Durometer / Shore Durometer

Durometer PCE-DD-A Shore A
£ 88.00
Price excl. VAT &. delivery
2 year Warranty

The PCE-DD-A durometer is used to measure Shore A hardness in soft gums, rubber, elastomers and more. This compact pocket sized tester is ideal for checking / testing rubber hardness (tyre condition checker). Calibration is not available for this item.

- Measurement area: 0 ... 100 Shore A
- Resolution: 0.5
- Accuracy: ± 1
- Depth of indentation: 0 ... 2.5 mm / .1 in
- Indenter: 35°





Durometer PCE-DD-D Shore D
£ 88.00
Price excl. VAT &. delivery
2 year Warranty

PCE-DD-D is a Shore D durometer or hardness tester. This Shore D durometer uses an impact rod with a 30º conical point and 50 Newtons (N) of force to make a surface indentation on material samples with a minimum thickness of 6 mm or 0.24". Calibration is not available for this item.


- For Shore D hardness testing of hard rubber, hard resin, acrylic, glass,
  thermoplastic and more
- Measurement range: 0 ... 100 Shore D
- Accuracy: ± 2 Hardness - Grade



Durometer PCE-DX-AS Shore A
£ 121.00
Price excl. VAT &. delivery
2 year Warranty

Mechanical shore durometer for measuring hardness of soft elastomer with drag needle. The shore durometer is composed of a single component with a measuring head and a 360º dial. To improve the readability of peak value, the device comes with a drag needle, that ensures the maximum reading can be captured. Once it has been measured, it can be reset to zero.


- Force of pressure: 0 to 12.5 N
- Penetrating body: 35º (according to Shore A)
- Equipped with drag needle
- Measurement range: 10 ... 90
  (pressure diminishes below 10 and above 90)
- Margin of error: ± 1
- Division of scale: 1

Durometer PCE-DX-AS-ICA Shore A incl. ISO Calibration Certificate
£ 231.00
Price excl. VAT &. delivery
2 year Warranty
ISO Calibration

Mechanical shore durometer for measuring hardness of soft elastomer with drag needle. The shore durometer is composed of a single component with a measuring head and a 360º dial. To improve the readability of peak value, the device comes with a drag needle, that ensures the maximum reading can be captured. Once it has been measured, it can be reset to zero.


- Force of pressure: 0 to 12.5 N
- Penetrating body: 35º (according to Shore A)
- Equipped with drag needle
- Measurement range: 10 ... 90
  (pressure diminishes below 10 and above 90)
- Margin of error: ± 1
- Division of scale: 1
- incl. ISO Calibration Certificate

Durometer PCE-DDA 10-ICA incl. ISO Calibration Certificate
£ 699.00
Price excl. VAT &. delivery
2 year Warranty
ISO Calibration

The PCE-DDA 10 shore durometer is an ergonomic device to check Shore hardness in gum, plastic and other non-metallic materials. It has been designed with a very high quality. The PCE-DDA 10 durometer is mainly used for soft gums, elastomers, natural rubber, neoprenes, casting resin, white PVC, leather, etc. It has a reading accuracy of 0.1 hardness units.


- Handheld device
- For Shore A measurements
- Single and Serial Measurements
- Data transfer to pc
- Incl. ISO Calibration Certificate

Durometer PCE-DDD 10 Shore D
£ 560.00
Price excl. VAT &. delivery
2 year Warranty

The PCE-DDD 10 Shore D durometer is a portable handheld device used to check Shore D hardness in hard rubber and thermoplastic. This digital durometer has a reading accuracy of 0.1 hardness units. The durometer comes manufacturer calibrated and can be optionally certified to ISO standards for an additional fee (see accessories for details).


- Portable handheld digital device
- For Shore D hardness testing
- Single and serial measurements
- Data transfer to PC

Durometer PCE-DDD 10-ICA incl. ISO Calibration Certificate
£ 694.00
Price excl. VAT &. delivery
2 year Warranty
ISO Calibration

The PCE-DDD 10 shore durometer is an ergonomic device to check Shore D hardness in materials such as hard rubber and thermoplastic. It has been designed with a very high quality.


- Handheld device
- For Shore D measurements
- Single and Serial measurements
- Data transfer to PC
- Incl. ISO Calibration Certificate

Durometer PCE-DDO 10 Shore O
£ 738.00
Price excl. VAT &. delivery
2 year Warranty

The PCE-DDO 10 shore durometer is an ergonomic device to check Shore hardness in gum. It has been designed with a high quality. The PCE-DDO 10 durometer is mainly used for soft gums. If the material thickness is not enough, it should be tightened on the back with the same material in order to increase its thickness.


- Handheld device
- For Shore O measurements
- Single and Serial-Measurements
- Data transfer to PC



Barcol Hardness Testing Durometer PCE-1000N
£ 961.00
Price excl. VAT &. delivery
2 year Warranty

PCE-1000N is a portable handheld Barcol hardness testing durometer used to measure the hardness of pure aluminum, soft aluminum, thick aluminum alloy and aluminum sheets, strips, rods, castings and forgings. The hardness of fiber-reinforced (FRP) plastics, glass-reinforced (GRP) plastics, hard plastics and soft metals (such as copper or lead) also can be tested using this battery-powered digital Barcol impressor hardness meter.


- Measurement parameters: Barcol (HBA), Brinell (HB), Vickers (HV), Webster
  (HW), Rockwell
  (HRB / HRE / HRF / HRH)
- Measuring range: 0 ... 100 HBA / 25 ... 150 HB
- Accuracy: 81 ... 88 HBA: ± 1 HBA / 42 ... 48 HBA: ± 2 HBA
- Repeatability: 81 ... 88 HBA: ± 1.5 HBA / 42 ... 48 HBA: ± 2.5 HBA
- Resolution: 0.1 HBA
- Meets ASTM standards: E140-97; D2583-75; B648-78







Durometer PCE-2000N
£ 788.00
Price excl. VAT &. delivery
2 year Warranty

The PCE Instruments PCE-2000N durometer uses the Leeb rebound method. This is a dynamic hardness test method in which a standardized test specimen, usually a hard metal ball, is hit with defined impact energy on a test surface.

- Measurement according to Leeb Rebound method
- Hardness scales: HL (Leeb), HV (Vickers), HB (Brinell), HS (Shore), HRA (Rockwell A), HRB (Rockwell B), HRC (Rockwell C)
- Measurement Range: 170-960 HLD, 80-1042 HV, 19-683 HB, 30.6-102.6 HS, 59.1-88 HRA, 13.5-101.7 HRB
- External impact device on 1.5 m / 4.9 ft cable
- Accuracy: ± 0.5% (@ 800 HLD), Repeatability: 0.8% (@ 800 HLD)
- Storage data measurements on a USB stick
- Color display, Measurement in different angles possible, Various other impactors as accessories

Durometer PCE-2000N-ICA incl. ISO calibration certificate
£ 952.00
Price excl. VAT &. delivery
2 year Warranty
ISO Calibration
The PCE Instruments PCE-2000N durometer uses the Leeb rebound method. This is a dynamic hardness test method in which a standardized test specimen, usually a hard metal ball, is hit with defined impact energy on a test surface.

- Measurement according to Leeb Rebound method
- Hardness scales: HL (Leeb), HV (Vickers), HB (Brinell), HS (Shore), HRA (Rockwell A), HRB (Rockwell B), HRC (Rockwell C)
- Measurement Range: 170-960 HLD, 80-1042 HV, 19-683 HB, 30.6-102.6 HS, 59.1-88 HRA, 13.5-101.7 HRB
- External impact device on 1.5 m / 4.9 ft cable
- Accuracy: ± 0.5% (@ 800 HLD), Repeatability: 0.8% (@ 800 HLD)
- Storage data measurements on a USB stick
- Color display, Measurement in different angles possible, Various other impactors as accessories
Incl. ISO calibration certificate



Durometer for Metals PCE-2500N
£ 578.00
Price excl. VAT &. delivery
2 year Warranty

PCE-2500N is a portable handheld pen-sized digital material hardness tester, rebound hammer or durometer for use with metals. This high-accuracy hardness tester quickly and accurately measures the surface hardness of 10 common metal materials including steel, cast steel, alloy tool steel, stainless steel, cast iron, ductile iron, cast aluminum alloy, brass, bronze and copper.

- Measuring principle: Leeb Rebound method
- Displays measurements in Rockwell A, B or C (HRA, HRB or HRC), Brinell (HB), Vickers (HV), Shore (HS) or Leeb (HLD)
- Measurement ranges: 170-960 HLD, 59.1-88 HRA, 3.5-101.7 HRB, 17.9-69.5 HRC, 19-683 HB, 80-1042 HV, 30.6-102.6 HS
- Accuracy: ± 0.5%; Repeatability: ± 0.8%
Type D impact device

Durometer for Metals with ISO Certificate PCE-2500N-ICA
£ 796.00
Price excl. VAT &. delivery
2 year Warranty
ISO Calibration

PCE-2500N-ICA is a portable handheld pen-sized digital material hardness tester, rebound hammer or durometer for use with metals. This high-accuracy hardness tester quickly and accurately measures the surface hardness of 10 common metal materials including steel, cast steel, alloy tool steel, stainless steel, cast iron, ductile iron, cast aluminum alloy, brass, bronze and copper.

- Measuring principle: Leeb Rebound method
- Displays measurements in Rockwell A, B or C (HRA, HRB or HRC), Brinell (HB), Vickers (HV), Shore (HS) or Leeb (HLD)
- Measurement ranges: 170-960 HLD, 59.1-88 HRA, 3.5-101.7 HRB, 17.9-69.5 HRC, 19-683 HB, 80-1042 HV, 30.6-102.6 HS
- Accuracy: ± 0.5%; Repeatability: ± 0.8%
Type D impact device
- Includes ISO calibration certificate

Durometer PCE-2550
£ 780.00
Price excl. VAT &. delivery
2 year Warranty

Due to its compact design, the PCE-2550 durometer is very easy to use for incoming and outgoing inspections. Due to the adjustable hardness scales, the durometer PCE-2550 is versatile.

- Measurement according to Leeb Rebound method
- Measurement units: HLD, HRA, HRB, HRC, HB, HV, HS
- Measurement ranges: 170-960 HLD, 59.1-88 HRA, 3.5-101.7 HRB, 17.9-69.5 HRC, 19-683 HB, 80-1042 HV, 30.6-102.6 HS
- Accuracy: ± 0.4%, Repeatability: ± 0.6%
- Impact Device: Type D
- Measuring Direction: 360°
- Internal measured value memory

Durometer PCE-2550-ICA incl. ISO Calibration Certificate
£ 1,003.00
Price excl. VAT &. delivery
2 year Warranty
ISO Calibration

Due to its compact design, the PCE-2550-ICA durometer is easy to use for incoming and outgoing inspections. Due to the adjustable hardness scales, the durometer is very versatile.

- Measuring ranges: 170 ... 960 HLD
- Measurement direction: 360°
- Impact device: Type D
- Measurement units: HL, HB, HRB, HRC, HRA, HV, HS
- Internal measurement memory
- incl. ISO Calibration Certificate

Metal Hardness Testing Durometer PCE-2600N
£ 1,279.00
Price excl. VAT &. delivery
2 year Warranty

The Metal Hardness Testing Durometer PCE-2600N is used wherever a fast hardness test has to be carried out. It is possible to use the durometer PCE-2600N to determine the surface hardness of many metals. The durometer PCE-2600N is especially suitable for quality or product inspection.

- Measurement according to Leeb Rebound method
- Measurement units: HLD, HRA, HRB, HRC, HB, HV, HS
- Measurement ranges: 170-960 HLD, 59.1-88 HRA, 3.5-101.7 HRB, 17.9-69.5 HRC, 19-683 HB, 80-1042 HV, 30.6-102.6 HS
- Accuracy: ± 0.5%, Repeatability: ± 0.8%
- Impactor: DL
- Display: 128 x 64 OLED

Metal Hardness Testing Durometer with ISO Certificate PCE-2600N-ICA
£ 1,506.00
Price excl. VAT &. delivery
2 year Warranty
ISO Calibration

The Metal Hardness Testing Durometer PCE-2600N-ICA is used wherever a fast hardness test has to be carried out. It is possible to use the durometer PCE-2600N-ICA to determine the surface hardness of many metals. The durometer PCE-2600N-ICA is especially suitable for quality or product inspection.

- Measurement according to Leeb Rebound method
- Measurement units: HLD, HRA, HRB, HRC, HB, HV, HS
- Measurement ranges: 170-960 HLD, 59.1-88 HRA, 3.5-101.7 HRB, 17.9-69.5 HRC, 19-683 HB, 80-1042 HV, 30.6-102.6 HS
- Accuracy: ± 0.5%, Repeatability: ± 0.8%
- Impactor: DL
- Display: 128 x 64 OLED
- Includes ISO calibration certificate

Durometer PCE-2900
£ 1,563.00
Price excl. VAT &. delivery
2 year Warranty

The durometer PCE-2900 has been developed for hardness measurements on metallic materials. The durometer PCE-2900 measures the material hardness in Vickers, Brinell, Rockwell, Leeb and Shore. The durometer PCE-2900 measures the hardness according to the Leeb rebound principle.

- Measurement according to Leeb Rebound method
- Measurement units: HLD, HRA, HRB, HRC, HB, HV, HS
- Measurement ranges: 170-960 HLD, 59.1-88 HRA, 3.5-101.7 HRB, 17.9-69.5 HRC, 19-683 HB, 80-1042 HV, 30.6-102.6 HS
- Accuracy: ± 0.5%, Repeatability: ± 0.6%
- Impactor: Type D
- USB and WiFi for data transmission
