Food Hygiene / Hygiene Test Equipment PCE-PH20M-ICA

Food / Hygiene Meter PCE-PH20M-ICA incl. ISO calibration certificate

Order no.: PCE-PH20M-ICA

GTIN (EAN): 4250348728203

Description

PCE-PH20M-ICA Food / hygiene meter incl. ISO calibration certificate
Easy-to-use pH meter for pH determination / External pH electrode / Recalibratable / Waterproof (IP 67)

The food / hygiene meter was developed to directly determine the pH in food, e.g. meat. The waterproof food / hygiene meter PCE-PH20 is used for the fast and accurate measurement of pH. The practical display makes the pH value on the food / hygiene meter easy to read. Due to the waterproof and robust housing (IP 67), the pH value tester can also be used under difficult conditions. A recalibration always guarantees optimum accuracy and is very easy to perform using the optionally available calibration kits (automatic calibration function without calibration screws - to be performed only via the keyboard).

Highlights

- Waterproof (IP 67)

- Special external measuring electrode on cable

- High accuracy

- Auto-power-off for battery saver

- Supplied with calibration solutions

- Data hold function

- Easy-to-read digital display

- Easy to use

- incl. ISO-Calibration Certificate

Specification

pH
Measuring range	0 ... 14 pH
Resolution	0,01 pH
Accuracy	±0.07 pH (within range 5 ... 9 pH) / ±0.1 pH (within ranges 4 ... 4.9 and 9.1 ... 10 pH) / ±0.2 pH (within ranges 1 ... 3.9 and 10 ... 13 pH)

Electrode
Designation	CPC-OSH-12-01
Measuring range	0 ... 14 pH
Temperature range	0 ... 60 °C
Application	food
Reference electrolyte	Saturated KCl gel
Shank material	Glass
Material of diaphragm	Ceramics
Shank length	120 mm
Shank diameter	12 mm
Shank diameter additional information	Sensor diameter: 6 mm
Cable length	1 m
Connection	BNC

General technical data
Measuring functions	HOLD
Display type	LCD
Display size	1,35 Inch
Automatic power-off	10 min
Number of calibration points	3
Calibration	Automatically, at pH 4, pH 7, pH 10 using calibration solutions
Protection class (device)	IP67
(Rechargeable) battery	4 x 1,5 V AAA battery , Alkali-manganese
Capacity	1200 mAh
Operating conditions	0 ... 60 °C , 0 ... 80 % RH
Storage conditions	0 ... 60 °C , 0 ... 80 % RH
Dimensions ( L x W x H )	180 x 40 x 32 mm
Weight	220 g
