Wind Measurer

The wind measurer measures the flow velocity according to the hot wire principle. This guarantees a particularly compact design. In addition to the flow rate, the wind measurer can measure the volume flow and the ambient temperature.

- Measuring range: 0.3 ... 30.0 m/s / 0.98 ... 98.4 ft/s
- Probe length: 270 … 990 mm / 10.63 … 38.98 / 29.1"
- Probe diameter: Ø0.8 ... 1.2 mm / 0.031 x 0.047"
- Data memory for 960 measured values
- Wind speed
- Volume flow
- Temperature measurement

The wind measurer measures the flow velocity according to the hot wire principle. This guarantees a particularly compact design. In addition to the flow rate, the wind measurer can measure the volume flow and the ambient temperature.

- Measuring range: 0.3 ... 30.0 m/s / 0.98 ... 98.4 ft/s
- Probe length: 270 … 990 mm / 10.63 … 38.98 / 29.1"
- Probe diameter: Ø0.8 ... 1.2 mm / 0.031 x 0.047"
- Data memory for 960 measured values
- Wind speed
- Volume flow
- Temperature measurement
- incl. ISO Calibration Certificate (wind speed function only)

This wind measurer station with outside sensor is a real all-rounder. The wireless wind measurer station with outside sensor is easy to assemble based on the instructions provided. You do not have to be a professional to operate the wireless wind measurer station and outside sensors. The weather data of the wind measurer station with outside sensor for different parameters are sent up to 100 meters by radio signal to the main station.

- 3 displays
- Indoor temperature in Celsius or Fahrenheit
- Outside temperature in Celsius or Fahrenheit
- Indoor air humidity / outdoor air humidity
- Air pressure gauge in inHg or hPa
- Absolute or relative air pressure display selectable
- Precipitation indication in mm or inch
- Precipitation indicator for 1 hour, 24 hours, 1 week, 1 month
- Wind speed in mph, km/h, m/s, knots ...
- Wind direction indicator
- Wind chill temperature gauge
- Weather forecast, trend indicator, storm warning
- and much more...

This airwheel wind measurer is very economical. With this airwheel wind measurer you can measure wind speed and air temperature.

- Speed measurement up to 45 m/s or 100 mph
- Wind speed: 0.01 m/s, accuracy ±3% ±0.1
- Air temperature: 0.2°C / 32.4°F, accuracy ±1°C / 33.8°F
- Air flow: 0.001 to 100, accuracy calculated from the wind speed and surface
- Incl. ISO calibration certificate

The Wind Measurer PCE-VA 11 is an extensively used measuring instrument. This wind measurer offers the opportunity to determine air speeds, air temperature and infrared temperature. The illuminated LCD allows comfortable readings and facilitates use in dimly lit areas.

- Air speed range: 0.4 ... 30 m/s / 0.9 ... 67 mph
- Air flow range: 0 ... 9999 CFM / CMM
- Air temperature range: -10 ... 60°C / 14 ... 140°F
- IR temperature range: -50 ... 500°C / -58 ... 932°F

PCE-VA 20 is a multifunction wind measurer for assessing wind, weather, indoor / outdoor environmental climate conditions as well as for testing heating, ventilation and air conditioning or cooling (HVAC) systems. This combination anemometer-hygrometer-thermometer features a 10 cm / 3.9" Ø fan impeller, easy-to-read backlit LCD, and functions such as display hold, average value, maximum value, minimum value, battery-saving automatic power off, low-battery indicator, and metric or imperial unit selection.

- Measures air flow velocity, volume flow, relative humidity, air temperature, dew
  point temperature and wet-bulb temperature
- Air flow velocity range: 0.2 ... 30 m/s (39.4 ... 5905.5 fpm)
- Accuracy: ±(1.5% of measured value + 0.3 m/s) when less than 20 m/s, ±(3% of
  measured value + 0.3 m/s) when more than 20 m/s
- Resolution: 0.1



PCE-HVAC 2 is a high-velocity multifunction wind measurer or anemometer with a pitot tube. This portable wind measurer can be used to determine air speed, air pressure, air flow, differential pressure and ambient temperature. The pitot tube allows access through tiny openings to take measurements in small pipe systems and other confined spaces.-

- Measures air velocities up to 80 m/s / 262 ft/s, 2.24 ... 178.66 MPH
- Zero, minimum, maximum, average, record and hold functions
- Stores to memory up to 99 measurement values per parameter

The Wind Measurer PCE-VA 11 is a useful and versatile device for measuring air speeds, air temperature and infrared temperature. Thanks to the fast response time of the device, real-time measurement is possible without problems. The large display provides an accurate overview of the measured values.

- Air speed range: 0.4 ... 30 m/s / 0.9 ... 67 mph
- Air flow range: 0 ... 9999 CFM / CMM
- Air temperature range: -10 ... 60°C / 14 ... 140°F
- IR temperature range: -50 ... 500°C / -58 ... 932°F
- USB interface
- Incl. ISO Calibration Certificate



The PCE-VA 20 is a versatile multifunction wind measurer for determining environmental conditions such as wind, temperature and humidity. It is additionally used to test heating, ventilation and air conditioning / cooling (HVAC) systems. This triple thermometer-hygrometer-anemometer device has a 10 cm / 3.9" Ø fan impeller and a clear backlit LCD. Available functions include display hold, average / maximum / minimum value, auto shutdown, low-battery warning, and metric / imperial choice.

- Measures air flow velocity, volume flow, relative humidity, air temperature, dew
  point temperature and wet-bulb temperature
- Air flow velocity range: 0.2 ... 30 m/s (39.4 ... 5905.5 fpm)
- Accuracy: ±(1.5% of measured value + 0.3 m/s) when less than 20 m/s, ±
  (3% of measured value + 0.3 m/s) when more than 20 m/s
- Resolution: 0.1
- incl. ISO Calibration Certificate

The PCE-HVAC 2 is a multifunction wind measurer with a pitot tube that measures air velocities up to 80 m/s. It is possible to measure air speed, air pressure, air flow, differential pressure and ambient temperature with this mobile wind measurer. Readings can be taken in narrow pipes and other restricted spaces because the pitot tube can be inserted in very small gaps.-

- Measures air velocities up to 80 m/s / 262 ft/s, 2.24 ... 178.66 MPH
- Zero, minimum, maximum, average, record and hold functions
- Stores to memory up to 99 measurement values per parameter
- Includes ISO calibration certificate

The PCE-VA 20-SET is a multi-functional wind measurer including flow hoods for assessing and balancing heating, ventilation and air conditioning or cooling (HVAC) installations. This multi-faceted anemometer-thermometer-hygrometer incorporates a 10 cm / 3.9" diam. fan impeller, easy-to-view backlit LCD, and useful functions, e.g. display hold, average val, maximum val, minimum val, auto power-off, low battery indication, and imperial/metric option.

- Measures air flow velocity, volume flow, relative humidity, air temperature, dew
  point temperature and wet-bulb temperature
- Air flow velocity range: 0.2 ... 30 m/s (39.4 ... 5905.5 fpm)
- Accuracy: ±(1.5% of measured value + 0.3 m/s) when less than 20 m/s, ±(3% of
  measured value + 0.3 m/s) when more than 20 m/s
- Resolution: 0.1°C / 0.18°F
- Includes 2 x capture hoods (1 x round 210 mm / 8.3 in Ø, 1 x square 346 x 346
  mm / 13.6 x 13.6 in)
- incl. ISO Calibration Certificate

PCE-MAM 2 is a lightweight portable handheld pocket-sized mini anemometer, wind speed meter or air velocity measuring device with an impeller wheel sensor that is ideal for determining air or wind speeds inside or out. This mini anemometer allows you to take velocity and temperature measurements quickly and on the spot.

- Velocity measuring range: 0.4 ... 30 m/s (0.9 ... 67 mph)
- Temperature measuring range: -20 ... 70°C / -4 ... 158°F
- Displays velocity measurements in m/s, km/h, mph, knots or ft/min
- Impeller wheel sensor for air or wind speed
- Colour display

This wind measurer station with outside sensor is a real all-rounder. The wireless wind measurer station with outside sensor is easy to assemble based on the instructions provided. You do not have to be a professional to operate the wireless wind measurer station and outside sensors. The weather data of the wind measurer station with outside sensor for different parameters are sent up to 100 meters by radio signal to the main station.

- Indoor temperature in Celsius or Fahrenheit
- Outside temperature in Celsius or Fahrenheit
- Indoor air humidity / outdoor air humidity
- Air pressure gauge in inHg or hPa
- Absolute or relative air pressure display selectable
- Precipitation indication in mm or inch
- Precipitation indicator for 1 hour, 24 hours, 1 week, 1 month
- Wind speed in mph, km / h, m / s, knots ...
- Wind direction indicator
- Wind chill temperature gauge
- Weather forecast, trend indicator, storm warning
- and much more...

The Wind Measurer is compatible with and can be mounted on to a wide variety of available measuring equipment. The sensor will detect even the minutest movements of air and the results are then output in analogue form.

- Output signal: 0 … 10V
- Operating voltage: 12 … 36V DC
- Measurement reading range: 0.5 m/s … 50 m/s (1.1 ... 111.8 mph)

- Measuring range: 1.2 ... 30.0 m (3.9 ... 98.4 ft) / sec.
- Resolution: 0.01 m (0.03 ft) / s
- Measurement accuracy m / s: ± (3% + 0.20 m (0.7 ft) / s)
- Units selectable: km / h, knots, miles / h, ft / min
- Memory: for up to 60000 readings
- PC software

The wind measurer has a measuring range of up to 0 ... 30 m/s. In addition to the velocity, the wind measurer can precisely measure the volume flow and temperature. The compact design of the sensors, in combination with the extendable telescopic probe, enable measurements to be taken even in places that are particularly difficult to access.

- Speed: 0.00 ... 30.00 m/s / 0.00 ... 98.42 ft/s
- Volume flow: 0.0 ... 339120.0 m3/h
- Temperature: 0 ... 50 °C / 32 ... 122 °F
- Telescopic probe length: 210 ... 426 mm / 8.2 ... 16.7"
- Telescopic probe diameter: 12 mm / 0.47"
