Condition Monitoring

Condition Monitoring Stroboscope PCE-DSX 100
₹18,585.00
Price excl. VAT &. delivery
The condition monitoring stroboscope is a handy device for measuring the rotational speed of objects with a measuring range of 60 to 20,000 rpm. The condition monitoring stroboscope is suitable for inspecting objects with periodic movements and for detecting faults.

  • Measuring range: 60 … 20000 RPM
  • Coarse adjustment: +10, +100 RPM
  • Fine adjustment: +0.1, +1 RPM
  • Accuracy: 0.05 %
  • 2.1" LC display with illumination
  • Data storage function up to 10 values
Condition Monitoring Manifold PCE-HVAC 10
₹36,590.00
Price excl. VAT &. delivery
The condition monitoring manifold is a robust measuring instrument designed for daily use in refrigeration systems and heat pumps to determine pressure and temperature. Measurement with the condition monitoring manifold is carried out using supplied refrigerant hoses and 2 NTC clamp-on temperature sensors. The 83 preloaded refrigerants can be quickly selected and are visible on the measurement screen.

  • Measurement Range: -1 … +60 bar
  • Resolution: 0.01 bar
  • Accuracy: ±0.5% F.S. (Full Scale)
  • 83 refrigerants stored in the device
  • 2-way valve block with 3 connectors 7/16" – UNF
  • Includes 2 NTC clamp-on temperature sensors
  • Temperature measurement -10 … +200 °C
Condition Monitoring Stroboscope PCE-DSX 100-ICA incl. ISO-calibrartion-certificate
₹39,566.00
Price excl. VAT &. delivery
ISO Calibration
The condition monitoring stroboscope is a handy device for measuring the rotational speed of objects with a measuring range of 60 to 20,000 rpm. The condition monitoring stroboscope is suitable for inspecting objects with periodic movements and for detecting faults.

  • Measuring range: 60 … 20000 RPM
  • Coarse adjustment: +10, +100 RPM
  • Fine adjustment: +0.1, +1 RPM
  • Accuracy: 0.05 %
  • 2.1" LC display with illumination
  • Data storage function up to 10 values
  • incl. ISO-calibrartion-certificate
Condition Monitoring Pyrometer PCE-TC 28
₹91,646.00
Price excl. VAT &. delivery

The Condition Monitoring Pyrometer was designed for taking non-contact temperature measurements. To get accurate readings, the emissivity of the Condition Monitoring Pyrometer can be adjusted, depending on the operation purpose. Besides taking infrared images, the Condition Monitoring Pyrometer can also take normal pictures, as well as a mixture of both, due to the built-in digital camera.


  • Measurement range: -20 … +600°C / -4 … 1112°F
  • Accuracy: ± 2%, ± 2°C / 3.6°F
  • Frequency image recording: 9 Hz
  • Camera: 32 x 31 Pixel



Condition Monitoring Pyrometer PCE-TC 28-ICA incl. ISO Calibration Certificate
₹126,912.00
Price excl. VAT &. delivery
ISO Calibration

The Condition Monitoring Pyrometer was designed for taking non-contact temperature measurements. To get accurate readings, the emissivity of the Condition Monitoring Pyrometer can be adjusted, depending on the operation purpose. Besides taking infrared images, the Condition Monitoring Pyrometer can also take normal pictures, as well as a mixture of both, due to the built-in digital camera.


  • Measurement range: -20 … +600°C / -4 … 1112°F
  • Accuracy: ± 2%, ± 2°C / 3.6°F
  • Frequency image recording: 9 Hz
  • Camera: 32 x 31 Pixel- incl. ISO Calibration Certificate



Condition Monitoring Vibration Meter PCE-VT 1100S
₹43,435.00
Price excl. VAT &. delivery
The condition monitoring vibration meter is suitable for relative measurements on various machines. With the 45 mm long needle probe, you can access hard-to-reach places in machines and motors. For this reason, this condition monitoring vibration meter is used for rapid measurement of imbalance and for checking bearing and gear conditions.



  • Frequency range: 10 Hz … 1 kHz
  • Measures speed, distance, acceleration in metric units
  • Holds the reading after each measurement
  • Portable and battery operated
  • Needle probe: 45mm / 1.77"



Condition Monitoring Vibration Meter PCE-VT 1100S-ICA incl. Certificate
₹70,368.00
Price excl. VAT &. delivery
ISO Calibration
The condition monitoring vibration meter is suitable for relative measurements on various machines. With the 45 mm long needle probe, you can access hard-to-reach places in machines and motors. For this reason, this condition monitoring vibration meter is used for rapid measurement of imbalance and for checking bearing and gear conditions.


  • Frequency range: 10 Hz … 1 kHz
  • Measures speed, distance, acceleration in metric units
  • Holds the reading after each measurement
  • Portable and battery operated
  • Needle probe: 45mm / 1.77"
  • incl. ISO Calibration Certificate
Condition Monitoring Human Vibration Meter with Hand-Arm Sensor PCE-VM 31-HA
₹519,595.00
Price excl. VAT &. delivery

The PCE-VM 31-HA Condition Monitoring Human Vibration Meter is designed for measuring human vibration at the workplace. The Condition Monitoring Vibration Meter can calculate hand-arm vibration measurements according to ISO 5349 and whole-body vibration measurements according to ISO 2631.


  • Measuring of human vibration at the workplace
  • Velocity, acceleration, displacement
  • 3 channel FFT
  • TEDS support
  • Includes hand-arm sensor only - whole-body sensor sold separately (see  accessories)



Condition Monitoring Human Vibration Meter with Whole-Body Sensor PCE-VM 31-WB
₹550,545.00
Price excl. VAT &. delivery

The PCE-VM 31-WB Condition Monitoring Human Vibration Meter or Analyzer is designed for measuring human vibration at the workplace. The Condition Monitoring Vibration Meter can calculate hand-arm vibration measurements according to ISO 5349 and whole-body vibration measurements according to ISO 2631.


  • Measuring of human vibration at the workplace
  • Velocity, acceleration, displacement
  • 3 channel FFT
  • TEDS support
  • Includes whole-body sensor only - hand-arm sensor sold separately (see     accessories)
