AED 966.00
The PAT Tester belongs to a series of highly accurate resistance devices that have a 6 digit display. These PAT Testers have been developed specifically for technical service and for difficult measurement conditions.
One of the advantages is the built in protection to avoid errors originating from loss of current. The PAT Tester contains a microprocessor and both optical and visual alarms. Factory calibration ensures the most accurate measurements with this series of PAT Testers.
| Insulation resistance | |
| Test voltage DC | 500V |
| Measuring range | 0 ... 30 GΩ |
| Resolution | 0,1 GΩ |
| Accuracy | ±5% |
| Insulation resistance | |
| Test voltage DC | 1000V |
| Measuring range | 0 ... 60 GΩ |
| Resolution | 0,1 GΩ |
| Accuracy | ±5% M Ω |
| Insulation resistance | |
| Test voltage DC | 2500V |
| Measuring range | 0 ... 150 GΩ |
| Resolution | 0,1 GΩ |
| Accuracy | ±5% |
| Insulation resistance | |
| Test voltage DC | 5000V |
| Measuring range | 0 ... 300 GΩ |
| Resolution | 0,1 GΩ |
| Accuracy | ±5% |
| General technical data | |
| Performance | 1 W |
| Menu language | English, English (GB) |
| Protection class (device) | IP20 |
| (Rechargeable) battery | 8 x 1,5 V AA battery , Alkali-manganese |
| Capacity | 3000 mAh |
| Operating conditions | 0 ... 40 °C , 0 ... 80 % RH |
| Storage conditions | 0 ... 40 °C , 0 ... 80 % RH |
| Dimensions ( L x W x H ) | 250 x 110 x 190 mm |
| Weight | 1500 g |
