Accelerometer

Order no.: PCE-PVS 10
The Acceleration Sensor has been developed for the continuous monitoring of the vibration speed. The Acceleration Sensor is available in different versions. Depending on the type of vibration sensor, a distinction is made between design and measuring range.

- Measuring range: ± 12.7 mm / s
- Frequency range: 3 ... 1500 Hz
- Design: vertical connection
- Power supply: 12 ... 24 V DC in current loop


£ 435.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-PVS 20
The Acceleration Sensor has been developed for the continuous monitoring of the vibration speed. The Acceleration Sensor is available in different versions. Depending on the type of vibration sensor, a distinction is made between design and measuring range.

- Measuring range: ± 25.4 mm / s
- Frequency range: 3 ... 1500 Hz
- Design: vertical connection
- Power supply: 12 ... 24 V DC in current loop


£ 435.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-PVS 30
The Acceleration Sensor has been developed for the continuous monitoring of the vibration speed. The Acceleration Sensor is available in different versions. Depending on the type of vibration sensor, a distinction is made between design and measuring range.

- Measuring range: ± 12.7 mm / s
- Frequency range: 3 ... 1500 Hz
- Design: horizontal connection
- Power supply: 12 ... 24 V DC in current loop


£ 435.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VT 1100

The accelerometer is designed for quick measurements of an imbalance in machines and the examination of bearings and gears. The accelerometer is also frequently used to evaluate the state of small electronic motors. Meter can only be used for realtime measurement, no memory storage.

- Vibration Acceleration: 0.01 ... 199.9 m/s2 (peak value)
- Vibration Speed: 0.01 ... 199.9 mm/s (effective)
Vibration Displacement:  0.001 ... 1.999 mm (peak-peak)
- Accuracy: ±5%, ±2 Digits (20 Hz ... 1 KHz) / ±10%, ±2 Digits (10 Hz ... 20 Hz)
- Frequency: Accel. and Vel. 10 Hz ... 1 kHz, Displacement 10 Hz ... 500 Hz
- Frequency range: 10 Hz ... 1 kHz
- Needle probes: 10mm / 0.39" // 45mm / 1.77"


£ 254.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VT 1100S

The accelerometer is suitable for relative measurements on various machines. With the 45 mm long needle probe, you can access hard-to-reach places in machines and motors. For this reason, this accelerometer is used for rapid measurement of imbalance and for checking bearing and gear conditions.

- Frequency range: 10 Hz ... 1 kHz
- Measures speed, distance, acceleration in metric units
- Holds the reading after each measurement
- Portable and battery operated
- Needle probe: 45mm / 1.77"

£ 254.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-WVS 50
Portable accelerometer  used to monitor, diagnose, control and solve problems related to the vibration velocity of various industrial equipment.

- Vibration velocity: 0,01 ... 200 mm/s
- Vibration acceleration: 0,1 ...  200 m/s²
- Vibration displacement: 2 ... 2000 μm
- Frequency range: 10 ... 1000 Hz
- Accuracy: ± 5
- Display: OLED, 0,91"
£ 343.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VT 1100-ICA

The accelerometer is designed for quick measurements of an imbalance in machines and the examination of bearings and gears. The accelerometer is also frequently used to evaluate the state of small electronic motors. Meter can only be used for realtime measurement, no memory storage.

- Vibration Acceleration: 0.01 ... 199.9 m/s2 (peak value)
- Vibration Speed: 0.01 ... 199.9 mm/s (effective)
Vibration Displacement:  0.001 ... 1.999 mm (peak-peak)
- Accuracy: ±5%, ±2 Digits (20 Hz ... 1 KHz) / ±10%, ±2 Digits (10 Hz ... 20 Hz)
- Frequency: Accel. and Vel. 10 Hz ... 1 kHz, Displacement 10 Hz ... 500 Hz
- Frequency range: 10 Hz ... 1 kHz
- Needle probes: 10mm / 0.39" // 45mm / 1.77"
- incl. ISO Calibration Certificate


£ 415.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VT 1100S-ICA



The accelerometer is suitable for relative measurements on various machines. With the 45 mm long needle probe, you can access hard-to-reach places in machines and motors. For this reason, this accelerometer is used for rapid measurement of imbalance and for checking bearing and gear conditions.



- Frequency range: 10 Hz ... 1 kHz
- Measures speed, distance, acceleration in metric units
- Holds the reading after each measurement
- Portable and battery operated
- Needle probe: 45mm / 1.77"
- incl. ISO Calibration Certificate

£ 415.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-WVS 50-ICA
Portable accelerometer  used to monitor, diagnose, control and solve problems related to the vibration velocity of various industrial equipment.

- Vibration velocity: 0,01 ... 200 mm/s
- Vibration acceleration: 0,1 ...  200 m/s²
- Vibration displacement: 2 ... 2000 μm
- Frequency range: 10 ... 1000 Hz
- Accuracy: ± 5
- Display: OLED, 0,91"
incl. ISO Calibration Certificate
£ 498.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VDL 16I
The accelerometer PCE-VDL 16I from PCE Instruments measures and stores the relevant measured variables: temperature, relative humidity, air pressure, light as well as acceleration in three axes by means of a vibration sensor. Therefore, this accelerometer is ideal for monitoring vibrations on machines while simultaneously measuring and recording the relevant environmental conditions of the system.

- 3-Axis acceleration up to 800 Hz
- 32 GB SD memory card
- Evaluation software
- Small design: 86.8 x 44.1 x 22.2 mm / 3.4 x 1.7 x 0.87 in
Temperature, Humidity, Air pressure, Vibration, and Light

£ 222.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VDL 24I
For this accelerometer PCE-VDL 24I the acceleration sensor is delivered with a sampling rate of 1600 Hz. The sensor measures the acceleration, which is currently acting on it (3 axes), for example shock / vibration. The measurements take place at predetermined (selectable) time intervals.

- 3-Axis acceleration up to 1600 Hz and ±16 g
- 32 GB SD memory card
- Evaluation software
- Small design: 86.8 x 44.1 x 22.2 mm / 3.4 x 1.7 x 0.87 in
£ 267.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VM 22
The accelerometer has a measuring range of 0 ... 200 m/s² for acceleration. In addition to acceleration, the accelerometer can also perform speed, displacement, frequency and an ISO 18016-3 measurement.

- Acceleration
- Velocity
- Displacement
- Frequency
- Tachometer
- Infrared temperature measurement
- 4 GB data memory
- FFT analysis and wave view of the vibration
£ 2,390.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VM 22-ICA
The accelerometer has a measuring range of 0 ... 200 m/s² for acceleration. In addition to acceleration, the accelerometer can also perform speed, displacement, frequency and an ISO 18016-3 measurement.

- Acceleration
- Velocity
- Displacement
- Frequency
- Tachometer
- Infrared temperature measurement
- 4 GB data memory
- FFT analysis and wave view of the vibration
- incl. ISO Calibration Certificate
£ 2,534.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VDR 10-ICA

PCE-VDR 10-ICA is a single-axis accelerometer or vibration recorder with real-time measurement and data logging capabilities. This accelerometer records acceleration (m/s, g, ft/s) as well as velocity (mm/s, cm/s, in/s) measurements and saves the measured data to an included SD card memory. There is also an analog output, which makes this accelerometer compatible with control systems.

- Acceleration measuring range:
  0.5 ... 199.9 m/s, 0.05 ... 20.39 g, 2 ... 656 ft/s
- Velocity measuring ranges:
  0.5 ... 199.9 mm/s, 0.05 ... 19.99 cm/s, 0.02 ... 7.87 in/s
- Frequency range: 10 ... 1000 Hz
- Analog output: 4 ... 20 mA
- RS-232 and USB interface
- incl. ISO Calibration Certificate

£ 769.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VD 3-ICA

PCE-VD 3-ICA is a Accelerometer that measures 3-axis shock/vibration via a built-in accelerometer sensor. This Accelerometer records 3-axis acceleration (X, Y, Z) vibration measurement data for Fast Fourier Transform (FFT) waveform analysis. The Accelerometer connects to your PC via a USB port for configuration and for quick and easy data transfer.


- Measuring range: ±16 g per axis
- Frequency range: 0 ... 60 Hz
- Recording interval: Adjustable from 1 sec .... 24 hr
- Logs and stores up to 168,042 records
- Includes magnetic bracket with wall-mounting screws
- incl. ISO Calibration Certificate

£ 293.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VD 3

The PCE-VD 3 Accelerometer is a miniaturized universal Accelerometer with an included built-in three-axes acceleration sensor (X, Y, Z axis). The internal sensor of the PCE-VD 3 Accelerometer measures acceleration force along the X, Y, and Z axes with a measurement range of ±16 g per axis. This device is specially made for use on industrial machinery.


- 3-axis vibration data logging instrument
- Software included / USB port
- Light weight
- Stand included
- Storage capacity: 8 Mbit (168042 records)
- Magnetic wall mount



£ 139.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VT 1100M

The accelerometer is used as a hand-held measuring device for the individual assessment of vibrations on machines and systems. With the help of this accelerometer, the actual state can easily be determined on site. Thus, corresponding changes can be made directly on site after the measurement.

- Frequency range: 10 Hz ... 1 kHz
- Measures speed, distance, acceleration in metric units only
- Holds the reading after each measurement
- Easy to handle and battery operated
- Standard probe: 10 mm
- including magnetic sensor

£ 276.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VDR 10

PCE-VDR 10 is a single-axis accelerometer or vibration monitor with real-time measurement and data logging capabilities. This vibration analyzer records acceleration (m/s, g, ft/s) as well as speed (mm/s, cm/s, in/s) measurements and saves the measured data to an included SD card memory.


- Acceleration measuring range:
  0.5 ... 199.9 m/s, 0.05 ... 20.39 g, 2 ... 656 ft/s
- Speed measuring range:
  0.5 ... 199.9 mm/s, 0.05 ... 19.99 cm/s, 0.02 ... 7.87 in/s
- Frequency range: 10 ... 1000 Hz
- Analog output: 4 ... 20 mA
- RS-232 and USB interface



£ 610.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VT 204

The PCE-VT 204 is a multifunction handheld accelerometer device with the ability to accurately measure both rotation and vibration. An ideal tool for the testing and inspection of machine parts and components such as motors, transmissions, gears, gear boxes and wheels, this multi-purpose instrument measures revolutions per minute (RPMs) as well as three-axis vibration, i.e., speed or velocity, displacement and acceleration.


- Vibration measurement: Velocity or speed, acceleration and displacement
- RPM measurement: Contact / mechanical and noncontact / optical
- Internal memory for up to 1000 readings
- Min / max and data hold functions
- RS-232 port



£ 645.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VT 204-ICA

The PCE-VT 204 is a multifunction handheld accelerometer device with the ability to accurately measure both rotation and vibration. An ideal tool for the testing and inspection of machine parts and components such as motors, transmissions, gears, gear boxes and wheels, this multi-purpose instrument measures revolutions per minute (RPMs) as well as three-axis vibration, i.e., speed or velocity, displacement and acceleration.


- Vibration measurement: Velocity or speed, acceleration and displacement
- RPM measurement: Contact / mechanical and noncontact / optical
- Internal memory for up to 1000 readings
- Min / max and data hold functions
- RS-232 port
- incl. ISO Calibration Certificate



£ 645.00

Price excl. VAT &. delivery
2 year Warranty
