Sensor

Order no.: PCE-DMM 50

The pressure sensor PCE-DMM 50 is suitable for stationary and mobile pressure measurement. The pressure sensor PCE-DMM 50 is used in mechanical and plant engineering, laboratory technology and environmental technology. This pressure sensor is battery powered. The measuring range of the pressure sensor reaches up to 600 bar.


- Max. 600 bar / 8702 psi
- Rotating display
- For hygienic applications
- Media: water, oxygen, fuels and oils
- Print: absolute or relative (user selectable)
- Diaphragm: Ceramics
- Accuracy class: 0.2



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-DMM 51

The pressure sensor PCE-DMM 51 is suitable for flush mounting hygiene. Thus, the sensor can be installed both in the food industry as well as in medical technology. The pressure gauge shows on its rotatable display pressures up to 400 bar, relative or absolute. The operating fluid of the pressure sensor has a food safe FDA approval.


- Max. 400 bar / 5801 psi
- Rotating display
- For hygienic applications
- Media: water, paints and coatings, gases, viscous and paste media
- Pressure: relative
- Diaphragm: stainless steel flush
- Accuracy class: 0.2



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: 6000-1082

Tank sensor with weight, with oil-resistant cable (approx 10 m  / 11 yard cable length)



- Class B
- Measuring range: -30 ... +150 °C / -22 ... +302 °F
- Dimensions.: 80 x 4.0 mm / 3.15 x 0.15"
- Response time: 8 sec.

Manufacturer: Dostmann electronic GmbH
Test Instruments manufacturer
Order no.: PCE-DMM 21

The pressure sensor PCE-DMM 21 is suitable for flush sanitary installation. The pressure sensor may represent on its rotatable display pressures up to 40 bar, absolute or relative. The filling of the pressure sensor has a food safe FDA approval. The flush mounting of the pressure sensor can be sterilized.


- To 40 bar / 580 psi
- Relative and absolute pressure measurement
- Max-min function with reset
- 2-line backlit display



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-DMM 60

The pressure sensor PCE-DMM 60 is a precision instrument of the highest standards. The pressure sensor is specifically designed for process monitoring and calibration. This pressure sensor is distinguished by its modular concept. This means that the actual sensor and the display can be separated. The pressure transmitter can be selected on site for different measuring ranges and connected to the display without tools.


- Max. 400 bar / 5801 psi
- Media: water, gases
- Pressure type: Absolute / Relative
- Diaphragm: stainless steel
- Accuracy: 0.05



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: WTR 150

The resistance temperature sensor WTR 150 is designed for applications in the food industry. Thanks to the 1/2" thread, the WTR 150 resistance temperature sensor can be screwed to a tube or vessel by means of a sleeve. Due to the rounded tip, it is not a problem if the resistance temperature sensor comes in contact with food. The proble length is in steps of 50 mm up to 400 mm and can be freely selected.


- Measuring range: - 50 °C ... 400 °C
- Accuracy: Class A
- Tapped holes for sockets with 1/2"



Manufacturer: Promesstec GmbH
Test Instruments manufacturer
Order no.: WTR 190

The WTR 190 ambient temperature sensor can be mounted on the wall. The WTR 190 ambient temperature sensor has a polyamide case. The protective case of the Pt100 sensor is made of stainless steel. The measuring range extends from -50 °C to 130 °C.


- Sensor length: 45 mm
- Wall-mounted
- Class A Pt100



Manufacturer: promesstec GmbH
Test Instruments manufacturer
Order no.: WTR 270

The WTR 270 temperature sensor for food industry is distinguished by its robust design (stainless steel or PTFE ). The WTR 270 temperature sensor for food industry is available in different lengths, so the device will be a great help for health inspectors.


- Different sensor lengths
- Stainless steel or PTFE versions
- Pt100 Class A



Manufacturer: Promesstec GmbH
Test Instruments manufacturer
Order no.: WTR 280

The Pt100 WTR 280 sensor cable has a simple design. The Pt100 WTR 280 sensor cable has a class A Pt100 sensor, a protective case as well as a connection. The Pt100 WTR 280 is available in 2 -, 3 - or 4-wire connected to the supply line.


- Different sensor lengths
- Measuring range of -50 °C ... 200 °C
- 4 mm, 5 mm, 6 mm and 9 mm in diameter



Manufacturer: Promesstec GmbH
Test Instruments manufacturer
Order no.: WTR 290

The WTR 290 surface temperature sensor has been designed to measure surface temperature. Thanks to its small size (30 x 10 x 10 mm), the WTR 290 surface temperature sensor can be installed everywhere.


- Measuring range: - 50 °C ... 110 °C
- Stainless steel contact surface
- 2 -, 3 - or 4-wire Class A Pt100 sensor



Manufacturer: promesstec GmbH
Test Instruments manufacturer
Order no.: PCE-P18L

The humidity sensor PCE-P18L was developed and constructed for the permanent monitoring of temperature or humidity. The compact dimensions of the humidity sensor are the characteristics of this instrument. The measurement of the temperature and humidity is via a semiconductor component.


- Humidity measuring range: 0 ... 100% RH
- Temperature measuring range: -20 ... 60 °C
- Output: 4 ... 20 mA
- Special Feature: Manual switchable analog value output



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-P18-1

The humidity sensor PCE-P18-1 can be used to monitor air humidity and temperature in HVAC engineering.


- Humidity and temperature sensor
- Simple wall fastening
- RS-485 interface



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-P18-2

The humidity sensor PCE-P18-2 can be used to monitor air humidity and temperature in HVAC engineering.


- Humidity and temperature sensor
- 4…20 mA output
- Simple wall fastening
- RS-485 interface



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-P18-3

The Humidity Sensor PCE-P18-3 can be used to monitor air humidity and temperature in HVAC engineering. The Humidity Sensor PCE-P18-3 releases the measured indicator as a standard signal 0…10 V (not galvanic isolated). Air humidity and temperature are detected accurately due to a semiconductor.


- Humidity and temperature sensor
- 0…10 V output
- Simple wall fastening
- RS-485 interface



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-P18D

The humidity sensor PCE-P18 is used in HVAC technology to monitor humidity and temperature. The measured values ??are output as a standard signal by the humidity sensor PCE-P18. Air humidity and temperature are accurately determined in this compact humidity sensor via a semiconductor component. For commissioning, the PCE-P18 humidity probe is supplied with a DC voltage. The measured values ??are output via a two-wire cable.


- With display
- Standard signal output
- Simple wall mounting
- RS-485 interface



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-P18D

The temperature sensor PCE-P18 is used in HVAC technology to monitor humidity and temperature. The measured values are output as a standard signal by the humidity sensor PCE-P18. Air humidity and temperature are accurately determined in this compact humidity sensor via a semiconductor component. For commissioning, the PCE-P18 humidity probe is supplied with a DC voltage. The measured values are output via a two-wire cable.


- With display
- Standard signal output
- Simple wall mounting
- RS-485 interface



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-PS 420

The simple pressure sensor PCE-PS 420 can be used everywhere where simple pressure is to be measured. The measured pressure is provided as a 4 ... 20 mA analog value on the pressure sensor.


- Max. 400 Bar (selectable)
- 4 ... 20 mA output
- Media: non-corrosive gases and liquids
- Pressure: relative
- Diaphragm: Ceramics
- Accuracy class: 1



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-DMM 10

The compact pressure sensor PCE-DMM 10 is characterized by its rotatable housing and the display and the battery supply. Thus, the pressure sensor PCE-DMM 10 is ideal for mobile applications, such as test beds.


- Max. 250 bar / 3626 psi
- Rotatable 4.5 digit display
- Battery operation
- Media: gases, fuels and oils
- Pressure: relative
- Diaphragm: Ceramic
- Accuracy class: 0.5



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-DMM 11

The pressure sensor PCE-DMM 11 is distinguished by the long battery life of 1800h. The rotatable housing and display completes the functionality of the manometer. Thus, the pressure sensor PCE-DMM 11 is ideal for mobile applications, such as test beds.


- Up to 600 bar / 8702 psi
- Relative pressure
- Revolving 4.5 digit display
- Max-Min function
- Different units



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-DMM 20

The Pressure Sensor PCE-DMM 20 has a two-line display. The Pressure Sensor can represent pressures up to 600 bar, relative or absolute. The parts of the gauge PCE-DMM 20 that come in contact with liquids are made of stainless steel.


- Max. 600 bar / 8702 psi
- Rotating display
- Battery operation
- Media: gas, water, fuels and oils
- Print: absolute or relative (user selectable)
- Diaphragm: stainless steel
- Accuracy class: 0.1



Manufacturer: PCE Instruments
Test Instruments manufacturer
