PCE Instruments

Vibration Meter / Vibration Tester

Order no.: PCE-VDL 16I
The vibration meter PCE-VDL 16I from PCE Instruments measures and stores the relevant measured variables: temperature, relative humidity, air pressure, light as well as acceleration in three axes by means of a vibration sensor. Therefore, this vibration meter is ideal for monitoring vibrations on machines while simultaneously measuring and recording the relevant environmental conditions of the system.

- 3-Axis acceleration up to 800 Hz
- 32 GB SD memory card
- Evaluation software
- Small design: 86.8 x 44.1 x 22.2 mm / 3.4 x 1.7 x 0.87 in
Temperature, Humidity, Air pressure, Vibration, and Light

£ 222.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VDL 24I
For this vibration meter PCE-VDL 24I the acceleration sensor is delivered with a sampling rate of 1600 Hz. The sensor measures the acceleration, which is currently acting on it (3 axes), for example shock / vibration. The measurements take place at predetermined (selectable) time intervals.

- 3-Axis acceleration up to 1600 Hz and ±16 g
- 32 GB SD memory card
- Evaluation software
- Small design: 86.8 x 44.1 x 22.2 mm / 3.4 x 1.7 x 0.87 in
£ 267.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VD 3

The PCE-VD 3 Vibration Meter is a miniaturized universal Vibration Meter with an included built-in three-axes acceleration sensor (X, Y, Z axis). The internal sensor of the PCE-VD 3 Vibration Meter measures acceleration force along the X, Y, and Z axes with a measurement range of ±16 g per axis. This device is specially made for the use at industrial machinery.


- 3-axis vibration data logging instrument
- Software included / USB port
- Light weight
- Stand included
- Storage capacity: 8 Mbit (168042 records)
- Magnetic wall mount



£ 139.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VDR 10

PCE-VDR 10 is a single-axis vibration meter or monitor with real-time measurement and data logging capabilities. This vibration analyzer records acceleration (m/s, g, ft/s) as well as speed (mm/s, cm/s, in/s) measurements and saves the measured data to an included SD card memory.


- Acceleration measuring range:
  0.5 ... 199.9 m/s, 0.05 ... 20.39 g, 2 ... 656 ft/s
- Speed measuring range:
  0.5 ... 199.9 mm/s, 0.05 ... 19.99 cm/s, 0.02 ... 7.87 in/s
- Frequency range: 10 ... 1000 Hz
- Analog output: 4 ... 20 mA
- RS-232 and USB interface



£ 610.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VM 22
The vibration meter has a measuring range of 0 ... 200 m/s² for acceleration. In addition to acceleration, the vibration meter can also perform speed, displacement, frequency and an ISO 18016-3 measurement.

- Acceleration
- Velocity
- Displacement
- Frequency
- Tachometer
- Infrared temperature measurement
- 4 GB data memory
- FFT analysis and wave view of the vibration
£ 2,390.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VT 1100

The vibration meter is used as a hand-held measuring device for the individual assessment of vibrations on machines and systems. With the help of this vibration meter, the actual state can easily be determined on site. Thus, corresponding changes can be made directly on site after the measurement.

- Frequency range: 10 Hz ... 1 kHz
- Measures speed, distance, acceleration in metric units only
- Holds the reading after each measurement
- Easy to handle and battery operated
- Standard probe: 10 mm

£ 254.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VT 1100M

The vibration meter is used as a hand-held measuring device for the individual assessment of vibrations on machines and systems. With the help of this vibration meter, the actual state can easily be determined on site. Thus, corresponding changes can be made directly on site after the measurement.

- Frequency range: 10 Hz ... 1 kHz
- Measures speed, distance, acceleration in metric units only
- Holds the reading after each measurement
- Easy to handle and battery operated
- Standard probe: 10 mm
- including magnetic sensor

£ 276.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VT 1100S

The vibration meter is suitable for relative measurements on various machines. With the 45 mm long needle probe, you can access hard-to-reach places in machines and motors. For this reason, this vibration meter is used for rapid measurement of imbalance and for checking bearing and gear conditions.


- Frequency range: 10 Hz ... 1 kHz
- Measures speed, distance, acceleration
- Holds the reading after each measurement in metric units
- Portable and battery operated
- Needle probe: 45 mm / 1.77 in

£ 254.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VT 3700
The vibration meter is ideal for maintenance workers to quickly check vibrating parts, machines and systems. This vibration meter shows the vibration acceleration, vibration velocity and vibration displacement directly on the display. The measurement unit can be switched between the metric system and imperial units.

Measuring ranges
- Acceleration: 0.0 - 399.9 m/s² / 0.0 - 15744 in/s²
- Velocity: 0.00 - 399.99 mm/s / 0.00 - 15.74 in/s
- Displacement: 0.000 - 3.9 mm / 0.000 - 0.154 in
- Automatic ISO 10816-3 evaluation
- Colored graphic display
£ 685.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VT 3700S
The vibration meter is ideal for maintenance workers to quickly check vibrating parts, machines and systems. This vibration meter shows the vibration acceleration, vibration velocity and vibration displacement directly on the display. The measurement unit can be switched between the metric system and imperial units.

Measuring ranges
- Acceleration: 0.0 - 399.9 m/s² / 0.0 - 15744 in/s²
- Velocity: 0.00 - 399.99 mm/s / 0.00 - 15.74 in/s
- Displacement: 0.000 - 3.9 mm / 0.000 - 0.154 in
- Automatic ISO 10816-3 evaluation
- Colored graphic display
£ 788.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VT 3750
The vibration meter is ideal for maintenance workers to quickly check vibrating parts, machines and systems. This vibration meter shows the vibration acceleration, vibration velocity and vibration displacement directly on the display. The measurement unit can be switched between the metric system and imperial units.

Measuring ranges
- Acceleration: 0.0 - 399.9 m/s² / 0.0 - 15744 in/s²
- Velocity: 0.00 - 399.99 mm/s / 0.00 - 15.74 in/s
- Displacement: 0.000 - 3.9 mm / 0.000 - 0.154 in
- Automatic ISO 10816-3 evaluation
- Colored graphic display
- incl. headset
£ 882.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VT 3800
The vibration meter is the ideal companion for checking vibrating parts, machines and systems. With the external vibration sensor on the vibration meter, the vibration displacement up to 3.9 mm, the vibration velocity up to 399.9 mm/s and the vibration acceleration up to 399.9 m/s² can be determined.

Measuring ranges
- Acceleration: 0.0 ... 399.9 m/s² / 0.0 - 15744 in/s²
- Velocity: 0.00 ... 399.9 mm/s / 0.00 - 15.74 in/s
- Displacement: 0.000 ... 3.9 mm / 0.000 - 0.154 in
- Automatic ISO 10816-3 evaluation
- Data logger: 50 memory locations with 43200 measured values each
- Rechargeable battery
- Color graphic display
£ 788.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VT 3800S
The vibration meter is the ideal companion for checking vibrating parts, machines and systems. With the external vibration sensor on the vibration meter, the vibration displacement up to 3.9 mm, the vibration velocity up to 399.9 mm/s and the vibration acceleration up to 399.9 m/s² can be determined.

Measuring ranges
- Acceleration: 0.0 ... 399.9 m/s² / 0.0 - 15744 in/s²
- Velocity: 0.00 ... 399.9 mm/s / 0.00 - 15.74 in/s
- Displacement: 0.000 ... 3.9 mm / 0.000 - 0.154 in
- Automatic ISO 10816-3 evaluation
- Data logger: 50 memory locations with 43200 measured values each
- Rechargeable battery
- Color graphic display
- Measuring tip with handgrip
£ 877.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VT 3850
The vibration meter is the ideal companion for checking vibrating parts, machines and systems. With the external vibration sensor on the vibration meter, the vibration displacement up to 3.9 mm, the vibration velocity up to 399.9 mm/s and the vibration acceleration up to 399.9 m/s² can be determined.

Measuring ranges
- Acceleration: 0.0 ... 399.9 m/s² / 0.0 - 15744 in/s²
- Velocity: 0.00 ... 399.9 mm/s / 0.00 - 15.74 in/s
- Displacement: 0.000 ... 3.9 mm / 0.000 - 0.154 in
- Automatic ISO 10816-3 evaluation
Data logger: 50 memory locations with 43200 measured values each
Rechargeable battery
- Color graphic display
- incl. headset
£ 931.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VT 3850S
The vibration meter is the ideal companion for checking vibrating parts, machines and systems. With the external vibration sensor on the vibration meter, the vibration displacement up to 3.9 mm, the vibration velocity up to 399.9 mm/s and the vibration acceleration up to 399.9 m/s² can be determined.

Measuring ranges
- Acceleration: 0.0 ... 399.9 m/s² / 0.0 - 15744 in/s²
- Velocity: 0.00 ... 399.9 mm/s / 0.00 - 15.74 in/s
- Displacement: 0.000 ... 3.9 mm / 0.000 - 0.154 in
- Automatic ISO 10816-3 evaluation
Data logger: 50 memory locations with 43200 measured values each
Rechargeable battery
- Color graphic display
Measuring tip with handgrip
- incl. headset
£ 1,011.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VT 3900
The vibration meter is an ideal measuring device for fast and precise checking of vibrating parts, machines and systems. Various measurement parameters are available for the vibration meter, such as RMS, peak, peak-peak and crest factor.

Measuring ranges
- Acceleration: 0.0 ... 399.9 m/s² / 0.0 - 15744 in/s²
- Velocity: 0.00 ... 399.9 mm/s / 0.00 - 15.74 in/s
- Displacement: 0.000 ... 3.9 mm / 0.000 - 0.154 in
- Automatic ISO 10816-3 evaluation
- Data logger: 50 memory locations with 43200 measured values each
- FFT analysis
- Route measurement
- Rechargeable battery
- Color graphic display
£ 1,153.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VD 3-ICA

PCE-VD 3-ICA is a vibration meter that measures 3-axis shock/vibration via a built-in accelerometer sensor. This vibration meter records 3-axis acceleration (X, Y, Z) vibration measurement data for Fast Fourier Transform (FFT) waveform analysis. The vibration meter connects to your PC via a USB port for configuration and for quick and easy data transfer.


- Measuring range: ±16 g per axis
- Frequency range: 0 ... 60 Hz
- Recording interval: Adjustable from 1 sec .... 24 hr
- Logs and stores up to 168,042 records
- Includes magnetic bracket with wall-mounting screws
- incl. ISO Calibration Certificate

£ 293.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VT 3900S
The vibration meter is an ideal measuring device for fast and precise checking of vibrating parts, machines and systems. Various measurement parameters are available for the vibration meter, such as RMS, peak, peak-peak and crest factor.

Measuring ranges
- Acceleration: 0.0 ... 399.9 m/s² / 0.0 - 15744 in/s²
- Velocity: 0.00 ... 399.9 mm/s / 0.00 - 15.74 in/s
- Displacement: 0.000 ... 3.9 mm / 0.000 - 0.154 in
- Automatic ISO 10816-3 evaluation
- Data logger: 50 memory locations with 43200 measured values each
- FFT analysis
- Route measurement
- Measuring tip with handgrip
- Rechargeable battery
- Color graphic display
£ 1,233.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VDR 10-ICA

PCE-VDR 10-ICA is a single-axis accelerometer or vibration meter with real-time measurement and data logging capabilities. This vibration meter records acceleration (m/s, g, ft/s) as well as velocity (mm/s, cm/s, in/s) measurements and saves the measured data to an included SD card memory. There is also an analog output, which makes this vibration meter compatible with control systems.

- Acceleration measuring range:
  0.5 ... 199.9 m/s, 0.05 ... 20.39 g, 2 ... 656 ft/s
- Velocity measuring ranges:
  0.5 ... 199.9 mm/s, 0.05 ... 19.99 cm/s, 0.02 ... 7.87 in/s
- Frequency range: 10 ... 1000 Hz
- Analog output: 4 ... 20 mA
- RS-232 and USB interface
- incl. ISO Calibration Certificate

£ 769.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-VT 3950
The vibration meter is an ideal measuring device for fast and precise checking of vibrating parts, machines and systems. Various measurement parameters are available for the vibration meter, such as RMS, peak, peak-peak and crest factor.

Measuring ranges
- Acceleration: 0.0 ... 399.9 m/s² / 0.0 - 15744 in/s²
- Velocity: 0.00 ... 399.9 mm/s / 0.00 - 15.74 in/s
- Displacement: 0.000 ... 3.9 mm / 0.000 - 0.154 in
- Automatic ISO 10816-3 evaluation
- Data logger: 50 memory locations with 43200 measured values each
- FFT analysis
- Route measurement
- Rechargeable battery
- Color graphic display
- incl. headset
£ 1,349.00

Price excl. VAT &. delivery
2 year Warranty
