AED 3,782.00
| Electric field strength | |
| Measuring range | 20 ... 108 mV/m |
| Resolution | 0,1 mV/m |
| Accuracy | ±1.0 dB (50 MHz ... 1.9 GHz) ±2.4 dB (1.9 GHz ... 3.5 GHz) ±1.0 dB (for frequency >50 MHz) |
| Magnetic field strength | |
| Measuring range | 53 ... 286,4 µA/m |
| Resolution | 0,1 µA/m |
| Accuracy | ±1.0 dB (50 MHz ... 1.9 GHz) ±2.4 dB (1.9 GHz ... 3.5 GHz) ±1.0 dB (for frequency >50 MHz) |
| Power flux density | |
| Measuring range | 1 µw/m² ... 30,93 W/m² |
| Resolution | 0,01 µw/m² |
| Accuracy | ±1.0 dB (50 MHz ... 1.9 GHz) ±2.4 dB (1.9 GHz ... 3.5 GHz) ±1.0 dB (for frequency >50 MHz) |
| Power flux density | |
| Measuring range | 0 µW/cm² ... 3,093 mW/cm² |
| Resolution | 0,01 µw/m² |
| Accuracy | ±1.0 dB (50 MHz ... 1.9 GHz) ±2.4 dB (1.9 GHz ... 3.5 GHz) ±1.0 dB (for frequency >50 MHz) |
| General technical data | |
| Measuring functions | AVG, MIN, MAX |
| Units | mV/m, V/m, µA/m, mA/m, µW/m², mW/m². |
| Frequency | 50 ... 3500 MHz |
| Display type | LCD |
| Storage medium | Internal memory |
| Storage capacity | 99 Data records |
| Sensor | Electric field |
| Response time | 1 s |
| Response time Additional information | until 90% of the final value is reached |
| Automatic power-off | 15 min |
| Alarm | optical, Acoustic |
| Measuring range selection | Automatic |
| Measurement error | absolute, at 1 V/m and 50 MHz: ±1.0 dB |
| Isotropic deviation | ±1.0 dB (at frequency >50 MHz) |
| Maximum overrange | 4.2 W/m² (40 V/m) |
| Temperature-related deviation | ±1.5 dB |
| Menu language | English, English (GB) |
| Protection class (device) | IP20 |
| (Rechargeable) battery | 1 x 9 V 9V block , Zinc carbon |
| Capacity | 640 mAh |
| Operating conditions | -10 ... 60 °C , 0 ... 80 % RH |
| Storage conditions | -10 ... 60 °C , 0 ... 80 % RH |
| Dimensions ( L x W x H ) | 237 x 60 x 60 mm |
| Weight | 350 g |
