0 kW ... 9.999 MW (VA/VAR)

Manufacturer: PCE Instruments
£ 1,492.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: CA-Mini01

Current transformers for multimeter to 150 A AC, Æ max. 10 mm, different output signals - The opening width of the clamp to this converter is 39 mm. The measured current is a conversion ratio of 1000; 1 or 100: 1 output as direct or alternating current or voltage of the clamp convertor. The clamp convertor is connected via the connector to any multimeter or to a data logger.


- Measuring range: 2 ... 150 A
- Accuracy: 2.5 %
- Bandwidth: 48 ... 500 Hz



Manufacturer: Chauvin Arnoux GmbH
£ 62.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: CA-Mini03

Current transformers for multimeter to 150 A AC, Æ max. 10 mm, different output signals. The clamp convertor can be used both for currents up to 150 A and for small currents of a few mA. The clamp convertor of the mini-series measures the AC reliably and accurately. Cables with a diameter up to 10 mm can be added to the clamp convertor. The opening width of the clamp to this converter is 39 mm.


- Measuring range: 1 ... 100 A
- Accuracy: 2%
- Bandwidth: 48 ... 500 Hz



Manufacturer: Chauvin Arnoux GmbH
£ 62.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: CA-Mini09

Current transformers for multimeter to 150 A AC, Æ max. 10 mm - The clamp convertor is connected via the connector to any multimeter or to a data logger. In addition to the measurement of simple direct current at 50 Hz, the clamp convertor of the mini-series measures the TRMS current up to 10 kHz, if the connected meter also supports this measurement.


- Measuring range: 1 ... 150 A
- Accuracy: 4%
- Bandwidth: 48 ... 500 Hz



Manufacturer: Chauvin Arnoux GmbH
£ 62.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: CA-Mini05

The clamp meter convertor of the mini-series impresses with its compact dimensions. The clamp convertor can be used both for currents up to 150 A and for small currents of a few mA. The clamp meter convertor of the mini-series measures the AC reliably and accurately. Cables with a diameter up to 10 mm can be added to the convertor. The opening width of the clamp to this converter is 39 mm.


- Measuring range: 0.005 ... 10 A, 1 ... 100 A
- Accuracy: 3%
- Bandwidth: 48 ... 500 Hz



Manufacturer: Chauvin Arnoux GmbH
£ 71.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: CA-Mini02

Current transformers for multimeter to 150 A AC, Æ max. 10 mm, different output signals - The clamp convertor can be used both for currents upto 150 A and for small currents of a few mA. The clamp meter convertor measures the AC reliably and accurately. Cables with a diameter up to 10 mm can be added to the clamp convertor. The opening width of the clamp to this converter is 39 mm.


- Measuring range: 0.05 ... 100 A
- Accuracy: 1%
- Bandwidth: 48 ... 10 Hz



Manufacturer: Chauvin Arnoux GmbH
£ 79.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: CA-MN08

Current transformers for multimeters, oscilloscopes and current faults, max. 200 A AC, max. Diameter 20 mm. With its bandwidth of 10 kHz, the Clamp Meter MN series is designed for various applications such as fault current, power and harmonics measurements. The Clamp Meter offers 3 choices for output. In addition to AC and AC voltage, a DC voltage output is possible from the Clamp Meter MN series.

- Rated current: 200 A AC
- Transformation ratio: 1,000/1
- Output: isolated Ø 4 mm female sockets



Manufacturer: Chauvin Arnoux GmbH
£ 95.00

Price excl. VAT &. delivery
2 year Warranty
