Clamp on Tester

Measurement function:
- AC
- DC
- DC voltage
- AC voltage
- LowZ AC / DC
- Resistance
- Continuity test
- Diode test
- Capacities
- Temperature (type K)
- Frequency (with the current clamp)
- Frequency (during voltage measurement)
- frequency (direct measurement)
- Duty cycle

- Current measurement up to 1000 A
- Cover of the measuring sockets
- Voltage measurement up to 600V
- Temperature measurement via 2 thermocouples
- Incl. ISO Calibration Certificate

- Current measurement up to 1000 A
- Cover of the measuring sockets
- Voltage measurement up to 600V
- Temperature measurement via 2 thermocouples

The PCE-830 Clamp on Tester is used for measuring one to three phases of electrical quantities for alternating current (AC). This 3-Phase Clamp on Tester also measures such parameters as voltage, current, frequency, harmonics and power as well as indicating, according to standard EN50160, harmonic values, interharmonics and asymmetrics. Interference, such as interruptions, leaks, overloads or transience (from 16µs) are detected with their corresponding values.

- PCE-830 + PCE-6801 amp clamp (100 A)
- Electrical conductor pick-up: 30 mm diameter
- Range selection: manual (1 A, 10 A, 100 A)
- Clamp dimensions: 210 x 62 x 36 mm
- Incl. ISO calibration certificate

The PCE-830 Clamp on Tester is used for measuring one to three phases of electrical quantities for alternating current (AC). This Clamp on Tester also measures such parameters as voltage, current, frequency, harmonics and power as well as indicating, according to standard EN50160, harmonic values, interharmonics and asymmetrics. Interference, such as interruptions, leaks, overloads or transience (from 16µs) are detected with their corresponding values.

- PCE-830 + PCE-6802 amp clamp (1000 A)
- Electrical conductor pick-up: 55 mm / 2.2 in diameter
- Range selection: manual (10 A, 100 A, 1000 A)
- Clamp dimensions: 244 x 97 x 46 mm / 9.6 x 3.8 x 1.8 in
- Incl. ISO calibration certificate

Clamp on Tester with network Analyzer / Clamp on Tester with data logger. The Clamp on Tester (Graphic Power Quality Analyzer) PCE-GPA 62 is used for single-phase or three-phase measurements of the active, reactive and apparent power, power factor, phase angle, energy, voltage, current as well as peaks and harmonics up to 50? of the harmonic waveform. As all test instruments, the Clamp on Tester is delivered manufacturer calibrated (ISO certification is available optional).

- Real-time test, register and measurement of voltage and current (real and effective)
- Measures power factor and phase angle, frequency, energy, active, reactive and apparent power
  (single-phase or three-phase in symmetrical networks).
- Max. conductor diameter: 55 mm / 2.2 in
- Records up to 50,000 records

This clamp on tester is used for single-phase or three-phase measurements of the active, reactive and apparent power, power factor, phase angle, energy, voltage, current as well as peaks and harmonics up to 50º of the harmonic waveform. The clamp on tester is equipped with data logger. The test instrument is delivered manufacturer calibrated (ISO or certification as an option).

- Real-time test, register and measurement of voltage and current (real and effective)
- Measures power factor and phase angle, frequency, energy, active, reactive and apparent power
  (single-phase or three-phase in symmetrical networks).
- Max. conductor diameter: 55 mm / 2.2 in
- Datalogger for 50,000 readings / software/ USB interface
- incl. ISO Calibration Certificate

The PCE-360 is a HVAC Meter with data logger functionality. This versatile power analyzer can take single-phase and three-phase power measurements both in real time and over an extended time period.

- Voltage range: 50.0 V ... 600.0 V True RMS value
- Current range: 3.0 A ... 999.9 A True RMS value
- Includes clamps, clips, leads, PC software and data cable
- Data logger of 10,000,000 records at 5/10/30/60/120 second interval options
- For measurement in real time and over an extended time period up to 578 days @ 5 second sample rate
- incl. ISO Calibration Certificate

Clamp on Tester for measuring AC current, AC voltage, DC current and frequency. The reduced dimensions of this device allow for measurements to be taken in places with limited access. The backlight display ensures that it is easy to read, even in places with limited light available, such as electrical cabinets or in cabling ducts. The Clamp on Tester (as all the test instruments) comes manufacturer calibrated - ISO certification is available as an option.

- AC current (50/60 Hz): 200 A / 0.1 A or 100-mA / ±3.0% + 8 digits
- DC current: 200 A / 100-mA / ±2.8% + 8 digits
- AC test voltage (without contact):100 VAC to 600 VAC at 50 /
  60 Hz
- Frequency (3 ranges): 40 to 50 Hz / 51 to 510 Hz / 0.51 to 1 kHz



The clamp on tester is a measuring device for the precise determination of electrical currents. With a current clamp diameter of 25 mm and a measuring range of 0 … 1000 A AC/DC, the clamp on tester covers a large part of all measurement tasks. The clamp on tester can be used to monitor the wallbox of an electric vehicle on both the primary and secondary side.

- Wallbox monitoring (primary/secondary)
- Measuring range: 0 ... 1000 A AC/DC
- Inductive current measurement
- Direct current
- Alternating current
- Frequency
- Inrush AC
- AC low-pass filter (LPF)

- Digital Multimeters up to 200 A
- Compact dimensions
- Robust plastic housing
- Multimeter functions
- Safety conditions: IEC1010-1 (2001)
                             CAT II 1000V
                             CAT III 600V

Digital Clamp Meter for measuring AC/DC current, AC voltage and resistance. This clamp meter is designed to indirectly detect AC/DC current and ohms. The clamp has white LEDs which illuminate the point of measurement and test the voltage without contact. Small dimensions of this device allow to take measurements in places with limited access. The clamp meter comes manufacturer calibrated and can optionally be certified according to ISO or standards.

- AC / DC current, voltage and resistance measurement
- 3 2/3-digit LCD display
- Power supply: 2 x 1.5V AAA battery
- Dimensions: 164 x 65 x 32 mm / 6.4 x 2.5 x 1.2 in



- Measurable up to 600 A
- Clamp with multimeter functions
- OLED display
- NCV function
- TRMS AC A

This clamp on tester was developed for the indirect measurement of AC/DC currents as well as the frequency. A non-contact voltage tester function and a torch/flashlight for illuminating the measuring point have also been integrated into this clamp on tester.

- AC/DC current, AC voltage and frequency measurement
- AC voltage test (contactless test):
   100 VAC to 600 VAC 50/60Hz 100 VAC to 600 VAC 50/60Hz
- DCA zero point function

Measurement functions
- DC power
- AC power
- DC voltage
- AC voltage
- Resistance
- Frequency (direct)
- Frequency (current clamp)

Clamp on Tester to test leakage / RMS measurement / continuity and resistance test. The Clamp on Tester can measure leakage currents which appear when current flows through electrical conductors which are not designed for conduction current. The Clamp on Tester, as all test instruments, is delivered manufacturer calibrated, but can additionally be certified to ISO.

- Measures current up to 100 A
- Measures voltage up to 600 V
- Measures resistance up to 400 O
- Test cables are included



The clamp on tester has a measuring range of 0 … 1000 A AC/DC. The current is measured inductively using the clamp on the measuring device. Live supply lines with a diameter of up to 32 mm (1.2") can be connected to the clamp on tester.

- Measuring range: 0 ... 1000 A AC/DC
- Bluetooth interface
- Inrush current measurement
- LC color display
- Not Connected Voltage function

- Measuring range up to 3000 A AC
- LC display
- Inrush function
- Frequency measurement
- Data memory

PCE-PCM 1 is a multipurpose clamp-on tester or power analyzer used to measure alternating current (AC), voltage (TRMS) and frequency to determine active (kW), apparent (kVA) and reactive (kVAR) power as well as active energy (kWh) consumption. Both the phase angle and the power factor (cos φ) are shown on the handheld power meter's large and easy-to-read backlit display.

- Voltage (50 ... 200 Hz): 100 / 400 / 750V, ± (1.2% + 5 digits)
- Internal memory: Stores up to 99 measurement values
- Includes USB cable and PC software
- Three-phase power measurement
- True RMS
