Probe Thermometer PCE-IR 835C

Probe Thermometer PCE-IR 835C

Order no.: PCE-IR 835C
GTIN (EAN): 4250348739377
67,90 €
price ex. (VAT / delivery)
:
4250348739377
PCE-IR 835C
Delivery time:1-2 working days

Description

Probe Thermometer for non-contact temperature measurement / 1.6-inch colour LCD / Circular laser targeting / °C and °F temperature units / IP54

The Probe Thermometer is suitable for fast, non-contact temperature measurement during servicing and maintenance work in mechanical and plant engineering, in heating, ventilation and air-conditioning systems, and for checking surfaces in various industrial applications. The Probe Thermometer enables measurements in the range from -50 … 800°C. It also features a Type K input for contact measurements from -50 … 1370°C.

With a response time of 150 ms, the Probe Thermometer enables rapid recording of temperature values. The 16:1 optical ratio allows measurements from a greater distance, while the circular laser targeting supports precise alignment with the measuring point. The emissivity can be adjusted from 0.10 … 1.0, allowing it to be adapted to different surfaces. HOLD, MAX, MIN, DIF and AVG functions, as well as upper and lower limit alarms, are available for checking measured values.

The Probe Thermometer features a backlit LCD and allows selection between °C and °F. Automatic switch-off, an out-of-range indicator and a trigger lock for continuous measurements complete its features. Power is supplied by two 1.5V AAA batteries. With an IP54 rating and robust construction, the Probe Thermometer is suitable for flexible use in industry, servicing and maintenance.


Highlights

- IR measuring range: -50 … 800°C
- Type K measuring range: -50 … 1370°C
- Fast response time of 150 ms
- Measuring spot ratio (D:S): 16:1
- Spectral range: 8 ... 14 μm
- Circular multi-point laser targeting
- MAX, MIN, DIF and AVG functions
- Automatic data hold function
- Adjustable emissivity
- Upper and lower limit alarms

Specification

Type K temperature
Measuring range  -50 ... 0 °C
Resolution  0,1 °C
Accuracy  ±2 °C

Type K temperature
Measuring range  0 ... 1000 °C
Resolution  0,1 °C
Accuracy  ±0.5% of reading or ±1.5°C (larger value applies)

Type K temperature
Measuring range  1000 ... 1370 °C
Resolution  1 °C
Accuracy  ±0.5% of reading or ±1.5°C (larger value applies)

Type K temperature
Measuring range  -58 ... +32 °F
Resolution  0,1 °F
Accuracy  3.6°F

Type K temperature
Measuring range  32 ... 1832 °F
Resolution  0,1 °F
Accuracy  ±0.5% or 3°F (larger value applies)

Type K temperature
Measuring range  1832 ... 2498 °F
Resolution  1 °F
Accuracy  ±0.5% or 3°F (larger value applies)

Infrared temperature
Measuring range  -50 ... +20 °C
Resolution  0,1 °C
Accuracy  ±3.5°C

Infrared temperature
Measuring range  20 ... 300 °C
Resolution  0,1 °C
Accuracy  ±1.0% of reading or ±1.0°C (larger value applies)

Infrared temperature
Measuring range  300 ... 800 °C
Resolution  0,1 °C
Accuracy  ±1.5% f.s.

Infrared temperature
Measuring range  -58 ... +68 °F
Resolution  0,1 °F
Accuracy  ±6.3°F

Infrared temperature
Measuring range  68 ... 572 °F
Resolution  0,1 °F
Accuracy  ±1% of reading or ±1.8°F (larger value applies)

Infrared temperature
Measuring range  572 ... 1472 °F
Resolution  1 °F
Accuracy  ±1.5% of full scale

General technical data
Measuring functions  MIN, MAX, HOLD, AVG, DIF
Display type  LC colour display with backlight
Display size  1,6 Inch
Response time  150 mS
Measurement spot  16:1
Laser  Class 2 <1mW
Alarm modes  Upper value
Lower value
Repeatability  ±1.8°C (±3.2°F) @ -50 ... 20°C (-31 ... 68°F)
±0.5% or ±0.5°C (±0.9°F) @ 20 ... 800°C (68 ... 1472°F)
Emissivity from/to  0.1 ... 1
Spectral range  8 ... 14 µm
Wavelength range  630 ... 670 Nm
Menu language  English, English (GB)
Protection class (device)  IP54
Power supply  batteries
(Rechargeable) battery  2 x 1,5 V AAA battery , Alkali-manganese
Capacity  1270 mAh
Performance  1,91 Wh
Operating conditions  0 ... 50 °C , 10 ... 90 % RH
Storage conditions  -10 ... 60 °C , 0 ... 80 % RH
Dimensions ( L x W x H )  175 x 50 x 98 mm
Weight  219 g

Delivery Scope

1 x Probe Thermometer PCE-IR 835C
1 x Type K thermocouple
2 x 1.5V AAA batteries
1 x Operating instructions
1 x Carrying case
