Our fixed-installation Soldering iron / Soldering device offers the capability to measure flow rates from ±0.1 m/s to ±5 m/s using ultrasonic technology. This Soldering iron / Soldering device is suitable for small pipes with a diameter of DN25 / 1" and is compatible with various pipe materials such as steel, copper, aluminum, and plastics. Due to its compact design, it can be quickly and easily mounted on the pipe.
The Soldering iron / Soldering device's display provides information on flow velocity, date, and time. In another view, it also displays the volume flow rate for the day, month, and year. Additionally, the Soldering iron / Soldering device can output the measurement value as an analog signal (4 ... 20mA) and digitally via an RS485 interface.
With a power supply range of 9 ... 36 V DC, the fixed-installation Soldering iron / Soldering device is highly versatile and can be used in a wide range of applications. It comes with a 2m connection cable and coupling pads for improved signal transmission.
This Soldering iron / Soldering device can be used in various applications, including heating systems, cooling water systems, and industrial processes where flow monitoring and control are necessary.
