Hardness Tester

Hardness Tester PCE-3000ULS
£ 3,280.00
Price excl. VAT &. delivery
2 year Warranty
The hardness tester can be used to quickly check the hardness of components even when installed. The hardness tester impresses with a large measuring range, easy handling, robust design and temperature resistance down to -20°C.

- Measurement according to UCI method and rebound method
- Testing of HRC, HV, HB
- Measuring direction 360 °
- Large LCD
- USB interface
- incl. UCI probe & type D Leebsonde
Portable Metal Hardness Tester PCE-2600N
£ 1,279.00
Price excl. VAT &. delivery
2 year Warranty

The Portable Metal Hardness Tester PCE-2600N is used wherever a fast hardness test has to be carried out. It is possible to use the hardness tester PCE-2600N to determine the surface hardness of many metals. The hardness tester PCE-2600N is especially suitable for quality or product inspection.

- Measurement according to Leeb Rebound method
- Measurement units: HLD, HRA, HRB, HRC, HB, HV, HS
- Measurement ranges: 170-960 HLD, 59.1-88 HRA, 3.5-101.7 HRB, 17.9-69.5 HRC, 19-683 HB, 80-1042 HV, 30.6-102.6 HS
- Accuracy: ± 0.5%, Repeatability: ± 0.8%
- Impactor: DL
- Display: 128 x 64 OLED

Portable Metal Hardness Tester with ISO Certificate PCE-2600N-ICA
£ 1,506.00
Price excl. VAT &. delivery
2 year Warranty
ISO Calibration

The Portable Metal Hardness Tester PCE-2600N-ICA is used wherever a fast hardness test has to be carried out. It is possible to use the hardness tester PCE-2600N-ICA to determine the surface hardness of many metals. The hardness tester PCE-2600N-ICA is especially suitable for quality or product inspection.

- Measurement according to Leeb Rebound method
- Measurement units: HLD, HRA, HRB, HRC, HB, HV, HS
- Measurement ranges: 170-960 HLD, 59.1-88 HRA, 3.5-101.7 HRB, 17.9-69.5 HRC, 19-683 HB, 80-1042 HV, 30.6-102.6 HS
- Accuracy: ± 0.5%, Repeatability: ± 0.8%
- Impactor: DL
- Display: 128 x 64 OLED
- Includes ISO calibration certificate

Hardness Tester PCE-2900
£ 1,563.00
Price excl. VAT &. delivery
2 year Warranty

The hardness tester PCE-2900 has been developed for hardness measurements on metallic materials. The hardness tester PCE-2900 measures the material hardness in Vickers, Brinell, Rockwell, Leeb and Shore. The hardness tester PCE-2900 measures the hardness according to the Leeb rebound principle.

- Measurement according to Leeb Rebound method
- Measurement units: HLD, HRA, HRB, HRC, HB, HV, HS
- Measurement ranges: 170-960 HLD, 59.1-88 HRA, 3.5-101.7 HRB, 17.9-69.5 HRC, 19-683 HB, 80-1042 HV, 30.6-102.6 HS
- Accuracy: ± 0.5%, Repeatability: ± 0.6%
- Impactor: Type D
- USB and WiFi for data transmission



Hardness Tester PCE-2900-ICA incl. ISO Calibration Certificate
£ 1,776.00
Price excl. VAT &. delivery
2 year Warranty
ISO Calibration

The hardness tester PCE-2900 has been developed for hardness measurements on metallic materials. The hardness tester PCE-2900 measures the material hardness in Vickers, Brinell, Rockwell, Leeb and Shore. The hardness tester PCE-2900 measures the hardness according to the Leeb rebound principle.

- Measurement according to Leeb Rebound method
- Measurement units: HLD, HRA, HRB, HRC, HB, HV, HS
- Measurement ranges: 170-960 HLD, 59.1-88 HRA, 3.5-101.7 HRB, 17.9-69.5 HRC, 19-683 HB, 80-1042 HV, 30.6-102.6 HS
- Accuracy: ± 0.5%, Repeatability: ± 0.6%
- Impactor: Type D
- USB and WiFi for data transmission
- Incl. ISO Calibration Certificate

Hardness Tester PCE-DD-A Shore A
£ 88.00
Price excl. VAT &. delivery
2 year Warranty

The PCE-DD-A hardness tester is used to measure Shore A hardness in soft gums, rubber, elastomers and more. Calibration is not available for this item.

- Measurement area: 0 ... 100 Shore A
- Resolution: 0.5
- Accuracy: ± 1
- Depth of indentation: 0 ... 2.5 mm / .1 in
- Indenter: 35°





Hardness Tester PCE-DD-D Shore D
£ 88.00
Price excl. VAT &. delivery
2 year Warranty

PCE-DD-D is a Shore D durometer or hardness tester. This Shore D hardness tester uses an impact rod with a 30º conical point and 50 Newtons (N) of force to make a surface indentation on material samples with a minimum thickness of 6 mm or 0.24 in. Calibration is not available for this item.


- For Shore D hardness testing of hard rubber, hard resin, acrylic, glass,
  thermoplastic and more
- Measurement range: 0 ... 100 Shore D
- Accuracy: ± 2 Hardness - Grade


Hardness Tester PCE-DX-AS Shore A
£ 121.00
Price excl. VAT &. delivery
2 year Warranty

Mechanical hardness tester for measuring hardness of soft elastomer with drag needle. The shore hardness tester is composed of a single component with a measuring head and a 360º dial. To improve the readability of peak value, the device comes with a drag needle, that ensures the maximum reading can be captured. Once it has been measured, it can be reset to zero.

- Force of pressure: 0 to 12.5 N
- Penetrating body: 35º (according to Shore A)
- Measurement range: 10 ... 90 (pressure diminishes below 10 and above 90)
- Margin of error: ± 1
- Division of scale: 1

Concrete Hardness Tester PCE-HT-225A
£ 346.00
Price excl. VAT &. delivery
2 year Warranty

PCE-HT-225A is a heavy-duty concrete hardness tester or concrete test hammer, also called a concrete rebound hammer or Swiss hammer, used to measure surface hardness and material compression strength. Suitable for use with concrete, rock and building materials, this rugged, manufacturer-calibrated rebound hammer is both easy to use and built to last.


- Test range: 10 ... 60 MPa or 100 ... 600 kg/cm² or 1450 ... 8702 psi
- Impact energy: 2.207 J or N-m / 0.225 kgf.m / 1.6278 ft-lb or Type N
- Impact stroke: 75 ± 0.3 mm / 2.95 ± 0.012 in
- Radius of spherical tip: 25 ± 1 mm / 0.99 ± 0.04 in
- kg/cm², psi, and MPa conversion tables
- Optional test anvil to verify accuracy listed under accessories

Hardness Tester PCE-DDD 10 Shore D
£ 560.00
Price excl. VAT &. delivery
2 year Warranty

The PCE-DDD 10 shore hardness tester and durometer is an ergonomic device to check Shore D hardness in materials such as hard rubber and thermoplastic. It has been designed with a very high quality.  The durometer (as all test instruments) comes manufacturer calibrated and can additionally be lab certified to ISO standards.


- Handheld device
- For Shore D measurements
- Single and Serial Measurements
- Data transfer to PC



Concrete Hardness Tester PCE-HT-75
£ 573.00
Price excl. VAT &. delivery
2 year Warranty
Topseller

The PCE-HT-75 Concrete Hardness Tester is easy to use and is fundamentally used in the construction industry as well as other industrial sectors (testing for Wickel hardness of rolls in commodities). This Hardness Tester in the form of a hammer device for testing concrete is based on the Swiss principle of measurement.


- Spring stretch: 75 ± 0.3 mm / 3 ± .01 in
- Measuring range: 10 ... 70 N/mm²
- Energy: 0.735 J / 0.54 ft-lbs
- Low strength concrete testing or Type L
- Indication of measurement: 0 to 100 (without dimensions)
- Maximum thickness of concrete (of the material): 70 cm

Hardness Tester for Metals PCE-2500N
£ 578.00
Price excl. VAT &. delivery
2 year Warranty

PCE-2500N is a portable handheld pen-sized digital material hardness tester, rebound hammer or durometer for use with metals. This high-accuracy hardness tester quickly and accurately measures the surface hardness of 10 common metal materials including steel, cast steel, alloy tool steel, stainless steel, cast iron, ductile iron, cast aluminum alloy, brass, bronze and copper.

- Measuring principle: Leeb Rebound method
- Displays measurements in Rockwell A, B or C (HRA, HRB or HRC), Brinell (HB), Vickers (HV), Shore (HS) or Leeb (HLD)
- Measurement ranges: 170-960 HLD, 59.1-88 HRA, 3.5-101.7 HRB, 17.9-69.5 HRC, 19-683 HB, 80-1042 HV, 30.6-102.6 HS
- Accuracy: ± 0.5%; Repeatability: ± 0.8%
Type D impact device

Hardness Tester PCE-HT 224E with Digital Display
£ 676.00
Price excl. VAT &. delivery
2 year Warranty
Wireless
The Hardness Tester is a measuring tool for testing the strength of concrete. The Hardness Tester measures strength according to the Schmidt principle. According to this measurement method, the quality of concrete can be measured with the Hardness Tester.  The Hardness Tester is also suitable for measuring hardness of rolled paper.  The Hardness Tester displays measurements Rebound Value and can display force in PSI, MPa, kgF/cm², or N/mm².

- Measuring range: 10 ... 100 N/mm² / 1500 ... 8500 PSI (lbs / in²)
- Impact energy: 2.207 J or N-m / 0.225 kgf.m / 1.6278 ft-lb or Type N
- Digital Display of results
- USB interface for connection to a PC
Data storage
- Rechargeable battery
Portable Metal Hardness Tester PCE-900
£ 693.00
Price excl. VAT &. delivery
2 year Warranty

The Leeb Portable Metal Hardness Tester PCE-900 measures the hardness of nine different metals using the Leeb rebound method. This means that with the portable metal hardness tester a firing pin bounces on a metallic surface and the intensity of the rebound is used as an indicator of the material hardness. The Portable Metal Hardness Tester PCE-900 measures the metal hardness in 6 different hardness scales.

- Measurement according to Leeb Rebound method
- Testing of HRC, HRB, HV, HB, HSD
- Measurement Range: 200-900 HLD / 13-99 HRB / 20-68 HRC / 20-655 HB / 80-940 HV / 32-99 HSD
- Accuracy: 0.80% / Repeatability: 1.10%
Incl. type D Leeb probe
- Optional Software Available

Hardness Tester PCE-DDD 10-ICA incl. ISO Calibration Certificate
£ 694.00
Price excl. VAT &. delivery
2 year Warranty
ISO Calibration

The PCE-DDD 10 shore hardness tester is an ergonomic device to check Shore D hardness in materials such as hard rubber and thermoplastic. It has been designed with a very high quality.


- Handheld device
- For Shore D measurements
- Single and Serial measurements
- Data transfer to PC
- Incl. ISO Calibration Certificate

Hardness Tester PCE-DDO 10 Shore O
£ 738.00
Price excl. VAT &. delivery
2 year Warranty

The PCE-DDO 10 hardness tester is an ergonomic device to check Shore O hardness in gum. It has been designed with a high quality. The PCE-DDO 10 hardness tester is mainly used for soft gums. If the material thickness is not enough, it should be tightened on the back with the same material in order to increase its thickness.


- Handheld device
- For Shore O measurements
- Single and Serial-Measurements
- Data transfer to PC



Hardness Tester PCE-2550
£ 780.00
Price excl. VAT &. delivery
2 year Warranty

Due to its compact design, the PCE-2550 hardness tester is easy to use for incoming and outgoing inspections. Due to the adjustable hardness scales, the hardness tester PCE-2550 is very versatile.

- Measuring ranges: 170 ... 960 HLD
- Measurement direction: 360°
- Impact device: Type D
- Measurement units: HL, HB, HRB, HRC, HRA, HV, HS
- Internal measurement memory

Hardness Tester PCE-2000N
£ 788.00
Price excl. VAT &. delivery
2 year Warranty
The PCE Instruments PCE-2000N hardness tester uses the Leeb rebound method. This is a dynamic hardness test method in which a standardized test specimen, usually a hard metal ball, is hit with defined impact energy on a test surface.

- Measurement according to Leeb Rebound method
- Hardness scales: HL (Leeb), HV (Vickers), HB (Brinell), HS (Shore), HRA (Rockwell A), HRB (Rockwell B), HRC (Rockwell C)
- Measurement Range: 170-960 HLD, 80-1042 HV, 19-683 HB, 30.6-102.6 HS, 59.1-88 HRA, 13.5-101.7 HRB
- External impact device on 1.5 m / 4.9 ft cable
- Accuracy: ± 0.5% (@ 800 HLD), Repeatability: 0.8% (@ 800 HLD)
- Storage data measurements on a USB stick
- Color display, Measurement in different angles possible, Various other impactors as accessories
