AED 621.00
| Direct voltage DC | |
| Measuring range | 0 ... 600 mV |
| Resolution | 0,1 mV |
| Accuracy | ±(1.0 % +2 digits) |
| Direct current DC | |
| Measuring range | 0 ... 200 A |
| Resolution | 0,1 A |
| Accuracy | ±(2.0% +5 digits) |
| AC voltage | |
| Measuring range | 0 ... 600 V |
| Resolution | 0,1 V |
| Accuracy | ±(1.5 % +8 digits) |
| Frequency range | 50 ... 60 Hz |
| Alternating current AC | |
| Measuring range | 0 ... 200 A |
| Resolution | 0,1 A |
| Accuracy | ±(2.5 % +8 digits) |
| Frequency range | 50 ... 60 Hz |
| Resistance | |
| Measuring range | 0 ... 999,9 Ω |
| Resolution | 0,1 Ω |
| Accuracy | ±(1.5 % +8 digits) |
| General technical data | |
| Measuring functions | MIN, MAX, HOLD |
| Display type | LCD with backlight |
| Display size | 1,4 Inch |
| Measuring rate | 10 Hz |
| Maximum cable diameter | 18 mm |
| Automatic power-off | 10 min |
| Safety standard | CAT III 600V, CAT IV 300V |
| Test current | <0.5 mA |
| Menu language | English, English (GB) |
| Protection class (device) | IP20 |
| (Rechargeable) battery | 2 x 1,5 V AAA battery , Alkali-manganese |
| Capacity | 1200 mAh |
| Operating conditions | -10 ... 50 °C , 0 ... 75 % RH |
| Storage conditions | -30 ... 60 °C , 0 ... 75 % RH |
| Dimensions ( L x W x H ) | 164 x 65 x 32 mm |
| Weight | 175 g |
