PCE Instruments

Thermal Imager

Order no.: PCE-TC 28

The Thermal Imager PCE-TC 28 was designed for taking non-contact temperature measurements. To get accurate readings, the emissivity of the thermal imager can be adjusted, depending on the operation purpose. Besides taking infrared images, the thermal imager can also take normal pictures, as well as a mixture of both, due to the built-in digital camera.


- Measurement range: -20 ... +600°C / -4 ... 1112°F
- Accuracy: ±2%, ±2°C / 3.6°F
- Frequency image recording: 9 Hz
- Camera: 32 x 31 Pixel



£ 543.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-TC 28-ICA

The Thermal Imager PCE-TC 28 was designed for taking non-contact temperature measurements. To get accurate readings, the emissivity of the thermal imager can be adjusted, depending on the operation purpose. Besides taking infrared images, the thermal imager can also take normal pictures, as well as a mixture of both, due to the built-in digital camera.


- Measurement range: -20 ... +600°C / -4 ... 1112°F
- Accuracy: ±2%, ±2°C / 3.6°F
- Frequency image recording: 9 Hz
- Camera: 32 x 31 Pixel
- incl. ISO Calibration Certificate

£ 752.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-TC 30N
The PCE-TC 30N thermal imager for preventive maintenance is the ideal tool for maintenance and servicing. This thermal imager is a must-have for electricians, fitters or general maintenance personnel for troubleshooting and fault prevention of electrical equipment, electromechanical devices, production process machinery, heating, ventilation and air conditioning systems, especially when working in harsh environments.

- IR resolution: 160 x 120 pixels
- Measuring range: -20 ... 450°C / -4  ... 842°F
- Thermal sensitivity: 70 mK
- Memory: 3 GB memory for more than 20,000 pictures
- 5 different color palettes
- Hot and cold spot location
- Picture in Picture function
£ 601.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-TC 30N-ICA
The PCE-TC 30N thermal imager for preventive maintenance is the ideal tool for maintenance and servicing. This thermal imager is a must-have for electricians, fitters or general maintenance personnel for troubleshooting and fault prevention of electrical equipment, electromechanical devices, production process machinery, heating, ventilation and air conditioning systems, especially when working in harsh environments.

- IR resolution: 160 x 120 pixels
- Measuring range: -20 ... 450°C / -4  ... 842°F
- Thermal sensitivity: 70 mK
- Memory: 3 GB memory for more than 20,000 pictures
- 5 different color palettes
- Hot and cold spot location
- Picture in Picture function
- incl. ISO Calibration Certificate
£ 809.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-TC 33N
In preventative maintenance, the high-resolution PCE-TC 33N thermal imager is ideal for maintaining or repairing machinery or other equipment. The heart of the high-resolution thermal imager PCE-TC 33N is an uncooled microbolometer (uncooled focal plane array) with a resolution of 220 x 160 pixels.

- IR resolution: 220 x 160 pixels
- Measuring range: -20 ... 300°C / -4  ... 572°F
- Thermal sensitivity: 70 mK
- Memory: 3 GB memory for more than 20,000 pictures
- 5 different color palettes
- Hot and cold spot location
- Picture in Picture function
£ 618.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-TC 33N-ICA
In preventative maintenance, the high-resolution PCE-TC 33N thermal imager is ideal for maintaining or repairing machinery or other equipment. The heart of the high-resolution thermal imager PCE-TC 33N is an uncooled microbolometer (uncooled focal plane array) with a resolution of 220 x 160 pixels.

- IR resolution: 220 x 160 pixels
- Measuring range: -20 ... 300°C / -4  ... 572°F
- Thermal sensitivity: 70 mK
- Memory: 3 GB memory for more than 20,000 pictures
- 5 different color palettes
- Hot and cold spot location
- Picture in Picture function
- incl. ISO Calibration Certificate
£ 827.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-TC 32N
The thermographic camera has a measuring range of -20 ... +550 °C. This means that the thermographic camera already covers a wide temperature range of measuring tasks. With an image frequency of 25 Hz, problems can be quickly localised with the thermographic camera.

- Measuring range: -20 ... +550 °C
- Picture-in-picture function
- Frame rate: 25 Hz
- Internal/external memory
Wi-Fi 802.11
- Display resolution: 240 x 320 pixels
- Battery
£ 774.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-TC 32N-ICA
The thermographic camera has a measuring range of -20 ... +550 °C. This means that the thermographic camera already covers a wide temperature range of measuring tasks. With an image frequency of 25 Hz, problems can be quickly localised with the thermographic camera.

- Measuring range: -20 ... +550 °C
- Picture-in-picture function
- Frame rate: 25 Hz
- Internal/external memory
Wi-Fi 802.11
- Display resolution: 240 x 320 pixels
- Battery
- incl. ISO Calibration Certificate
£ 978.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-TC 34N
The thermal imager has a resolution of 320 x 240 pixels. With a measuring range of -20 ... 300 °C, the thermal imager already covers a large temperature range. The emission value of the thermal imager can be set to carry out measurements on different surfaces.

- Measuring range: -20 ... 300 °C / -4 ... 572 °F
- Infrared and real image resolution: 320 x 240 pixels
- Picture in picture function
- USB-C interface
- Refresh rate: 9Hz
- Storage for about 20,000 images
£ 876.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-TC 34N-ICA
The thermal imager has a resolution of 320 x 240 pixels. With a measuring range of -20 ... 300 °C, the thermal imager already covers a large temperature range. The emission value of the thermal imager can be set to carry out measurements on different surfaces.

- Measuring range: -20 ... 300 °C / -4 ... 572 °F
- Infrared and real image resolution: 320 x 240 pixels
- Picture in picture function
- USB-C interface
- Refresh rate: 9Hz
- Storage for about 20,000 images
- incl. ISO Calibration Certificate
£ 1,085.00

Price excl. VAT &. delivery
2 year Warranty
