Car Measuring Device

- Measuring range: 0 ... 1250 μm / 0 ...  49.2 mils
- Resolution: 1 μm / 0.039 mils
- Accuracy: ± (3% + 2 μm / 0.079 mils)
- Wear-resistant sensor
- V-groove for measurement on pipes

- Measuring range: 0 ... 1250 μm / 0 ...  49.2 mils
- Resolution: 1 μm / 0.039 mils
- Accuracy: ± (3% + 2 μm / 0.079 mils)
- Wear-resistant sensor
- V-groove for measurement on pipes
- Incl. ISO calibration certificate

- Current measurement up to 1000 A
- Cover of the measuring sockets
- Voltage measurement up to 600V
- Temperature measurement via 2 thermocouples
- Incl. ISO Calibration Certificate

With this car measuring device, weld seams, wear and tear and damage can be assessed quickly and easily in order to make quick diagnoses. The sheathing of the endoscope cable from the car measuring device consists of braided tungsten.

- Endoscope cable length: approx. 2 m / 6.5 ft
- Diameter: 3.8mm / 0.15"
- Front camera with resolution: 1,000,000 pixels
- Front camera viewing angle 120°
- Focus 10 … 100 mm / 0.39 … 3.9"
- Movable camera head 46 mm / 1.8" long
- Bending radius approx. 35 mm / 1.3" at 90°
- 7" touch screen for easy operation
- replaceable battery with status display
- Storage of recording on SD card
- Motor with endoscope cable can be changed quickly
- HDMI connection for direct image transmission

With this car measuring device, weld seams, wear and tear and damage can be assessed quickly and easily in order to make quick diagnoses. The sheathing of the endoscope cable from the car measuring device consists of braided tungsten.

- Diameter: Ø2.8mm / 0.11"
- Cable length: 2m / 6.5 ft
- Camera direction: 0°
- Resolution: 160,000 pixels
- Focusing range: 5 ... 50 mm / 0.19 ... 1.96"
- 7" touch screen for easy operation
- Replaceable battery with status display
- Storage of recording on SD card
- Motor with endoscope cable can be changed quickly
- HDMI connection for direct image transmission

- Current measurement up to 1000 A
- Cover of the measuring sockets
- Voltage measurement up to 600V
- Temperature measurement via 2 thermocouples

PCE-DRA 1 is an antifreeze car measuring device used to determine the percentage or content and freezing point of propylene glycol- and ethylene glycol-based solutions. This waterproof IP65-rated car measuring device features automatic temperature compensation (ATC) from +10 ... +40 °C / +50 ... +104 °F, as well as a large, easy-to-read LCD that shows both the measured value and the temperature.

Measurement parameters:
- Ethylene glycol %, propylene glycol %, temperature °C
- Measuring range: 0 ... 60 % ethylene glycol
- Resolution: 0.1 % / 0.1 °
- Accuracy: ±0.5 % / ±0.5 °C
- Automatic temperature compensation (ATC)
- Easy calibration with distilled water

PCE-CT 65 is a car measuring device that uses magnetic induction (ferrous) or eddy current (non-ferrous) to take non-destructive measurements of coating and dry film thickness (DFT) on metal substrates such as steel and aluminum. This car measuring device is ideal for painted and powder-coated surface testing, automotive paint inspection, coated material testing, and manufacturing quality control applications.

- Measuring range of 0 ... 1350 µm / 0 ... 53 mils
- Accuracy of ±2.5 % ±2 µm for 0 ... 1000 µm / ±3.5 % for 1000 µm ... 1350 µm / ±2 % ±0.08 mils for 0 ... 39.3 mils / ±3.5 % for 39.3 mils ... 53.1 mils
- Saves up to 1500 measurements to memory

PCE-CT 65 is a car measuring device that uses magnetic induction (ferrous) or eddy current (non-ferrous) to take non-destructive measurements of coating and dry film thickness (DFT) on metal substrates such as steel and aluminum. This car measuring device is ideal for painted and powder-coated surface testing, automotive paint inspection, coated material testing, and manufacturing quality control applications.

- Measuring range of 0 ... 1350 µm / 0 ... 53 mils
- Accuracy of ±2.5 % ±2 µm for 0 ... 1000 µm / ±3.5 % for 1000 µm ... 1350 µm / ±2 % ±0.08 mils for 0 ... 39.3 mils / ±3.5 % for 39.3 mils ... 53.1 mils
- Saves up to 1500 measurements to memory
- Incl. ISO Calibration Certificate

PCE-CT 5000H is a car measuring device used for the rapid determination of coating thicknesses on ferrous (Type F) and non-ferrous (Type N) metals. The car measuring device automatically detects the type of metal to be measured.

- Type F measuring range: 0 ... 5000 µm / 0 ... 5 mm / 0 ... 196 mils
- Type N measuring range: 0 ... 3000 µm / 0 ... 3 mm / 0 ... 118 mils
- Displays measuring units in μm, mm or mils
- Saves up to 2000 measurements to internal memory
- Practical V-groove on the measuring head

PCE-CT 5000H is a car measuring device used for the rapid determination of coating thicknesses on ferrous (Type F) and non-ferrous (Type N) metals. The car measuring device automatically detects the type of metal to be measured.

- Type F measuring range: 0 ... 5000 µm / 0 ... 5 mm / 0 ... 196 mils
- Type N measuring range: 0 ... 3000 µm / 0 ... 3 mm / 0 ... 118 mils
- Displays measuring units in μm, mm or mils
- Saves up to 2000 measurements to internal memory
- Practical V-groove on the measuring head
- Incl. ISO Calibration Certificate

The car measuring device for cars is for measuring the thickness of paint and plastic on ferrous or non-ferrous metals without damaging the coating's surface. The car measuring device stands out due to its high range of measurement.

- Measurement range: 0 ... 1250 µm / 49.2 mils
- Resolution: 0.1 µm / 0.004 mils (in a range of 0.0 µm ... 99.9 µm / 3.9
  mils) 1 µm / 0.04 mils (above the range)
- Accuracy: ± 2% or 2.5 µm / 0.1 mils (highest reading is valid)
- Display: LCD with 4 mm x 10 mm (0.2 in x 0.4 in) high digits



The car measuring device for cars is for measuring the thickness of paint and plastic on ferrous or non-ferrous materials without damaging the coating's surface. The car measuring device stands out due to its high range of measurement.

- Measurement range: 0 ... 1250 µm / 49.2 mils
- Resolution: 0.1 µm / 0.004 mils (in a range of 0.0 µm ... 99.9 µm / 3.9 mils)
  1 µm / 0.04 mils (above the range)
- Accuracy: ± 2% or 2.5 µm / 0.1 mils (highest reading is valid)
- Display: LCD with 4 mm x 10 mm (0.2 in x 0.4 in) high digits
- Incl. ISO Calibration Certificate

PCE-CT 27FN is a Car Measuring Device that takes non-destructive measurements of nonmagnetic coating, insulating layer and dry film thickness (DFT) on metal substrates such as steel and aluminum. Ideal for surface testing, automotive paint inspection, material testing and manufacturing quality control applications.

- Measuring range of 0 ... 1250 µm / 0 ... 50 mils
- Accuracy of ± (2% + 2 µm) / ± (2% + 0.1 mils)
- Features a resolution of 0.1 µ / 0.1 mils





The car measuring device with side view camera gives you new, visual insights into the interior of motors and systems. The car measuring device with side view camera is the ideal tool for maintenance and repair in workshops or industrial companies. Optical analysis with a videoscope has never been so easy.

- Cable length:  2000 mm, 6.56 ft
- Cable diameter:  3 mm, 0.11"
- Camera resolution / image sensor: 400 x 400 Px
- Cable type: flexible
- Video output: HDMI
- Side view camera
- LED light

The car measuring device gives you new, visual insights into the interior of motors and systems. The car measuring device is the ideal tool for maintenance and repair in workshops or industrial companies. Optical analysis with a videoscope has never been so easy.

- Cable length:  1000 mm, 3.28 ft
- Cable diameter:  2.1 mm, 0.08"
- 0° viewing angle
- Camera resolution / image sensor: 400 x 400 Px
- Cable type: flexible
- Video output: HDMI
- LED light

With this car measuring device, weld seams, wear and tear and damage can be assessed quickly and easily in order to make quick diagnoses. The sheathing of the endoscope cable from the car measuring device consists of braided tungsten.

- Endoscope cable length: approx. 2 m / 6.5 ft
- Diameter: 3.8mm / 0.15"
- Camera resolution 160,000 pixels each
- Viewing angle front camera 120°, side camera 90°
- Focusing distance 5 … 50 mm / 0.19 ... 1.96" each
- Camera head length: 42 mm / 1.6"
- Bending radius at 90° 35 mm / 1.3"
- Live images from both cameras side by side
- 7" touch screen for easy operation
- Replaceable battery with status display
- Storage of recording on SD card
- Motor with endoscope cable can be changed quickly
- HDMI connection for direct image transmission

PCE-CT 27FN is a Car Measuring Device that takes non-destructive measurements of nonmagnetic coating, insulating layer and dry film thickness (DFT) on metal substrates such as steel and aluminum. Ideal for surface testing, automotive paint inspection, material testing and manufacturing quality control applications.

- Measuring range of 0 ... 1250 µm / 0 ... 50 mils
- Accuracy of ± (2% + 2 µm) / ± (2% + 0.1 mils)
- Features a resolution of 0.1 µ / 0.1 mils
- Incl. ISO Calibration Certificate

The PCE-AT 5 car measuring device - handheld ignition-tachometer is a portable device used to measure revolutions per minute (rpm) in one-cylinder two-stroke and eight-cylinder four-stroke combustion engines with electric ignition starters. The PCE-AT 5 handheld automotive ignition-tachometer features an easy-to-read, backlit digital LCD display and flashlight functionality for low-light applications.

- Measurement range: 100 ... 20000 rpm
- Resolution: 1 rpm
- Accuracy: ± 10 rpm
- Measurement interval: 0.5 seconds
