Our fixed installation Aerosol particle counter offers the capability to measure flow rates from ±0.1 m/s to ±5 m/s using ultrasonic technology. This Aerosol particle counter is suitable for small pipes with a diameter of DN8 / 1/4" and is compatible with various pipe materials such as steel, copper, aluminum, and plastics. Due to its compact design, it can be quickly and easily mounted on the pipe.
The Aerosol particle counter's display provides information on flow velocity, date, and time. In another view, it also displays the volume flow rate for the day, month, and year. Additionally, the Aerosol particle counter can output the measurement value as an analog signal (4 ... 20mA) and digitally via an RS485 interface.
With a power supply range of 9 ... 36 V DC, the fixed installation Aerosol particle counter is highly versatile and can be used in a wide range of applications. It comes with a 2 m connection cable and coupling pads for improved signal transmission.
This Aerosol particle counter can be used in various applications, including heating systems, cooling water systems, and industrial processes where flow monitoring and control are necessary.
