Digital Universal Indicator PCE-N30B

The digital universal indicator PCE-N30B is a Modbus display for up to 10 slave devices. In addition to displaying the measured values, this display can also trigger alarms, pass on measured values ​​in analog form and also save measured values. These functions make the built-in display unique. The built-in display is used as a Modbus master in a Modbus network. This built-in display makes it possible to process several Modbus slave devices. At the push of a button, you can then switch from which end device the measured values ​​are to be displayed. The internal data memory of the built-in display is sufficient for up to 308,000 sets of measured values. In addition, the memory can be upgraded with a SD memory card with a maximum of 4 GB. The measured values ​​can be passed on to other controls or similar via various optionally selectable outputs. For example, the user has an analog output and another Modbus interface that acts as a slave. The LED display can be switched in three colors. Alarms can be switched or processes controlled via internally installed relays.
