Industrial Measurement Products and Solutions

- Humidity Sensor

Order no.: PCE-P18D

The humidity sensor PCE-P18 is used in HVAC technology to monitor humidity and temperature. The measured values ??are output as a standard signal by the humidity sensor PCE-P18. Air humidity and temperature are accurately determined in this compact humidity sensor via a semiconductor component. For commissioning, the PCE-P18 humidity probe is supplied with a DC voltage. The measured values ??are output via a two-wire cable.


- With display
- Standard signal output
- Simple wall mounting
- RS-485 interface



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-P18-0A0E0

The PCE-P18 humidity sensor is used in HVAC technology to monitor humidity and temperature. The measured values ​​are output by the humidity sensor PCE-P18 via the RS485 interface. In this compact humidity sensor, air humidity and temperature are precisely determined using a semiconductor component.



- Measuring range humidity: 0 ... 100% RH
- Measuring range temperature: - 20 ... 60 ° C
- Interface: RS 485 Modbus



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-P18L

The humidity sensor PCE-P18L was developed and constructed for the permanent monitoring of temperature or humidity. The compact dimensions of the humidity sensor are the characteristics of this instrument. The measurement of the temperature and humidity is via a semiconductor component.


- Humidity measuring range: 0 ... 100% RH
- Temperature measuring range: -20 ... 60 °C
- Output: 4 ... 20 mA
- Special Feature: Manual switchable analog value output



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-P18-2A0E0

The PCE-P18 temperature sensor is used in HVAC technology to monitor humidity and temperature. The measured values ​​are output by the temperature sensor PCE-P18 as a standard signal 4 ... 20 mA. Air humidity and temperature are precisely determined in this compact temperature sensor using a semiconductor component.



- Measuring range humidity: 0 ... 100% RH
- Measuring range temperature: - 20 ... 60 ° C
- Interface: RS 485 Modbus
- Analog output: 0 ... 10 V



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-P18-1A0E0

The PCE-P18 humidity sensor is used in HVAC technology to monitor humidity and temperature. The measured values ​​are output by the humidity sensor PCE-P18 as a standard signal 4 ... 20 mA. In this compact humidity sensor, air humidity and temperature are precisely determined using a semiconductor component.

- Measuring range humidity: 0 ... 100% RH
- Measuring range temperature: - 20 ... 60 ° C
- RS 485 Modbus interface, 4 ... 20 mA output

Manufacturer: PCE Instruments
Test Instruments manufacturer
