Air Sampler

The air sampler of PCE is used for microbiological examination of the air during the inspection of the microbiological contamination indoors in all rooms under the experts’ supervision and in biology, in clean rooms in the pharmaceutical industry, in hygienically sensitive production areas and equipment in the food industry and its suppliers, in medical environments with higher requirements or also in hygiene tests of air conditioning systems (HVAC).

The particle collector absorbs a defined volume of air that is directed to various growth media for cultivation. The microbial components of the air sample are qualitatively and quantitatively analyzed. In addition, the relevant types or kinds of the present molds are determined.

Molds that represent a health risk, as well as fungal species with indication for material damage are highlighted. The samples are analyzed by an independent laboratory. The air sampler or even particle collector provides information about whether and to what extent the mold spores and bacteria strains are present and what types occur primarily. The measurement is simple and can be carried out without prior preparation.

Microbial Air Measurement

By means of microbial air measurement the concentration of germable spores and hyphae fragments that are in the air is measured. The sampling is carried out via a microbial air aggregating device that operates in impaction. The microbial air aggregating device sucks a certain amount of air through a suction device and secretes the airborne spores through a sieve on the underlying growth medium in an agar plate. One should not ventilate the affected room for about 12 hours before the microbial air measurement and make sure no dust is raised up.

Air particle measurement

Air particle measurement registers live and dead components of the mold and also provides information on the other substances transported in the air such as mineral fibers, pollens, algae, etc. For the air particle measurement a certain amount of the indoor air is sucked in by a measuring instrument. The sucked indoor air is directed through a suction device (slit impactor) on the holder coated with an adhesive material. Because of the fact that a sample also registers the dead parts of a fungus, a conclusion can be made about a former fungal infestation. Therefore, this method is suitable for a quality control after a mold remediation and in the case of prophylactic examination before the real estate purchase.

If you have any questions, please contact us at or +44 ( 0 ) 161 464902 0.

Air Sampler PCE-AS1

£ 3,248.00

Price excl. VAT &. delivery

PCE-AS1 is an air sampling meter used to assess microbiological pollution and monitor hygiene. Designed for use in hospitals, clean rooms, food, beverage, cosmetics, and pharmaceutical production facilities. The PCE-AS1 air sampler meets the latest requirements for devices used for airborne microbial analysis of bacterial and fungal counts. Rate is 100 lpm or 3.53 cfm with 300 micropores. **Optional ISO lab calibration listed under accessories**

Accommodates manual adjustment of air volumes from 10 to 6000 liters
Offers data storage for up to 99 parameters / 2000 measurement records
Aids in compliance with HACCP, FDA FMSA, USP 797 and ISO 14698-1
Runs off a rechargeable battery or AC power
Supports standard Petri dishes of 90 mm / 3.5 in
Software free as QR image for IOS / Android

Air Sampler PCE-RCM 10

£ 193.00

Price excl. VAT &. delivery

PCE-RCM 10 is a portable handheld air sampler or particle counter used to monitor particulate matter (PM) concentrations in the air. Designed to aid in indoor air quality (IAQ) assessments, this particle counter also measures air temperature and relative humidity (RH).

PM channels: PM 2.5, PM 10
Particle sizes (in micrometers): 2.5 µm, 10 µm
Temp. measuring range: -20 … +70 °C / -4 … +158 °F
Humidity measuring range: 0 … 100 % RH
2.4" full-color LCD with user-friendly graphics
For indicative measurements

Air Sampler PCE-RCM 11

£ 318.00

Price excl. VAT &. delivery

The air sampler PCE-RCM 11 serves as an indicative test of environmental parameters. The air sampler PCE-RCM 11 enables the measurement of fine dust, temperature and relative humidity. The bright display of the air sampler provides information about the already mentioned parameters.

Fine dust, formaldehyde, humidity, temperature, TVOC
Particle size channels : PM 2.5 / PM 10
Measuring range TVOC: 0.00 … 9.99 mg / m³ (volatile organic compounds)
Measuring range temperature: -20 … 70°C / -4 … 158°F
Measuring range humidity: 0 … 100% RH
Measuring range formaldehyde: 0.00 … 5.00 mg / m³
Interface: USB
For indicative measurements

Air Sampler PCE-RCM 12

£ 416.00

Price excl. VAT &. delivery

The air sampler PCE-RCM 12 is used for indicative testing of environmental parameters. The air sampler PCE-RCM 12 enables the measurement of CO2, fine dust, temperature and relative humidity. The bright display of the air sampler provides information about these parameters.

Fine dust, CO2, formaldehyde, humidity, temperature
Particle size channels: PM 2.5 / PM 10
Temperature measuring range: -20 … 70°C / -4 … 158°F

Humidity measuring range: 0 … 100% r.H.
Formaldehyde measuring range: 0.00 … 5.00 mg/m³
CO2 measuring range: 0 … 9999 ppm

For indicative measurements

Air Sampler PCE-MPC 10

£ 486.00

Price excl. VAT &. delivery

PCE-MPC 10 is a portable handheld air sampler or particle counter used to monitor particulate matter (PM) concentrations in the air. Designed to aid in indoor air quality (IAQ) assessments, this particle counter also measures air temperature and relative humidity (RH).

PM channels: PM 2.5, PM 10
Particle sizes (in micrometers): 2.5 µm, 10 µm
Temp. measuring range: 0 … +50 °C / +32 … +122 °F
Humidity measuring range: 0 … 100 % RH
2" full-color LCD with user-friendly graphics
Integrated data logger with adjustable sampling time
Internal memory stores up to 5000 date-and-time-stamped data sets

Air Sampler PCE-MPC 15

£ 623.00

Price excl. VAT &. delivery

The air sampler is used in offices, workshops or in laboratories to carry out indicative measurements of the environmental conditions. In addition to the number of particles, the air sampler determines the mass concentration of PM2.5 and PM10 in the measuring range 0 … 1000 µg/m³.

Measurable particle sizes: PM2.5 / PM10
Particle sizes: 0.3 / 2.5 µm
Mass concentration
Particle counter
Temperature
Humidity (RH)
Flash memory for approx. 12 measurement runs

Air Sampler PCE-MPC 20

£ 745.00

Price excl. VAT &. delivery

The air sampler PCE-MPC 20 is a particle counter that measures the particles in the atmosphere. The measurable particle sizes in the particle collector are 0.3, 2.5 and 10 μm.

Measurable particle sizes: PM2.5 / PM10
Measuring range Mass concentration: 0 … 2000 μg / m³
Measurable particle sizes: 0.3, 2.5 and 10 μm
Display with graphic real-time diagram
Data memory up to 5000 data sets

Air Sampler PCE-PCO 1

£ 843.00

Price excl. VAT &. delivery

PCE-PCO 1 is a laser particle counter, air sampler or dust measuring device for measuring the concentration of particles in the air. The PCE-PCO 1 air sampler:

Measures 6 sizes of particles: 0.3 µm, 0.5 µm, 1.0 µm, 2.5 µm, 5.0 µm, 10 µm
Offers a robust 80 MB internal memory and microSD card slot
Features a large, full-color LCD display with backlight
Includes a built-in camera for image and video recording
Contains sensors for measuring air temperature, dew point and relative humidity
Displays temperature in degrees Celsius (°C) or Fahrenheit (°F)

Air Sampler PCE-MPC 25

£ 940.00

Price excl. VAT &. delivery

Measurable particle sizes: PM2.5 / PM10
Particle sizes: 0.3 / 0.5 / 1.0 / 2.5 / 5.0 and 10 µm
Mass concentration
Particle counter
Temperature
Humidity (RH)
Flash memory for approx. 12 measurement runs
