PCE Instruments

Magnetometer / Magnetic Field Detector

Order no.: PCE-EMF 823

PCE-EMF 823 is a portable handheld single-axis magnetometer or electromagnetic radiation detector for measuring electromagnetic fields (EMFs). This user-friendly EMF meter is ideal for assessing risks associated with exposure to electromagnetic radiation emitted from electric power lines, home appliances and industrial devices.


- EMF measuring ranges: 20 micro Tesla (µT) / 200 µT / 2000 µT and 200 milli-Gauss (mG) / 2000 mG / 20000 mG
- EMF bandwidth: 30 Hz to 300 Hz
- Sampling time: Approx. 1 second

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-G28

PCE-G28 is a portable, handheld magnetometer that detects electromagnetic fields (EMFs) and displays measurement results in milliGauss (mG) or microTesla (µT). This EMF radiation detector comes with an external 3-axis electromagnetic sensor (X, Y, Z direction).


- Measurement range: 0 ... 20000 mG / 0 ... 2000 µT
- Accuracy: ± 4% + 3 digits / ± 5% + 3 digits / ± 10% + 5 digits
- Resolution: 0.1 mG / 0.01 µT

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-MFM 3000

PCE-MFM 3000 is a handheld magnetometer that detects both static (DC) permanent magnet (rare earth) magnetic and dynamic (AC) electromagnetic fields (EMFs) and displays measurement results in gauss (G) or milli Tesla (mT). This portable magnetic field measuring device comes with an external sensor and features an RS-232 port for downloading data to a PC.


- Measurement range: 0 ... 30,000 Gauss DC fields, 0 ... 15,000 Gauss AC 50/60 Hz fields
- Accuracy: ± 5%; + 20 digits (static) / + 10 digits (dynamic)
- Resolution: 0.1 G / 0.01 mT
- Measures both AC (50/60 Hz) and DC magnetic fields, permanent magnets are DC fields
- Single axis Hall sensor (Transverse) with auto temp. compensation
- ISO lab calibration cert available as an optional accessory

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-EMF 40
With the magnetometer PCE-EMF 40, it is possible to measure magnetic fields up to 2000 mG directly. At the same time, the magnetometer shows the strength of the magnetic field numerically using an X, Y and Z axis.

- Measuring ranges: 20.00 ... 200.0 µT / 200.0 ... 2000 mG
- Bandwidth: 50 MHz ... 3.5 GHz
- Units: V / m, mV / m, V / m, µW / cm², µW / m², mW / m², mA / m
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-MFM 3500
The magnetometer is a reliable measuring device for measuring the existing magnetic field. This gauss meter is suitable for measuring both static/permanent magnet (DC) and alternating magnetic (AC) fields.

- Measuring range up to 30,000 G
- DC Milli Tesla, DC Gauss, Transverse Probe
- AC Milli Tesla, AC Gauss, frequency from 40 to 500 Hz
- Temperature sensor
- Switchable AC or DC measurement
- Memory: Manual / Automatic
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-MFM 3000-ICA

PCE-MFM 3000 is a handheld magnetometer that detects both static (DC) permanent magnet (rare earth) magnetic and dynamic (AC) electromagnetic fields (EMFs) and displays measurement results in gauss (G) or milli Tesla (mT). This portable magnetic field measuring device comes with an external sensor and features an RS-232 port for downloading data to a PC.


- Measurement range: 0 ... 30,000 Gauss DC fields, 0 ... 15,000 Gauss AC 50/60 Hz fields
- Accuracy: ± 5%; + 20 digits (static) / + 10 digits (dynamic)
- Resolution: 0.1 G / 0.01 mT
- Measures both AC (50/60 Hz) and DC magnetic fields, permanent magnets are DC fields
- Single axis Hall sensor (Transverse) with auto temp. compensation
- Incl. ISO calibration certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-MFM 3500-ICA
The magnetometer is a reliable measuring device for measuring the existing magnetic field. This magnetometer is suitable for measuring both static/permanent magnet (DC) and alternating magnetic (AC) fields.

- Measuring range up to 30,000 G
- DC Milli Tesla, DC Gauss, Transverse Probe
- AC Milli Tesla, AC Gauss, frequency from 40 to 500 Hz
- Temperature sensor
- Switchable AC or DC measurement
- Memory: Manual / Automatic
- Incl. ISO calibration certificate
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-MFM 2400
With a measuring range of 2,400 mT, the magnetometer covers a wide range of measuring tasks. The magnetometer has an accuracy of 1%. This makes the magnetometer a very precise measuring device.

- Measuring range up to 24,000 G and 2,400 mT
- Measuring direction: transverse
- for measuring static magnetic fields
- Transverse Hall sensor, cable length approx. 3.3 ft., 1 m
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-MFM 2400+
With a measuring range of 2,400 mT, the magnetometer covers a wide range of measuring tasks. The magnetometer has an accuracy of 1%. This makes the magnetometer a very precise measuring device.

- Measuring range up to 24,000 G and 2,400 mT
- Measuring direction: axial
- for measuring static magnetic fields
- Axial Hall sensor, cable length approx. 2 m / 6.6 ft
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-G28-ICA

PCE-G28 is a portable, handheld magnetometer that detects electromagnetic fields (EMFs) and displays measurement results in milliGauss (mG) or microTesla (µT). This EMF radiation detector comes with an external 3-axis electromagnetic sensor (X, Y, Z direction).


- Measurement range: 0 ... 20000 mG / 0 ... 2000 µT
- Accuracy: ± 4% + 3 digits / ± 5% + 3 digits / ± 10% + 5 digits
- Resolution: 0.1 mG / 0.01 µT
- incl. ISO Calibration Certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-MFM 2400+ICA
With a measuring range of 2,400 mT, the magnetometer covers a wide range of measuring tasks. The magnetometer has an accuracy of 1%. This makes the magnetometer a very precise measuring device.

- Measuring range up to 24,000 G and 2,400 mT
- Measuring direction: axial
- For measuring static magnetic fields
- Axial Hall sensor, cable length approx. 2 m / 6.6 ft
- incl. ISO Calibration Certificate
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-MFM 2400-ICA
With a measuring range of 2,400 mT, the magnetometer covers a wide range of measuring tasks. The magnetometer has an accuracy of 1%. This makes the magnetometer a very precise measuring device.

- Measuring range up to 24,000 G and 2,400 mT
- Measuring direction: transverse
- For measuring static magnetic fields
- Transverse Hall sensor, cable length approx. 3.3 ft., 1 m
- incl. ISO Calibration Certificate
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-MFM 4000

The magnetometer PCE-MFM 4000 is used in the laboratory and quality assurance to measure the strength of magnetic fields. The magnetometer is delivered with two different sensors. A magnetic field sensor is available for general measurements in the Gauss and milli-Tesla range, as well as a precision sensor for measurements in the milli-Gauss and micro-Tesla range.



- Tabletop device with 2 sensors

            General Probe Range: 0-3000 milli-Tesla (0-30,000 Gauss)

            Precision Probe Range: 0-300 micro-Tesla (0-3000 milli-Gauss)

- For static and changing magnetic fields

- Highly accurate Transverse Hall sensor

- Different units selectable  (mG / µT)

- Data storage on SD memory card

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-MFM 4000-ICA

The magnetometer PCE-MFM 4000 is used in the laboratory and quality assurance to measure the strength of magnetic fields. The magnetometer is delivered with two different sensors. A magnetic field sensor is available for general measurements in the Gauss and milli-Tesla range, as well as a precision sensor for measurements in the milli-Gauss and micro-Tesla range.



- Tabletop device with 2 sensors

            General Probe Range: 0-3000 milli-Tesla (0-30,000 Gauss)

            Precision Probe Range: 0-300 micro-Tesla (0-3000 milli-Gauss)

- For static and changing magnetic fields

- Highly accurate Transverse Hall sensor

- Different units selectable  (mG / µT)

- Data storage on SD memory card

- Incl. ISO calibration certificate
Manufacturer: PCE Instruments
Test Instruments manufacturer
