PCE Instruments

Air Flow Meter

Order no.: PCE-TA 30

The PCE-TA 30 air flow meter can measure air velocity, air temperature and air flow. The PCE-TA 30 air flow meter shows measurement values in its large backlight LCD display. The air flow meter shows the current value on the display as well as max. and min. values.


- Type of sensor: Wind Sensor
- External
- Memory: No
- Interface: No
- Measurement range: 1.0 ... 30.0 m/s
- Resolution: 0.01 m/s
- Accuracy: ±3% ±0.2 m/s

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-THA 10

The Multifunction Air Flow Meter PCE-THA 10 is easy to operate with one hand thanks to its compact size, the new structure and integrated impeller. In addition to the wind speed, the air flow meter measures the temperature, humidity, dew point, the wet bulb temperature and the air volume. Average values can be determined with the air flow meter from the 20 preset points.


- Temperature measuring range: -15 ... 50°C / 5 ... 122°F
- Humidity range: 5 ... 95% RH
- Air speed: 0.4 ... 35 m / s
- Air flow: 0 ... 9.999 m3 / s

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-A420

Without a doubt, the main advantage of this handheld cup vane air flow meter is that it doesn't need to be held exactly in the direction of the wind. Air flow meter with impellers typically have to be held exactly in the direction of the air flow to take accurate measurements. Digital cup vane Air flow meter, wind direction will not influence the measurement.


- 0.9 to 35.0 m/s
- 2.5 to 126.0 km/h
- 1.4 to 68.0 knots
- 1.6 to 78.2 miles/h

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VA 11

The Air Flow Meter PCE-VA 11 is an extensively used measuring instrument. This air flow meter offers the opportunity to determine air speeds, air temperature and infrared temperature. The illuminated LCD allows comfortable readings and facilitates use in dimly lit areas.


- Air speed range: 0.4 ... 30 m/s / 0.9 ... 67 mph
- Air flow range: 0 ... 9999 CFM / CMM
- Air temperature range: -10 ... 60°C / 14 ... 140°F
- IR temperature range: -50 ... 500°C / -58 ... 932°F

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VA 11-ICA

The Air Flow Meter PCE-VA 11 is a useful and versatile device for measuring air speeds, air temperature and infrared temperature. Thanks to the fast response time of the device, real-time measurement is possible without problems. The large display provides an accurate overview of the measured values.


- Air speed range: 0.4 ... 30 m/s / 0.9 ... 67 mph
- Air flow range: 0 ... 9999 CFM / CMM
- Air temperature range: -10 ... 60°C / 14 ... 140°F
- IR temperature range: -50 ... 500°C / -58 ... 932°F
- USB interface
- Incl. ISO Calibration Certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VA 20

PCE-VA 20 is a multifunction air flow meter for assessing wind, weather, indoor / outdoor environmental climate conditions as well as for testing heating, ventilation and air conditioning or cooling (HVAC) systems. This combination anemometer-hygrometer-thermometer features a 10 cm / 3.9" Ø fan impeller, easy-to-read backlit LCD, and functions such as display hold, average value, maximum value, minimum value, battery-saving automatic power off, low-battery indicator, and metric or imperial unit selection.


- Measures air flow velocity, volume flow, relative humidity, air temperature, dew
  point temperature and wet-bulb temperature
- Air flow velocity range: 0.2 ... 30 m/s (39.4 ... 5905.5 fpm)
- Accuracy: ±(1.5% of measured value + 0.3 m/s) when less than 20 m/s, ±(3% of
  measured value + 0.3 m/s) when more than 20 m/s
- Resolution: 0.1

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VA 20-SET

PCE-VA 20-SET is a multifunction air flow meter with capture hoods for assessing and balancing heating, ventilation and air conditioning or cooling (HVAC) systems. This combined hygrometer-anemometer-thermometer possesses a 10 cm / 3.9" diameter fan impeller and a bright backlit LCD. The functions of the air flow device incorporate display hold, mean value, max value, min value, battery-saving auto shutdown, low-battery display, and a choice between metric and imperial units.


- Measures air flow velocity, volume flow, relative humidity, air temperature, dew
  point temperature and wet-bulb temperature
- Air flow velocity range: 0.2 ... 30 m/s (39.4 ... 5905.5 fpm)
- Accuracy: ±(1.5% of measured value + 0.3 m/s) when less than 20 m/s, ±(3% of
  measured value + 0.3 m/s) when more than 20 m/s
- Resolution: 0.1°C / 0.18°F
- Includes 2 x capture hoods (1 x round 210 mm / 8.3 in Ø, 1 x square 346 x 346
  mm / 13.6 x 13.6 in)

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VA 20-ICA

The PCE-VA 20 is a versatile multifunction air flow meter for determining environmental conditions such as wind, temperature and humidity. It is additionally used to test heating, ventilation and air conditioning / cooling (HVAC) systems. This triple thermometer-hygrometer-anemometer device has a 10 cm / 3.9" Ø fan impeller and a clear backlit LCD. Available functions include display hold, average / maximum / minimum value, auto shutdown, low-battery warning, and metric / imperial choice.


- Measures air flow velocity, volume flow, relative humidity, air temperature, dew
  point temperature and wet-bulb temperature
- Air flow velocity range: 0.2 ... 30 m/s (39.4 ... 5905.5 fpm)
- Accuracy: ±(1.5% of measured value + 0.3 m/s) when less than 20 m/s, ±
  (3% of measured value + 0.3 m/s) when more than 20 m/s
- Resolution: 0.1
- Incl. ISO Calibration Certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-WSAC 50

PCE-WSAC 50 is an air flow meter alarm controller that displays the current wind speed as well as the average wind speed of the last 2 and 5 minutes. This air flow meter alarm controller allows measurement of the slightest of wind movements. PCE-WSAC 50 is used for a variety of wind monitoring applications in industries such as construction, mining, renewable energy and manufacturing.


- Pre-alarm and full alarm with visual and audible warnings
- Optional RS-485 modbus interface for data communication
- Measuring range: 0 ... 50 m/s or 0 ... 110 mph
- Incl. ISO calibration certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-WSAC 50-110
The Air Flow Meter PCE-WSAC 50-110 can be used in different fields of application. In use, the air flow meter carries out measurements from the smallest wind movements. The air flow meter  can be used to monitor and alert on the current wind speed.

- Supply voltage: 230 V AC
- Input signal: 4 ... 20 mA
- 2 types of alarms
- Sensor supply via evaluation device
- Degree of protection: IP66
- Incl. ISO calibration certificate
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-WSAC 50-120
The Air Flow Meter PCE-WSAC 50-120 can be used in different fields of application. In use, the air flow meter carries out measurements from the smallest wind movements. The air flow meter  can be used to monitor and alert on the current wind speed.

- Wind measuring device with adjustable alarms
- 2 alarm types
- Supply voltage: 230 V AC
- Input signal: 0 ... 10 V
- Sensor supply via evaluation device
- Degree of protection: IP66
- Incl. ISO calibration certificate
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-WSAC 50-210
The Air Flow Meter PCE-WSAC 50-210 can be used in different fields of application. In use, the air flow meter carries out measurements from the smallest wind movements. The air flow meter  can be used to monitor and alert on the current wind speed.

- Wind measuring device with adjustable alarms
- 2 alarm types
- Supply voltage: 115 V AC
- Input signal: 4 ... 20 mA
- Sensor supply via evaluation device
- Degree of protection: IP66
- Incl. ISO calibration certificate
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-WSAC 50-220
The Air Flow Meter PCE-WSAC 50-220 can be used in different fields of application. In use, the air flow meter carries out measurements from the smallest wind movements. The air flow meter  can be used to monitor and alert on the current wind speed.

- Wind measuring device with adjustable alarms
- 2 alarm types
- Supply voltage: 115 V AC
- Input signal: 0 ... 10 V
- Sensor supply via evaluation device
- Degree of protection: IP66
- Incl. ISO calibration certificate
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-WSAC 50-310
The Air Flow Meter PCE-WSAC 50-310 can be used in different fields of application. In use, the air flow meter carries out measurements from the smallest wind movements. The air flow meter  can be used to monitor and alert on the current wind speed.

- Wind measuring device with adjustable alarms
- 2 alarm types
- Supply voltage: 24 V DC
- Input signal: 4 ... 20 mA
- Sensor supply via evaluation device
- Degree of protection: IP66
- Incl. ISO calibration certificate
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-WSAC 50-320
The Air Flow Meter PCE-WSAC 50-320 can be used in different fields of application. In use, the air flow meter carries out measurements from the smallest wind movements. The air flow meter  can be used to monitor and alert on the current wind speed.

- Wind measuring device with adjustable alarms
- 2 alarm types
- Supply voltage: 24 V DC
- Input signal: 0 ... 10 V
- Sensor supply via evaluation device
- Degree of protection: IP66
- Incl. ISO calibration certificate
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-WSAC 50-710

PCE-WSAC 50-710 is an air flow meter that displays the current wind speed as well as the average wind speed of the last 2 and 5 minutes. This air flow meter allows measurement of the slightest of wind movements. The air flow meter is used for a variety of wind monitoring applications in industries such as construction, mining, renewable energy and manufacturing.


- Pre-alarm and full alarm with visual and audible warnings
- Measuring range: 0 ... 110 mph
- Power supply: 230 V AC
-
Signal input: 4...20 mA
- incl. ISO calibration certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-WSAC 50-111
The Air Flow Meter PCE-WSAC 50-111 can be used in different fields of application. In use, the air flow meter carries out measurements from the smallest wind movements. The air flow meter  can be used to monitor and alert on the current wind speed.

- Wind measuring device with adjustable alarms
- 2 alarm types
- Supply voltage: 230 V AC
- Input signal: 4 ... 20 mA
- Communication: RS485
- Sensor supply via evaluation device
- Degree of protection: IP66
- Incl. ISO calibration certificate
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-WSAC 50-121
The Air Flow Meter PCE-WSAC 50-121 can be used in different fields of application. In use, the air flow meter carries out measurements from the smallest wind movements. The air flow meter  can be used to monitor and alert on the current wind speed.

- Wind measuring device with adjustable alarms
- 2 alarm types
- Supply voltage: 230 V AC
- Input signal: 0 ... 10 V
- Communication: RS485
- Sensor supply via evaluation device
- Degree of protection: IP66
- Incl. ISO calibration certificate
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-WSAC 50-211
The Air Flow Meter PCE-WSAC 50-211 can be used in different fields of application. In use, the air flow meter carries out measurements from the smallest wind movements. The air flow meter  can be used to monitor and alert on the current wind speed.

- Wind measuring device with adjustable alarms
- 2 alarm types
- Supply voltage: 115 V AC
- Input signal: 4 ... 20 mA
- Communication: RS485
- Sensor supply via evaluation device
- Degree of protection: IP66
- Incl. ISO calibration certificate
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-WSAC 50-221
The Air Flow Meter PCE-WSAC 50-221 can be used in different fields of application. In use, the air flow meter carries out measurements from the smallest wind movements. The air flow meter  can be used to monitor and alert on the current wind speed.

- Wind measuring device with adjustable alarms
- 2 alarm types
- Supply voltage: 115 V AC
- Input signal: 0 ... 10 V
- Communication: RS485
- Sensor supply via evaluation device
- Degree of protection: IP66
- Incl. ISO calibration certificate
Manufacturer: PCE Instruments
Test Instruments manufacturer
